DC-DC Converters
(Industrial)

Quick Filter Mode Selection

All SMD THT

Advanced Filter Mode Selection

 Power, Package, Input Range and more

DC-DC Converters

(Industrial - SMD)

Find Products

DC-DC Converters

(Industrial - THT)

Find Products

DC-DC Converters

(Railway)

Find Products

DC-DC Converters

(Telecom Power)

Find Products

DC-DC Converters

(Photovoltaic)

Find Products

DC-DC Converters

(IGBT & SiC)

Find Products

0.1 watt 0.1 watt 0.25 watts 0.25 watts 0.5 watts 0.5 watts 0.75 watts 0.75 watts 1 watts 1 watts 2 watts 2 watts 3 watts 3 watts 5 watts 5 watts 6 watts 6 watts 7.5 watts 7.5 watts 8 watts 8 watts 9 watts 9 watts 10 watts 10 watts 12 watts 12 watts 15 watts 15 watts 20 watts 20 watts 25 watts 25 watts 30 watts 30 watts 40 watts 40 watts 50 watts 50 watts 60 watts 60 watts 75 watts 75 watts 100 watts 100 watts 150 watts 150 watts 200 watts 200 watts 350 watts 350 watts 400 watts 400 watts 450 watts 450 watts 500 watts 500 watts 700 watts 700 watts
* SCP: Short Circuit Protection


0.1 Watt DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details0.1S4A_1.5USIP4±10%3.3; 5; 123.3; 5; 121.5 86%-40°C - +85°C

0.1S4A_1.5U

Download PDF

The 0.1S4A series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 100mW Output Power
  • SIP Package (L x W x H) 11.48 x 6.0 x 10.0 mm
  • 1,5 KVDC Isolation
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.1S4A_0303S1.5U 3.33.3
0.1S4A_0305S1.5U 3.35
0.1S4A_0503S1.5U 53.3
0.1S4A_0505S1.5U 55
0.1S4A_0509S1.5U 59
0.1S4A_0512S1.5U 512
0.1S4A_0515S1.5U 515
0.1S4A_1205S1.5U 125
0.1S4A_1209S1.5U 129
0.1S4A_1212S1.5U 1212
0.1S4A_1215S1.5U 1215
Details0.1MS4A_1.5UPSIP4 micro±10%3.3; 5; 123.3; 5; 9; 12; 151.5•78%-40°C - +105°C

0.1MS4A_1.5UP

Download PDF

The 0.1MS4A series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 100mW Output Power
  • SIP4 Micro Package (L x W x H) 11.48 x 6.00 x 7.46 mm
  • 1500 VDC Isolation
  • Temperature Range: -40°C ~ +105°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.1MS4A_0303S1.5UP 3.33.3
0.1MS4A_0305S1.5UP 3.35
0.1MS4A_0309S1.5UP 3.39
0.1MS4A_0503S1.5UP 53.3
0.1MS4A_0505S1.5UP 55
0.1MS4A_0509S1.5UP 59
0.1MS4A_0512S1.5UP 512
0.1MS4A_0515S1.5UP 515
0.1MS4A_1205S1.5UP 125
0.1MS4A_1209S1.5UP 129
0.1MS4A_1212S1.5UP 1212
0.1MS4A_1215S1.5UP 1215
Details0.1MD4A_1.5UDIP4 micro±10%3.3; 5;3.3; 51.5 50%-40°C - +85°C

0.1MD4A_1.5U

Download PDF

The 0.1MD4A series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 100mW Output Power
  • DIP4 Micro Package (L x W x H) 9.40 x 8.80 x 6.35 mm
  • 1.5 KVDC Isolation
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.1MD4A_0303S1.5U 3.33.3
0.1MD4A_0503S1.5U 53.3
0.1MD4A_0505S1.5U 55
Details0.1D8A_1.5UDIP8±10%3.3; 5; 123.3; 5; 9; 12; 151.5 86%-40°C - +85°C

0.1D8A_1.5U

Download PDF

The 0.1D8A series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 100mW Output Power
  • DIP8 Package (L x W x H) 11.5 x 9.8 x 6.8 mm
  • 1,5 KVDC Isolation
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.1D8A_0303S1.5U 3.33.3
0.1D8A_0305S1.5U 3.35
0.1D8A_0503S1.5U 53.3
0.1D8A_0505S1.5U 55
0.1D8A_0509S1.5U 59
0.1D8A_0512S1.5U 512
0.1D8A_0515S1.5U 515
0.1D8A_1205S1.5U 125
0.1D8A_1209S1.5U 129
0.1D8A_1212S1.5U 1212
0.1D8A_1215S1.5U 1215
Details0.1S7B_3UPSIP7±10%3.3; 5; 12; 15; 243.3; 5; 9; 12; 15; 24; ±5 ±9; ±12; ±153•80%-40°C - +105°C

