AC-DC Off Board
(Open Frame)

Advanced Filter Mode Selection

 Power, Package, Input Range and more

AC-DC Modules
(Industrial)

AC-DC Modules
(Medical)

AC-DC Power
Supply (Medical)

AC-DC DIN-Rail
(Industrial)

AC-DC Off Board
(Housing)

AC-DC Off Board
(Open Frame)


20 watts 20 watts 35 watts 35 watts 45 watts 45 watts 60 watts 60 watts 65 watts 65 watts 125 watts 125 watts 150 watts 150 watts 180 watts 180 watts 200 watts 200 watts 280 watts 280 watts 360 watts 360 watts 500 watts 500 watts
* SCP: Short Circuit Protection

20 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"20ACPO_S89 x 51 x 20 mmwide85-264VAC; 47-63Hz; 120-370VDC3.3; 5; 12; 15; 24; 483••80%-25°C ~ 70°CUL60950

20ACPO_S


Download PDF

20ACPO_S Series, Single Output Power Supplies without Active PFC,

  • 20 Watts Power Supply without Housing (89 x 51 x 20mm)
  • High efficiency up to 80%
  • Universal AC & DC input range (90~264Vac / 120~370Vdc)
  • Over voltage protection (OVP)
  • Over load protection (OLP)
  • Short circuit protection (SCP)
  • Wide operating ambient
  • Temperature range -25°C~ +70°C
  • 100% full load burn-in test
  • Easy assembling from top side

The series offers stability and high noise immunity especially for industrial control equipment, machinery and other demanding environments for industrial equipment.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

20ACPO_03S 3.3
20ACPO_05S 5
20ACPO_12S 12
20ACPO_15S 15
20ACPO_24S 24
20ACPO_48S 48

35 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"35ACPO_S101,6 x 51 x 24 mmwide90-264VAC; 47-63Hz5; 12; 24; 483••86%-20°C ~ 65°CUL60950

35ACPO_S


Download PDF

35ACPO_S Series, Single Output Power Supplies without Active PFC,

  • 35 Watts Power Supply without Housing (101,6 x 51 x 24mm)
  • High efficiency up to 86%
  • AC input range (90~264Vac)
  • Over voltage protection (OVP)
  • Over load protection (OLP)
  • Short circuit protection (SCP)
  • Wide operating ambient
  • Temperature range -20°C~ +65°C
  • 100% full load burn-in test
  • Easy assembling from top side

The series offers stability and high noise immunity especially for industrial control equipment, machinery and other demanding environments for industrial equipment.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

35ACPO_05S 5
35ACPO_12S 12
35ACPO_24S 24
35ACPO_48S 48

45 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"45ACPO_S101,6 x 51 x 28 mmwide90-264VAC; 47-63Hz12; 24; 483••86%-10°C ~ 60°CUL60950

45ACPO_S


Download PDF

45ACPO_S Series, Single Output Power Supplies without Active PFC,

  • 45 Watts Power Supply without Housing (101,6 x 51 x 28mm)
  • High efficiency up to 86%
  • AC input range (90~264Vac)
  • Over voltage protection (OVP)
  • Over load protection (OLP)
  • Short circuit protection (SCP)
  • Wide operating ambient
  • Temperature range -10°C~ +60°C
  • 100% full load burn-in test
  • Easy assembling from top side

The series offers stability and high noise immunity especially for industrial control equipment, machinery and other demanding environments for industrial equipment.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

45ACPO_12S 12
45ACPO_24S 24
45ACPO_48S 48

60 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"60ACPO_S101,6 x 50,8 x 30 mmwide90-264VAC; 47-63Hz5; 12; 15; 24; 483••87%-25°C ~ 70°CUL60950

60ACPO_S


Download PDF

60ACPO_SE Series, Single Output Power 2"x4" Supplies without Active PFC,

  • 60 Watts Power Supply without Housing (101,6 x 50,8 x 30mm)
  • High efficiency up to 87%
  • AC input range (90~264Vac)
  • Over voltage protection (OVP)
  • Over load protection (OLP)
  • Short circuit protection (SCP)
  • Wide operating ambient temperature
  • Temperature range -25°C~ +70°C
  • 100% full load burn-in test

The series offers stability and high noise immunity especially for industrial control equipment, machinery and other demanding environments for industrial equipment.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

60ACPO_05S 5
60ACPO_12S 12
60ACPO_15S 15
60ACPO_24S 24
60ACPO_48S 48
\"Details\"60ACPO_SE101,6 x 51 x 29 mmwide90-264VAC; 47-63Hz5; 12; 15; 24; 483••86%-10°C ~ 65°CUL60950

