AC-DC Power Supplies (Industrial & Medical)

We are excited to announce the release of our latest product, the 3S6W4_1.6RP series, a highperformance
and high-power density DC-DC converter. This versatile converter is designed to meet the
needs of a wide range of applications, providing efficient and reliable power conversion.
Key Features and Specifications:

1. Wide 4:1 input voltage range: The 3S6W4_1.6RP series offers a wide input voltage range,
   accommodating various power sources and providing flexibility in system design.
2. Operating temperature range of -40°C to +75°C: Designed to withstand extreme temperature
   conditions, this converter ensures reliable operation in challenging environments.
3. High efficiency up to 86%: With its high-efficiency rating, the 3S6W4_1.6RP series minimizes
   energy loss, maximizing power conversion and reducing operating costs.
4. 3W single and dual outputs: The converter is available in both single and dual output
   configurations, providing flexibility to meet different application requirements.
5. I/O isolation 1.6kVDC and 3kVDC option: With its isolation capabilities, the converter ensures
   safe operation and protects sensitive components from voltage fluctuations.
6. Continuous short circuit protection and remote ON/OFF control: The 3S6W4_1.6RP series
   features continuous short circuit protection, safeguarding the system from potential damage. The
   remote ON/OFF control allows for convenient operation and power management.
7. Excellent performance and high-power density design: The 3S6W4_1.6RP series combines
   exceptional performance and high-power density, delivering reliable and efficient power
   conversion in a compact package.
   The 3S6W4_1.6RP series is designed to meet the demands of various industries, including batterypowered
   equipment and instrumentation. Its wide input voltage range, high efficiency, and low standby
   power consumption make it an ideal choice for applications requiring efficient power conversion.
   GAPTEC Electronic is a leading provider of innovative power supply solutions, committed to delivering
   high-performance, reliable, and efficient products to meet the evolving needs of various industries. With
   a focus on quality and customer satisfaction, we strive to empower businesses with advanced technology
   and exceptional support. GAPTEC Electronic guarantees very short delivery times. The product warranty
   is 3 years.

Download Data Sheet 3S6W4_1.6RP

Interview with Dipl.-Ing. (FH) Michael Altfeld, Managing Director at GAPTEC Electronic GmbH & Co. KG.

Click here to read the interview

GAPTEC Electronic presents the new isolated & regulated AC-DC DIN Rail series.

The xxxACDRS_SC series is featuring lightweight AC-DC converters that are offering space saving and compact design, that is ideal for applications such as industrial control equipment machinery and all kinds of applications in a harsh environment. The series is a cost effective and energy efficient solution for standard DIN Rail mounting and meets IEC/EN61000-4, CISPR32, EN55032, UL/EN/IEC62368, IEC/EN60335, IEC61558, UL61010 standards.

– Universal 85 – 264VAC (277VAC available) or 120-370VDC input voltage
– Accepts AC or DC input (dual-use of same terminal)
– Operating ambient temperature range from -30°C to +70°C
– Up to 4000VAS isolation
– High efficiency and high reliability
– Output short circuit protection
– Low standby power consumption, low ripple & noise

GAPTEC Electronic presents the new AC-DC DIN Rail Housing series.

The xxxACDRH_SC series is featuring a cost-effective, energy efficient green power supply solution for standard DIN Rail mounting. The products offer a high level of stability and immunity to noise for industrial control equipment, machinery, and other industrial equipment. These lightweight AC-DC converters are offering a compact design and standard space saving rail installation. The EMC performance is compliant with international IEC/EN/UL62368, UL61010, UL508 standards for EMC and safety.

– Universal 85 – 264VAC or 120-370VDC input voltage
– Accepts AC or DC input (dual-use of the same terminal)
– Operating ambient temperature range -40°C to +70°C
– Built-in active PFC function
– High efficiency and high reliability
– Output short circuit protection

GAPTEC Electronic presents the new 10ACFEW_3 series that offers AC or DC input.

The 10ACFEW_3 series features an ultra-wide input range (85-305VAC & 100-430VDC) accepting either
AC or DC voltage, high efficiency up to 83%, a low no-load power consumption (0.1W) and Class II
reinforced insulation. All models are particularly suitable for industrial control, electric power,
instrumentation and smart home applications. This series is IEC62368 and UL62368 approved.

• Wide Input voltage range: 85-305VAC & 70-430VDC
• SIP Package (L x W x H) 32.00 x 17.20 x 15.05 mm
• 3000VAC/1 Min. Isolation
• AC and DC All in one (input from the same terminal)
• Low ripple and noise (80mV – 20MHz Bandwidth)
• EMC meets EN55032 Class B with external components
• No-load power consumption 0.1W
• High efficiency up to 83%
• Over output current protection
• Short circuit protection (SCP)
• IEC62368 and UL62368 standards approved
• 3 years warranty

Download Data Sheet 10ACFEW_3