0.1S7B_3UP

Download PDF

The 0.1S7B_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 100mW Output Power
  • SIP7 Package (L x W x H) 19.5 x 6.0 x 10.0 mm
  • 3 KVDC Isolation
  • Short circuit Protection (SCP)
  • Temperature Range: -40°C ~ +105°C
  • Power sharing on dual output
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.1S7B_0303S3UP 3.33.3
0.1S7B_0305S3UP 3.35
0.1S7B_0505D3UP 55
0.1S7B_0505S3UP 55
0.1S7B_0509D3UP 59
0.1S7B_0509S3UP 59
0.1S7B_0512D3UP 512
0.1S7B_0512S3UP 512
0.1S7B_0515D3UP 515
0.1S7B_0515S3UP 515
0.1S7B_0524S3UP 524
0.1S7B_1205D3UP 125
0.1S7B_1205S3UP 125
0.1S7B_1209D3UP 129
0.1S7B_1209S3UP 129
0.1S7B_1212D3UP 1212
0.1S7B_1212S3UP 1212
0.1S7B_1215D3UP 1215
0.1S7B_1215S3UP 1215
0.1S7B_1505D3UP 155
0.1S7B_1505S3UP 155
0.1S7B_1512D3UP 1512
0.1S7B_1512S3UP 1512
0.1S7B_1515D3UP 1515
0.1S7B_1515S3UP 1515
Details0.1D14B_3UPDIP14±10%3.3; 5; 123.3; 5; 9; 12; 15; ±5 ±9; ±12; ±153•80%-40°C - +105°C

0.1D14B_3UP

Download PDF

The 0.1D14B_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 100mW Output Power
  • DIP14 Package (L x W x H) 19.5 x 9.8 x 6.8 mm
  • 3 KVDC Isolation
  • Short circuit Protection (SCP)
  • Temperature Range: -40°C ~ +105°C
  • Power sharing on dual output
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.1D14B_0303S3UP 3.33.3
0.1D14B_0305S3UP 3.35
0.1D14B_0505D3UP 55
0.1D14B_0505S3UP 55
0.1D14B_0509D3UP 59
0.1D14B_0509S3UP 59
0.1D14B_0512D3UP 512
0.1D14B_0512S3UP 512
0.1D14B_0515D3UP 515
0.1D14B_0515S3UP 515
0.1D14B_1205D3UP 125
0.1D14B_1205S3UP 125
0.1D14B_1209D3UP 129
0.1D14B_1209S3UP 129
0.1D14B_1212D3UP 1212
0.1D14B_1212S3UP 1212
0.1D14B_1215D3UP 1215
0.1D14B_1215S3UP 1215


0.25 Watt DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

DetailsQS4E_1USIP4±10%3.3; 5; 7,2; 12; 15; 24; 483.3; 5; 7.2; 9; 12; 15; 241 74%-40°C - +85°C

QS4E_1U

Download PDF

The QS4E_1U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP Package (L x W x H) 11.68 x 6.0 x 10.15 mm
  • 1 KVDC Isolation
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

QS4E_0303S1U 3.33.3
QS4E_0305S1U 3.35
QS4E_0307S1U 3.37.2
QS4E_0309S1U 3.39
QS4E_0312S1U 3.312
QS4E_0315S1U 3.315
QS4E_0318S1U 3.318
QS4E_0324S1U 3.324
QS4E_0503S1U 53.3
QS4E_0505S1U 55
QS4E_0507S1U 57.2
QS4E_0509S1U 59
QS4E_0512S1U 512
QS4E_0515S1U 515
QS4E_0518S1U 518
QS4E_0524S1U 524
QS4E_1203S1U 123.3
QS4E_1205S1U 125
QS4E_1207S1U 127.2
QS4E_1209S1U 129
QS4E_1212S1U 1212
QS4E_1215S1U 1215
QS4E_1218S1U 1218
QS4E_1224S1U 1224
QS4E_1503S1U 153.3
QS4E_1505S1U 155
QS4E_1507S1U 157.2
QS4E_1509S1U 159
QS4E_1512S1U 1512
QS4E_1515S1U 1515
QS4E_1518S1U 1518
QS4E_1524S1U 1524
QS4E_2403S1U 243.3
QS4E_2405S1U 245
QS4E_2407S1U 247.2
QS4E_2409S1U 249
QS4E_2412S1U 2412
QS4E_2415S1U 2415
QS4E_2418S1U 2418
QS4E_2424S1U 2424
QS4E_4803S1U 483.3
QS4E_4805S1U 485
QS4E_4807S1U 487.2
QS4E_4809S1U 489
QS4E_4812S1U 4812
QS4E_4815S1U 4815
QS4E_4818S1U 4818
QS4E_4824S1U 4824
DetailsQS4E_3USIP4±10%3.3; 5; 7,2; 12; 15; 24; 483.3; 5; 7.2; 9; 12; 15; 243 76%-40°C - +85°C

QS4E_3U

Download PDF

The QS4E_3U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP Package (L x W x H) 11.68 x 6.0 x 10.15 mm
  • 3 KVDC Isolation
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

QS4E_0303S3U 3.33.3
QS4E_0305S3U 3.35
QS4E_0307S3U 3.37.2
QS4E_0309S3U 3.39
QS4E_0312S3U 3.312
QS4E_0315S3U 3.315
QS4E_0318S3U 3.318
QS4E_0324S3U 3.324
QS4E_0503S3U 53.3
QS4E_0505S3U 55
QS4E_0507S3U 57.2
QS4E_0509S3U 59
QS4E_0512S3U 512
QS4E_0515S3U 515
QS4E_0518S3U 518
QS4E_0524S3U 524
QS4E_1203S3U 123.3
QS4E_1205S3U 125
QS4E_1207S3U 127.2
QS4E_1209S3U 129
QS4E_1212S3U 1212
QS4E_1215S3U 1215
QS4E_1218S3U 1218
QS4E_1224S3U 1224
QS4E_1503S3U 153.3
QS4E_1505S3U 155
QS4E_1507S3U 157.2
QS4E_1509S3U 159
QS4E_1512S3U 1512
QS4E_1515S3U 1515
QS4E_1518S3U 1518
QS4E_1524S3U 1524
QS4E_2403S3U 243.3
QS4E_2405S3U 245
QS4E_2407S3U 247.2
QS4E_2409S3U 249
QS4E_2412S3U 2412
QS4E_2415S3U 2415
QS4E_2418S3U 2418
QS4E_2424S3U 2424
QS4E_4803S3U 483.3
QS4E_4805S3U 485
QS4E_4807S3U 487.2
QS4E_4809S3U 489
QS4E_4812S3U 4812
QS4E_4815S3U 4815
QS4E_4818S3U 4818
QS4E_4824S3U 4824
DetailsQS4E_1.5UPSIP4±10%3.3; 5; 12; 243.3; 5; 9; 12; 151.5•75%-40°C - +105°C