60ACPO_SE


Download PDF

60ACPO_SE Series, Single Output Power 2"x4" Supplies without Active PFC,

  • 60 Watts Power Supply without Housing (101,6 x 51 x 29mm)
  • High efficiency up to 86%
  • AC input range (90~264Vac)
  • Over voltage protection (OVP)
  • Over load protection (OLP)
  • Short circuit protection (SCP)
  • Wide operating ambient temperature
  • Temperature range -10°C~ +65°C
  • 100% full load burn-in test

The series offers stability and high noise immunity especially for industrial control equipment, machinery and other demanding environments for industrial equipment.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)


65 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"65ACMOP76,2 x 50,8 x 28,7 mmwide90-264VAC; 47-63Hz5, 12, 15, 19, 20, 24, 28,48, 564••87%-20°C - +70°CUL60601

65ACMOP


Download PDF

The 65ACMOP_S4 series is a compact size high power open frame supply offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B, DOW level VI and ErP tier 1 efficienecy compliant. Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • PCB size (L x W x H) 76,2 x 50,8 x 28,7 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • <0.21W (<0.1W / +5VDC) no load input power
  • Ultra low Earth leakage current <189uA @264VAC
  • High efficiency up to 87%
  • Short circuit protection (SCP)
  • EMI Class I (with PE) and Class II (without PE) configuration
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

65ACMOP_05S45
65ACMOP_12S412
65ACMOP_15S415
65ACMOP_19S419
65ACMOP_20S420
65ACMOP_24S424
65ACMOP_28S428
65ACMOP_48S448
65ACMOP_56S456

125 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"125ACPO_SP127 x 76 x 30,5mmwide90-264VAC; 47-63Hz; 127-370VDC5; 12; 15; 24; 36; 483••87%-20°C ~ 70°C•

125ACPO_SP


Download PDF

The 125ACPO_SC series features standard rail mounting, energy efficiency and is highly cost-effective.

  • 125 Watts Power Supply without Housing (127 x 76 x 30,5mm)
  • High efficiency up to 87%
  • Universal AC & DC input range (90~264Vac / 127~370Vdc)
  • Over voltage protection (OVP)
  • Over load protection (OLP)
  • Short circuit protection (SCP)
  • Wide operating ambient temperature
  • Temperature range -20°C~ +70°C
  • UL60950 approved
  • 100% full load burn-in test

The series offers stability and high noise immunity especially for industrial control equipment, machinery and other demanding environments for industrial equipment.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)


150 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"150ACPEW_S4

150ACPEW_S4


Download PDF

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).


180 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"180ACMOP127 x 76,2 x 30 mmwide90-264VAC; 47-63Hz 12, 15, 19, 24, 28, 484••87%0°C - +60°CUL60601

180ACMOP


Download PDF

The 180ACMOP_S4 series is a compact size high power open frame supply offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • PCB size (L x W x H) 76,2 x 50,8 x 28,7 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • Power Factor: >0.90
  • Ultra low Earth leakage current <100uA @264VAC
  • High efficiency up to 87%
  • Over load protection : 110% to 150% maximum rating
  • Over voltage protection
  • Short circuit protection (SCP)
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

180ACMOP_12S412
180ACMOP_15S415
180ACMOP_19S419
180ACMOP_24S424
180ACMOP_28S428
180ACMOP_48S448

200 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"200ACMUP176 x 95 x 50 mmwide90-264VAC; 47-63Hz 12, 16, 19, 20, 24, 36, 484••87%0°C - +60°CUL60601

200ACMUP


Download PDF

The 200ACMUP_S4 series is a compact size high power U-bracket supply offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • U-Bracket size (L x W x H) 176 x 95 x 50 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • Power Factor: >0.90
  • No load power consumtion <500mW
  • Ultra low Earth leakage current <228uA @264VAC
  • High efficiency up to 87%
  • Over load protection : 110% to 160% maximum rating
  • Over voltage protection
  • Short circuit protection (SCP)
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

200ACMUP_12S412
200ACMUP_16S416
200ACMUP_19S419
200ACMUP_20S420
200ACMUP_24S424
200ACMUP_36S436
\"Details\"200ACPO_SP128 x 76,5 x 34,6mmwide90-264VAC; 47-63Hz; 127 – 370Vdc12; 24; 483••90%-20°C ~ +70°C•UL60950

200ACPO_SP


Download PDF

The 200ACPO_SC series features standard rail mounting, energy efficiency and is highly cost-effective.