QS4E_1.5UP

Download PDF

The QS4E_1.5UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP Package (L x W x H) 11.48 x 6.00 x 10.00 mm
  • 1.5 KVDC Isolation
  • Short Circuit Protection (SCP)
  • Temperature Range: -40°C ~ +105°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

DetailsQD8E_1UDIP8±10%3.3; 5; 12; 15; 243.3; 5; 7,2; 9; 12; 15; 24173% -40°C - +85°C

QD8E_1U

Download PDF

The QD8E_1U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP Package (L x W x H) 12.7 x 6,85 x 10.16 mm
  • 1 KVDC Isolation
  • EMI complies with EN55032 CLASS B
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

QD8E_0303S1U 3.33.3
QD8E_0305S1U 3.35
QD8E_0307S1U 3.37.2
QD8E_0309S1U 3.39
QD8E_0312S1U 3.312
QD8E_0315S1U 3.315
QD8E_0318S1U 3.318
QD8E_0324S1U 3.324
QD8E_0503S1U 53.3
QD8E_0505S1U 55
QD8E_0507S1U 57.2
QD8E_0509S1U 59
QD8E_0512S1U 512
QD8E_0515S1U 515
QD8E_0518S1U 518
QD8E_0524S1U 524
QD8E_1203S1U 123.3
QD8E_1205S1U 125
QD8E_1207S1U 127.2
QD8E_1209S1U 129
QD8E_1212S1U 1212
QD8E_1215S1U 1215
QD8E_1218S1U 1218
QD8E_1224S1U 1224
QD8E_1503S1U 153.3
QD8E_1505S1U 155
QD8E_1507S1U 157.2
QD8E_1509S1U 159
QD8E_1512S1U 1512
QD8E_1515S1U 1515
QD8E_1518S1U 1518
QD8E_1524S1U 1524
QD8E_2403S1U 243.3
QD8E_2405S1U 245
QD8E_2407S1U 247.2
QD8E_2409S1U 249
QD8E_2412S1U 2412
QD8E_2415S1U 2415
QD8E_2418S1U 2418
QD8E_2424S1U 2424
DetailsQD8E_1.5UPDIP8±10%3.3; 5; 12; 243.3; 5; 9; 12; 151.5•75%-40°C - +105°C

QD8E_1.5UP

Download PDF

The QD8E_1.5UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. Features:

  •     DIP Package (L x W x H) 11.50 x 9,80 x 6.80 mm
  •     1.5 KVDC Isolation
  •     Continuous Short Circuit Protection [SCP]
  •     Temperature Range: -40°C ~ +105°C
  •     No Heatsink Required
  •     Internal SMD Construction
  •     No External Component Required
  •     Industry Standard Pinout
  •     RoHS Compliance

Field of application:

  •     Purely Digital Circuits
  •     Ordinary low frequency analog circuits
  •     IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

DetailsQD8E_3UDIP8±10%3.3; 5; 12; 15; 243.3; 5; 7,2; 9; 12; 15; 24373% -40°C - +85°C

QD8E_3U

Download PDF

The QD8E_3U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. Features:

  •     DIP Package (L x W x H) 12.7 x 6,85 x 10.16 mm
  •     3 KVDC Isolation
  •     EMI complies with EN55032 CLASS B
  •     Temperature Range: -40°C ~ +85°C
  •     No Heatsink Required
  •     Internal SMD Construction
  •     No External Component Required
  •     Industry Standard Pinout
  •     RoHS Compliance

Field of application:

  •     Purely Digital Circuits
  •     Ordinary low frequency analog circuits
  •     IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

QD8E_0303S3U 3.33.3
QD8E_0305S3U 3.35
QD8E_0307S3U 3.37.2
QD8E_0309S3U 3.39
QD8E_0312S3U 3.312
QD8E_0315S3U 3.315
QD8E_0318S3U 3.318
QD8E_0324S3U 3.324
QD8E_0503S3U 53.3
QD8E_0505S3U 55
QD8E_0507S3U 57.2
QD8E_0509S3U 59
QD8E_0512S3U 512
QD8E_0515S3U 515
QD8E_0518S3U 518
QD8E_0524S3U 524
QD8E_1203S3U 123.3
QD8E_1205S3U 125
QD8E_1207S3U 127.2
QD8E_1209S3U 129
QD8E_1212S3U 1212
QD8E_1215S3U 1215
QD8E_1218S3U 1218
QD8E_1224S3U 1224
QD8E_1503S3U 153.3
QD8E_1505S3U 155
QD8E_1507S3U 157.2
QD8E_1509S3U 159
QD8E_1512S3U 1512
QD8E_1515S3U 1515
QD8E_1518S3U 1518
QD8E_1524S3U 1524
QD8E_2403S3U 243.3
QD8E_2405S3U 245
QD8E_2407S3U 247.2
QD8E_2409S3U 249
QD8E_2412S3U 2412
QD8E_2415S3U 2415
QD8E_2418S3U 2418
QD8E_2424S3U 2424
DetailsQS7A_3UPSIP7±10%3.3; 5; 12; 153.3; 5; 9; 12; 15; 243•73% -40°C - +85°C

QS7A_3UP

Download PDF

The QS7A_3UP series is specially designed for applications where a group of

polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 Package (L x W x H) 19.5 x 6.0 x 10.0 mm
  • 3 KVDC Isolation
  • Short circuit Protection (SCP)
  • Pin-Style A
  • Temperature Range: -40°C ~ +105°C
  • Power sharing on dual output
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

DetailsQS7B_3UPSIP7±10%3.3; 5; 12; 15±5 ±9; ±12; ±15; ±243•81%-40°C - +105°C

QS7B_3UP

Download PDF

The QS7B_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 Package (L x W x H) 19.5 x 6.0 x 10.0 mm
  • 3 KVDC Isolation
  • Short circuit Protection (SCP)
  • Temperature Range: -40°C ~ +105°C
  • Power sharing on dual output
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

QS7B_0303S3UP 3.33.3
QS7B_0305S3UP 3.35
QS7B_0505D3UP 55
QS7B_0505S3UP 55
QS7B_0509D3UP 59
QS7B_0509S3UP 59
QS7B_0512D3UP 512
QS7B_0512S3UP 512
QS7B_0515D3UP 515
QS7B_0515S3UP 515
QS7B_0524D3UP 524
QS7B_0524S3UP 524
QS7B_1203S3UP 123.3
QS7B_1205D3UP 125
QS7B_1205S3UP 125
QS7B_1209D3UP 129
QS7B_1209S3UP 129
QS7B_1212D3UP 1212
QS7B_1212S3UP 1212
QS7B_1215D3UP 1215
QS7B_1215S3UP 1215
QS7B_1224D3UP 1224
QS7B_1505D3UP 155
QS7B_1505S3UP 155
QS7B_1509D3UP 159
QS7B_1512D3UP 1512
QS7B_1512S3UP 1512
QS7B_1515D3UP 1515
QS7B_1515S3UP 1515
QS7B_1524D3UP 1524
DetailsQT8E_1USMD8±10%3.3; 5; 12; 153.3; 5; 9; 12; 151 72% -40°C - +85°C

QT8E_1U

Download PDF

QT8E_1U SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.25W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8 Package (L x W x H) 12.70 x 11.05 x 6.25 mm
  • Cost Effective
  • RoHS compliant
  • 1000VDC isolation
  • Operating temperature range: -40°C℃~ +85°C
  • Efficiency up to 72%
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

QT8E_0303S1U 3.33.3
QT8E_0305S1U 3.35
QT8E_0309S1U 3.39
QT8E_0312S1U 3.312
QT8E_0315S1U 3.315
QT8E_0503S1U 53.3
QT8E_0505S1U 55
QT8E_0509S1U 59
QT8E_0512S1U 512
QT8E_0515S1U 515
QT8E_1203S1U 123.3
QT8E_1205S1U 125
QT8E_1209S1U 129
QT8E_1212S1U 1212
QT8E_1215S1U 1215
QT8E_1503S1U 153.3
QT8E_1505S1U 155
QT8E_1509S1U 159
QT8E_1512S1U 1512
QT8E_1515S1U 1515
DetailsQT8A1_1.5UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 151.5•77%-40°C - +105°C

QT8A1_1.5UP

Download PDF

The QT8A1_1.5UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SMD 5/8 Pin Package (L x W x H) 12.70 x 7.60 x 6.25 mm
  • 1500VDC isolation
  • Efficiency up to 77%
  • Operating temperature range: -40°C℃~ +105°C
  • Isolation capacitance20pF
  • Internal SMD construction
  • Industry standard pinout
  • RoHS Compliance
  • Short circuit prtection (SCP)

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

DetailsQT8B1_1.5UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 151.5•77%-40°C - +105°C

QT8B1_1.5UP

Download PDF

The QT8B1_1.5UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SMD 8/8 Pin Package (L x W x H) 12.70 x 7.60 x 6.25 mm
  • 1500VDC isolation
  • Efficiency up to 77%
  • Operating temperature range: -40°C℃~ +105°C
  • Isolation capacitance20pF
  • Internal SMD construction
  • Industry standard pinout
  • RoHS Compliance
  • Short circuit prtection (SCP)

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

DetailsQT8A_3UPSMD8±10%3.3; 5; 12; 15; 243.3; 5; 9; 12; 153•78% -40°C - +105°C

QT8A_3UP

Download PDF

QT8A_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.25W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8/5 Package (L x W x H) 13.7 x 11.0 x 7.0 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +105°C
  • Efficiency up to 78%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

QT8A_0303S3UP 3.33.3
QT8A_0305S3UP 3.35
QT8A_0309S3UP 3.39
QT8A_0312S3UP 3.312
QT8A_0315S3UP 3.315
QT8A_0503S3UP 53.3
QT8A_0505S3UP 55
QT8A_0509S3UP 59
QT8A_0512S3UP 512
QT8A_0515S3UP 515
QT8A_1203S3UP 123.3
QT8A_1205S3UP 125
QT8A_1209S3UP 129
QT8A_1212S3UP 1212
QT8A_1215S3UP 1215
QT8A_1505S3UP 155
QT8A_1515S3UP 1515
QT8A_2403S3UP 243.3
QT8A_2405S3UP 245
QT8A_2409S3UP 249
QT8A_2412S3UP 2412
QT8A_2415S3UP 2415
DetailsQT8A1_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•77%-40°C - +105°C