  • 200 Watts Power Supply without Housing (128 x 76,5 x 34,6mm)
  • High efficiency up to 90%
  • Universal AC & DC input range (90~264Vac / 127~370Vdc)
  • Over voltage protection (OVP)
  • Over load protection (OLP)
  • Short circuit protection (SCP)
  • Wide operating ambient temperature
  • Built-in Active PFC function
  • Temperature range -20°C~ +70°C
  • UL60950 approval
  • 100% full load burn-in test

The series offers stability and high noise immunity especially for industrial control equipment, machinery and other demanding environments for industrial equipment.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)


280 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"280ACMOP127 x 76,2 x 30 mmwide90-264VAC; 47-63Hz12, 24, 28, 36, 48, 544••91%-20°C - +70°CUL60601

280ACMOP


Download PDF

The 280ACMOP_S4 series is a compact size high power open-frame supply offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B, EN55032 Class B Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • PCB size (L x W x H) 127 x 76,2 x 30 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • Power Factor: >0.90
  • High efficiency up to 91%
  • Over load protection : 105% to 150% maximum rating
  • Over voltage protection
  • Short circuit protection (SCP)
  • Remote control funktion
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

280ACMOP_12S412
280ACMOP_24S424
280ACMOP_28S428
280ACMOP_36S436
280ACMOP_48S448
280ACMOP_56S456
\"Details\"280ACMUP127 x 83,2 x 38 mmwide90-264VAC; 47-63Hz12, 24, 28, 36, 48, 544••91%-20°C - +70°CUL60601

280ACMUP


Download PDF

The 280ACMUP_S4 series is a compact size high power U-bracket supply offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B, EN55032 Class B Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • PCB size (L x W x H) 127 x 83,2 x 38 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • Power Factor: >0.90
  • High efficiency up to 91%
  • Over load protection : 105% to 150% maximum rating
  • Over voltage protection
  • Short circuit protection (SCP)
  • Remote control funktion
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

280ACMUP_12S412
280ACMUP_24S424
280ACMUP_28S428
280ACMUP_36S436
280ACMUP_48S448
280ACMUP_54S454
\"Details\"280ACMHP127 x 83,2 x 39,5 mmwide90-264VAC; 47-63Hz12, 24, 28, 36, 48, 544••91%-20°C - +70°CUL60601

280ACMHP


Download PDF

The 280ACMUP_S4 series is a compact size high power supply with housing offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B, EN55032 Class B Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • PCB size (L x W x H) 127 x 83,2 x 39,5 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • Power Factor: >0.90
  • High efficiency up to 91%
  • Over load protection : 105% to 150% maximum rating
  • Over voltage protection
  • Short circuit protection (SCP)
  • Remote control funktion
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

280ACMHP_12S412
280ACMHP_24S424
280ACMHP_28S428
280ACMHP_36S436
280ACMHP_48S448
280ACMHP_54S454

360 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"360ACMOP152,4 x 101,6 x 30 mmwide90-264VAC; 47-63Hz12, 24, 28, 48, 544••90%-0°C - +70°CUL60601

360ACMOP


Download PDF

The 360ACMOP_S4 series is a compact size high power open-frame supply offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B, EN55032 Class B Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • PCB size (L x W x H) 152,4 x 101,6 x 30 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • Power Factor: >0.90
  • High efficiency up to 90%
  • Main Output and Standby output Power On LED indicators
  • Over load protection : 105% to 150% maximum rating
  • Over voltage protection
  • Short circuit protection (SCP)
  • Remote control function
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

360ACMOP_12S412
360ACMOP_24S424
360ACMOP_28S428
360ACMOP_48S448
360ACMOP_56S456
\"Details\"360ACMUP203,2 x 118,5 x 42 mmwide90-264VAC; 47-63Hz12, 24, 30, 36, 48, 54, 574••83%-0°C - +70°CUL60601

360ACMUP


Download PDF

The 360ACMUP_S4 series is a compact size high power U-bracket supply offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B, EN55032 Class B Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • PCB size (L x W x H) 203,2 x 118,5 x 42 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • Power Factor: >0.90
  • High efficiency up to 83%
  • Over load protection : 110% to 150% maximum rating
  • Over voltage protection
  • Short circuit protection (SCP)
  • Remote control function
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

360ACMUP_12S412
360ACMUP_24S424
360ACMUP_30S430
360ACMUP_36S436
360ACMUP_48S448
360ACMUP_54S454
360ACMUP_57S457

500 Watts AC-DC Off Board (Open Frame)


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

PFC

Fan

Certs

\"Details\"500ACMUP203,2 x 118,5 x 42 mmwide90-264VAC; 47-63Hz12, 24, 30, 36, 48, 54, 574••83%-0°C - +70°CUL60601

500ACMUP


Download PDF

The 500ACMUP_S4 series is a compact size high power U-bracket supply offered by GAPTEC with medical 60601-1 3rd Edition MOPP approved.