QT8A1_3UP

Download PDF

The QT8A1_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SMD 5/8 Pin Package (L x W x H) 12.70 x 7.60 x 6.25 mm
  • 3000VDC isolation
  • Efficiency up to 77%
  • Operating temperature range: -40°C℃~ +105°C
  • Isolation capacitance20pF
  • Internal SMD construction
  • Industry standard pinout
  • RoHS Compliance
  • Short circuit prtection (SCP)

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

DetailsQT8B1_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•77%-40°C - +105°C

QT8B1_3UP

Download PDF

The QT8B1_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SMD 8/8 Pin Package (L x W x H) 12.70 x 7.60 x 6.25 mm
  • 3000VDC isolation
  • Efficiency up to 77%
  • Operating temperature range: -40°C℃~ +105°C
  • Isolation capacitance20pF
  • Internal SMD construction
  • Industry standard pinout
  • RoHS Compliance
  • Short circuit prtection (SCP)

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

DetailsQT8B_3UPSMD8±10%3.3; 5; 12; 15; 243.3; 5; 9; 12; 153•78% -40°C - +105°C

QT8B_3UP

Download PDF

QT8B_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.25W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8/8 Package (L x W x H) 13.7 x 11.0 x 7.0 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +105°C
  • Efficiency up to 78%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

QT8B_0303S3UP 3.33.3
QT8B_0305S3UP 3.35
QT8B_0309S3UP 3.39
QT8B_0312S3UP 3.312
QT8B_0315S3UP 3.315
QT8B_0503S3UP 53.3
QT8B_0505S3UP 55
QT8B_0509S3UP 59
QT8B_0512S3UP 512
QT8B_0515S3UP 515
QT8B_1203S3UP 123.3
QT8B_1205S3UP 125
QT8B_1209S3UP 129
QT8B_1212S3UP 1212
QT8B_1215S3UP 1215
QT8B_1505S3UP 155
QT8B_1515S3UP 1515
QT8B_2403S3UP 243.3
QT8B_2405S3UP 245
QT8B_2409S3UP 249
QT8B_2412S3UP 2412
QT8B_2415S3UP 2415
DetailsQT8C1_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•77%-40°C - +105°C

QT8C1_3UP

Download PDF

The QT8C1_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SMD 5/8 Pin Package (L x W x H) 12.70 x 7.60 x 6.25 mm
  • 3000VDC isolation
  • Efficiency up to 77%
  • Operating temperature range: -40°C℃~ +105°C
  • Isolation capacitance20pF
  • Internal SMD construction
  • Industry standard pinout
  • RoHS Compliance
  • Short circuit prtection (SCP)

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

DetailsQT8C1_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•77%-40°C - +105°C

QT8C1_3UP

Download PDF

The QT8C1_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SMD 8/8 Pin Package (L x W x H) 12.70 x 7.60 x 6.25 mm
  • 3000VDC isolation
  • Efficiency up to 77%
  • Operating temperature range: -40°C℃~ +105°C
  • Isolation capacitance20pF
  • Internal SMD construction
  • Industry standard pinout
  • RoHS Compliance
  • Short circuit prtection (SCP)

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



0.5 Watt DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details0.5S4E_3USIP4±10%3.3; 5; 12; 15; 24; 483.3; 5; 7.2; 9; 12; 15; 18; 24383% -40°C - +85°C

0.5S4E_3U

Download PDF

The 0.5S4E_3U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP 4 Package (L x W x H) 11.68 x 6.0 x 10.15 mm
  • Efficiency up to 83%
  • Small Footprint
  • Single Output Voltage
  • 3KVDC Isolation
  • Temperature Range: -40°C~+85°C
  • Industry Standard Pinout
  • UL94-V0 Package
  • No Heat sink Required
  • No External Component Required
  • RoHS Compliance

Field of application:

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5S4E_0303S3U 3.33.3
0.5S4E_0305S3U 3.35
0.5S4E_0307S3U 3.37.2
0.5S4E_0309S3U 3.39
0.5S4E_0312S3U 3.312
0.5S4E_0315S3U 3.315
0.5S4E_0318S3U 3.318
0.5S4E_0324S3U 3.324
0.5S4E_0503S3U 53.3
0.5S4E_0505S3U 55
0.5S4E_0507S3U 57.2
0.5S4E_0509S3U 59
0.5S4E_0512S3U 512
0.5S4E_0515S3U 515
0.5S4E_0518S3U 518
0.5S4E_0524S3U 524
0.5S4E_1203S3U 123.3
0.5S4E_1205S3U 125
0.5S4E_1207S3U 127.2
0.5S4E_1209S3U 129
0.5S4E_1212S3U 1212
0.5S4E_1215S3U 1215
0.5S4E_1218S3U 1218
0.5S4E_1224S3U 1224
0.5S4E_1503S3U 153.3
0.5S4E_1505S3U 155
0.5S4E_1507S3U 157.2
0.5S4E_1509S3U 159
0.5S4E_1512S3U 1512
0.5S4E_1515S3U 1515
0.5S4E_1518S3U 1518
0.5S4E_1524S3U 1524
0.5S4E_2403S3U 243.3
0.5S4E_2405S3U 245
0.5S4E_2407S3U 247.2
0.5S4E_2409S3U 249
0.5S4E_2412S3U 2412
0.5S4E_2415S3U 2415
0.5S4E_2418S3U 2418
0.5S4E_2424S3U 2424
0.5S4E_4803S3U 483.3
0.5S4E_4805S3U 485
0.5S4E_4807S3U 487.2
0.5S4E_4809S3U 489
0.5S4E_4812S3U 4812
0.5S4E_4815S3U 4815
0.5S4E_4818S3U 4818
0.5S4E_4824S3U 4824
Details0.5S4E_1USIP4±10%3.3; 5; 12; 15; 24; 483.3; 5; 7.2; 9; 12; 15; 18; 24179% -40°C - +85°C

0.5S4E_1U

Download PDF

The 0.5S4E_1U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP 4 Package (L x W x H) 11.68 x 6.0 x 10.15 mm
  • Efficiency up to 79%
  • Small Footprint
  • Single Output Voltage
  • 1KVDC Isolation
  • Temperature Range: -40°C~+85°C
  • Industry Standard Pinout
  • UL94-V0 Package
  • No Heat sink Required
  • No External Component Required
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5S4E_0303S1U 3.33.3
0.5S4E_0305S1U 3.35
0.5S4E_0307S1U 3.37.2
0.5S4E_0309S1U 3.39
0.5S4E_0312S1U 3.312
0.5S4E_0315S1U 3.315
0.5S4E_0318S1U 3.318
0.5S4E_0324S1U 3.324
0.5S4E_0503S1U 53.3
0.5S4E_0505S1U 55
0.5S4E_0507S1U 57.2
0.5S4E_0509S1U 59
0.5S4E_0512S1U 512
0.5S4E_0515S1U 515
0.5S4E_0518S1U 518
0.5S4E_0524S1U 524
0.5S4E_1203S1U 123.3
0.5S4E_1205S1U 125
0.5S4E_1207S1U 127.2
0.5S4E_1209S1U 129
0.5S4E_1212S1U 1212
0.5S4E_1215S1U 1215
0.5S4E_1218S1U 1218
0.5S4E_1224S1U 1224
0.5S4E_1503S1U 153.3
0.5S4E_1505S1U 155
0.5S4E_1507S1U 157.2
0.5S4E_1509S1U 159
0.5S4E_1512S1U 1512
0.5S4E_1515S1U 1515
0.5S4E_1518S1U 1518
0.5S4E_1524S1U 1524
0.5S4E_2403S1U 243.3
0.5S4E_2405S1U 245
0.5S4E_2407S1U 247.2
0.5S4E_2409S1U 249
0.5S4E_2412S1U 2412
0.5S4E_2415S1U 2415
0.5S4E_2418S1U 2418
0.5S4E_2424S1U 2424
0.5S4E_4803S1U 483.3
0.5S4E_4805S1U 485
0.5S4E_4807S1U 487.2
0.5S4E_4809S1U 489
0.5S4E_4812S1U 4812
0.5S4E_4815S1U 4815
0.5S4E_4818S1U 4818
0.5S4E_4824S1U 4824
Details0.5S4B_1.5UPSIP4±10%3.3; 5; 123.3; 5; 9; 12; 151•78%-40°C - +105°C

0.5S4B_1.5UP

Download PDF

The 0.5S4B_1.5UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP 4 Package (L x W x H) 11.48 x 6.00 x 10.00 mm
  • Efficiency up to 78%
  • Small Footprint
  • Single Output Voltage
  • 1.5KVDC Isolation
  • Temperature Range: -40°C~+105°C
  • Industry Standard Pinout
  • UL94-V0 Package
  • No Heat sink Required
  • No External Component Required
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5S4B_0303S1.5UP 3.33.3
0.5S4B_0305S1.5UP 3.35
0.5S4B_0503S1.5UP 53.3
0.5S4B_0505S1.5UP 55
0.5S4B_0509S1.5UP 59
0.5S4B_0512S1.5UP 512
0.5S4B_0515S1.5UP 515
0.5S4B_1205S1.5UP 125
0.5S4B_1209S1.5UP 129
0.5S4B_1212S1.5UP 1212
0.5S4B_1215S1.5UP 1215
Details0.5MD4A_1.5UDIP4 micro±10%3.3; 5; 123.3; 51.550%-40°C - +85°C

0.5MD4A_1.5U

Download PDF

The 0.5MD4A_1.5U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP4 Micro Size Package (L x W x H) 9.40 x 8,80 x 6,35 mm
  • 1500 VDC Isolation
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance
           Field of application:
  • Purely digital circuits
  • Low frequency analog circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details0.5D8E_1UDIP8±10%3.3; 5; 12; 15; 243.3; 5; 7,2; 9; 12; 15; 18; 241 77%-40°C - +85°C