It offers high EMC performance meets EN 55011 Class B, EN55032 Class B Widely used in medical instrumentations and critical applications in commercial and industrial electronic equipment.

  • PCB size (L x W x H) 203,2 x 118,5 x 42 mm
  • Input range: 90~264VAC / 47-63Hz
  • Medical insulation 2x MOPP
  • Power Factor: >0.90
  • High efficiency up to 83%
  • Over load protection : 110% to 150% maximum rating
  • Over voltage protection
  • Short circuit protection (SCP)
  • Remote control function
  • Meet UL60950 AM2 Safety Approvals, UL 60601 3.1 Edition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button

Input Voltage (VDC)

Output Voltage (VDC)

500ACMUP_12S412
500ACMUP_24S424
500ACMUP_30S430
500ACMUP_36S436
500ACMUP_48S448
500ACMUP_54S454
500ACMUP_57S457
  • Imprint
  • Disclaimer/Privacy Policy
  • Terms & Conditions

© 2023 GAPTEC Electronic, All Rights Reserved.

  • Home
  • Products
    ▼
    • Power-Chart Overview
    • AC-DC Modules (Industrial)
    • AC-DC Modules (Medical)
    • AC-DC Power Supply Medical
    • AC DC DIN Rail
    • AC-DC Off Board (Housing)
    • AC-DC Off Board (Open Frame)
    • DC-DC Converters (Industrial)
    • DC-DC Converters (Railway)
    • DC-DC Converters (Telecom Power)
    • DC-DC Converters (IGBT & SiC)
    • DC-DC Converters (Photovoltaic)
    • DC-DC Converters (POL)
    • DC-DC Converters (PoE)
    • DC-DC Converters (LED Drivers)
  • Isolation Calculator
  • About us
  • Info
  • Application Notes
    ▼
    • Video: Linear Regulators
      vs. Switching Regulators
    • AC-DC
      Application Notes
    • Fixed Input (DC-DC)
      Application Notes
    • Wide Input (DC-DC)
      Application Notes
    • Railway (DC-DC)
      Application Notes
    • IGBT (DC-DC)
      Application Notes
    • Photovoltaic (DC-DC)
      Application Notes
    • Non-Isolated Switching Regulator
      Application Notes
    • LED (DC-DC)
      Application Notes
  • Approvals & Certifications
  • Components Service
  • Press Releases
  • Contact
  • 3D CAD
  • English
    ▼
    • Deutsch
We use cookies on our website to give you the most relevant experience by remembering your preferences and repeat visits. By clicking “Accept”, you consent to the use of ALL the cookies. However you may visit Cookie Settings to provide a controlled consent.
Cookie settingsAccept
Privacy & Cookies Policy

Privacy Preference Centre

When you visit any web site, it may store or retrieve information on your browser, mostly in the form of cookies. This information might be about you, your preferences or your device and is mostly used to make the site work as you expect it to. The information does not usually directly identify you, but it can give you a more personalised web experience. Because we respect your right to privacy, you can choose not to allow some types of cookies. Click on the different category headings to find out more and change our default settings. However, blocking some types of cookies may impact your experience of the site and the services we are able to offer. More information

Strictly Necessary Cookies
Always Enabled

These cookies are necessary for the website to function and cannot be switched off in our systems. You can set your browser to block or alert you about these cookies, but some parts of the site will not work as a result. These cookies are not used to market or advertise to site visitors.

Performance Cookies

These cookies allow us to count visits and traffic sources so we can measure and improve site performance. Information these cookies collect is anonymous. If you do not allow these cookies we will not know when you have visited our site, and will not be able to monitor its performance.

Functional Cookies

These cookies enable the website to provide enhanced functionality and personalization. They may be set by us or by third party providers whose services we have added to our pages. If you do not allow these cookies then some or all of these services may not function properly.

Targeting Cookies

These cookies may be set through our site by our advertising partners, or by social media services that we have added to the site to enable you to share our content with your friends and networks. These cookies have been disabled for visitors from certain geographies in compliance with local law.

  • English
  • German