0.5D8E_1U

Download PDF

The 0.5D8E_1U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP8 Package (L x W x H) 12.7 x 10,16 x 6,85 mm
  • 1 KVDC Isolation
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5D8E_0303S1U 3.33.3
0.5D8E_0305S1U 3.35
0.5D8E_0307S1U 3.37.2
0.5D8E_0309S1U 3.39
0.5D8E_0312S1U 3.312
0.5D8E_0315S1U 3.315
0.5D8E_0318S1U 3.318
0.5D8E_0324S1U 3.324
0.5D8E_0503S1U 53.3
0.5D8E_0505S1U 55
0.5D8E_0507S1U 57.2
0.5D8E_0509S1U 59
0.5D8E_0512S1U 512
0.5D8E_0515S1U 515
0.5D8E_0518S1U 518
0.5D8E_0524S1U 524
0.5D8E_1203S1U 123.3
0.5D8E_1205S1U 125
0.5D8E_1207S1U 127.2
0.5D8E_1209S1U 129
0.5D8E_1212S1U 1212
0.5D8E_1215S1U 1215
0.5D8E_1218S1U 1218
0.5D8E_1224S1U 1224
0.5D8E_1503S1U 153.3
0.5D8E_1505S1U 155
0.5D8E_1507S1U 157.2
0.5D8E_1509S1U 159
0.5D8E_1512S1U 1512
0.5D8E_1515S1U 1515
0.5D8E_1518S1U 1518
0.5D8E_1524S1U 1524
0.5D8E_2403S1U 243.3
0.5D8E_2405S1U 245
0.5D8E_2407S1U 247.2
0.5D8E_2409S1U 249
0.5D8E_2412S1U 2412
0.5D8E_2415S1U 2415
0.5D8E_2418S1U 2418
0.5D8E_2424S1U 2424
Details0.5D8B_1.5UPDIP83.3; 5; 123.3; 5; 9; 12; 151.5•78% -40°C - +105°C

0.5D8B_1.5UP

Download PDF

The 0.5D8B_1.5UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP8 Package (L x W x H) 12.7 x 10,16 x 6,85 mm
  • 1.5 KVDC Isolation
  • Temperature Range: -40°C ~ +105°C
  • Short Circuit Protection [SCP]
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5D8B_0303S1.5UP 3.33.3
0.5D8B_0305S1.5UP 3.35
0.5D8B_0503S1.5UP 53.3
0.5D8B_0505S1.5UP 55
0.5D8B_0509S1.5UP 59
0.5D8B_0512S1.5UP 512
0.5D8B_0515S1.5UP 515
0.5D8B_1205S1.5UP 125
0.5D8B_1209S1.5UP 129
0.5D8B_1212S1.5UP 1212
0.5D8B_1215S1.5UP 1215
Details0.5D8E_3UDIP8±10%3.3; 5; 12; 153.3; 5; 7,2; 9; 12; 15; 18; 241 77%-40°C - +85°C

0.5D8E_3U

Download PDF

The 0.5D8E_3U series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP8 Package (L x W x H) 12.7 x 10,16 x 6,85 mm
  • 3 KVDC Isolation
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5D8E_0303S3U 3.33.3
0.5D8E_0305S3U 3.35
0.5D8E_0307S3U 3.37.2
0.5D8E_0309S3U 3.39
0.5D8E_0312S3U 3.312
0.5D8E_0315S3U 3.315
0.5D8E_0318S3U 3.318
0.5D8E_0324S3U 3.324
0.5D8E_0503S3U 53.3
0.5D8E_0505S3U 55
0.5D8E_0507S3U 57.2
0.5D8E_0509S3U 59
0.5D8E_0512S3U 512
0.5D8E_0515S3U 515
0.5D8E_0518S3U 518
0.5D8E_0524S3U 524
0.5D8E_1203S3U 123.3
0.5D8E_1205S3U 125
0.5D8E_1207S3U 127.2
0.5D8E_1209S3U 129
0.5D8E_1212S3U 1212
0.5D8E_1215S3U 1215
0.5D8E_1218S3U 1218
0.5D8E_1224S3U 1224
0.5D8E_1503S3U 153.3
0.5D8E_1505S3U 155
0.5D8E_1507S3U 157.2
0.5D8E_1509S3U 159
0.5D8E_1512S3U 1512
0.5D8E_1515S3U 1515
0.5D8E_1518S3U 1518
0.5D8E_1524S3U 1524
0.5D8E_2403S3U 243.3
0.5D8E_2405S3U 245
0.5D8E_2407S3U 247.2
0.5D8E_2409S3U 249
0.5D8E_2412S3U 2412
0.5D8E_2415S3U 2415
0.5D8E_2418S3U 2418
0.5D8E_2424S3U 2424
Details0.5S7B_3UPSIP7±10%3.3; 5; 12; 153.3; 5; 9; 12; 15; 24; ±5 ±9; ±12; ±153•83%-40°C - +105°C

0.5S7B_3UP

Download PDF

The 0.5S7B_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 Package (L x W x H) 19.5 x 6.0 x 10.0 mm
  • 3 KVDC Isolation
  • Short circuit Protection (SCP)
  • Temperature Range: -40°C ~ +105°C
  • Power sharing on dual output
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5S7B_0303S3UP 3.33.3
0.5S7B_0305S3UP 3.35
0.5S7B_0505D3UP 55
0.5S7B_0505S3UP 55
0.5S7B_0509D3UP 59
0.5S7B_0509S3UP 59
0.5S7B_0512D3UP 512
0.5S7B_0512S3UP 512
0.5S7B_0515D3UP 515
0.5S7B_0515S3UP 515
0.5S7B_0524S3UP 524
0.5S7B_1205D3UP 125
0.5S7B_1205S3UP 125
0.5S7B_1209D3UP 129
0.5S7B_1209S3UP 129
0.5S7B_1212D3UP 1212
0.5S7B_1212S3UP 1212
0.5S7B_1215D3UP 1215
0.5S7B_1215S3UP 1215
0.5S7B_1505D3UP 155
0.5S7B_1505S3UP 155
0.5S7B_1512D3UP 1512
0.5S7B_1512S3UP 1512
0.5S7B_1515D3UP 1515
0.5S7B_1515S3UP 1515
Details0.5D14B_3UPDIP14±10%3.3; 5; 123.3; 5; 9; 12; 15; ±5 ±9; ±12; ±153•80%-40°C - +105°C

0.5D14B_3UP

Download PDF

The 0.5D14B_3UP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP14 Package (L x W x H) 19.5 x 9,8 x 6,8 mm
  • 3 KVDC Isolation
  • Short circuit Protection (SCP)
  • Temperature Range: -40°C ~ +105°C
  • Power sharing on dual output
  • No Heatsink Required
  • Internal SMD Construction
  • No External Component Required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5D14B_0303S3UP 3.33.3
0.5D14B_0305S3UP 3.35
0.5D14B_0505D3UP 55
0.5D14B_0505S3UP 55
0.5D14B_0509D3UP 59
0.5D14B_0509S3UP 59
0.5D14B_0512D3UP 512
0.5D14B_0512S3UP 512
0.5D14B_0515D3UP 515
0.5D14B_0515S3UP 515
0.5D14B_1205D3UP 125
0.5D14B_1205S3UP 125
0.5D14B_1209D3UP 129
0.5D14B_1209S3UP 129
0.5D14B_1212D3UP 1212
0.5D14B_1212S3UP 1212
0.5D14B_1215D3UP 1215
0.5D14B_1215S3UP 1215
Details0.5T8A2_1.5UPSMD8/5±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 241.5•85% -40°C - +105°C

0.5T8A2_1.5UP

Download PDF

0.5T8A_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.5W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8 Package (L x W x H) 13.7 x 11.0 x 7,00 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +85°C
  • Efficiency up to 76%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

The internal SMD construction with lead frame technology makes it possible to offer a product with high performance, these converters are qualified for the higher temperatures requested by lead-free reflow solder processes, especially for automated SMD production lines.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details0.5T8A2_3UPSMD8/5±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 243•85% -40°C - +105°C

0.5T8A2_3UP

Download PDF

0.5T8A_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.5W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8 Package (L x W x H) 13.7 x 11.0 x 7,00 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +85°C
  • Efficiency up to 76%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

The internal SMD construction with lead frame technology makes it possible to offer a product with high performance, these converters are qualified for the higher temperatures requested by lead-free reflow solder processes, especially for automated SMD production lines.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details0.5T8A_3UPSMD8±10%3.3; 5; 12; 15; 243.3; 5; 9; 12; 153•78% -40°C - +105°C

0.5T8A_3UP

Download PDF

0.5T8A_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.5W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8 Package (L x W x H) 13.7 x 11.0 x 7,00 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +85°C
  • Efficiency up to 76%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

The internal SMD construction with lead frame technology makes it possible to offer a product with high performance, these converters are qualified for the higher temperatures requested by lead-free reflow solder processes, especially for automated SMD production lines.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

0.5T8A_0303S3UP 3.33.3
0.5T8A_0305S3UP 3.35
0.5T8A_0309S3UP 3.39
0.5T8A_0312S3UP 3.312
0.5T8A_0315S3UP 3.315
0.5T8A_0503S3UP 53.3
0.5T8A_0505S3UP 55
0.5T8A_0509S3UP 59
0.5T8A_0512S3UP 512
0.5T8A_0515S3UP 515
0.5T8A_1205S3UP 125
0.5T8A_1209S3UP 129
0.5T8A_1212S3UP 1212
0.5T8A_1215S3UP 1215
Details0.5T8B2_1.5UPSMD8/8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 241.5•85% -40°C - +105°C

0.5T8B2_1.5UP

Download PDF

0.5T8A_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.5W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8 Package (L x W x H) 13.7 x 11.0 x 7,00 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +85°C
  • Efficiency up to 76%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

The internal SMD construction with lead frame technology makes it possible to offer a product with high performance, these converters are qualified for the higher temperatures requested by lead-free reflow solder processes, especially for automated SMD production lines.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details0.5T8B2_3UPSMD8/8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 243•85% -40°C - +105°C

0.5T8B2_3UP

Download PDF

0.5T8A_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.5W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8 Package (L x W x H) 13.7 x 11.0 x 7,00 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +85°C
  • Efficiency up to 76%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

The internal SMD construction with lead frame technology makes it possible to offer a product with high performance, these converters are qualified for the higher temperatures requested by lead-free reflow solder processes, especially for automated SMD production lines.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details0.5T8C2_1.5UPSMD8/5 [R]±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 241.5•85% -40°C - +105°C

0.5T8C2_1.5UP

Download PDF

0.5T8A_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.5W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8 Package (L x W x H) 13.7 x 11.0 x 7,00 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +85°C
  • Efficiency up to 76%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

The internal SMD construction with lead frame technology makes it possible to offer a product with high performance, these converters are qualified for the higher temperatures requested by lead-free reflow solder processes, especially for automated SMD production lines.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details0.5T8C2_3UPSMD8/5 [R]±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 243•85% -40°C - +105°C

0.5T8C2_3UP

Download PDF

0.5T8A_3UP SMD8 case series. Miniature surface mounted DC/DC Converters are a 0.5W low power and high efficiency DC/DC converters in SMD package, are an ideal and economical solution for many applications where noise reduction, voltage isolation, voltage conversion in distributed power systems is required.

Features:

  • SMD 8 Package (L x W x H) 13.7 x 11.0 x 7,00 mm
  • RoHS compliant
  • 3000VDC isolation
  • Operating temperature range: -40°C℃~ +85°C
  • Efficiency up to 76%
  • Short circuit protection (SCP)
  • Internal SMD construction
  • No external component required
  • Industry standard pinout

The internal SMD construction with lead frame technology makes it possible to offer a product with high performance, these converters are qualified for the higher temperatures requested by lead-free reflow solder processes, especially for automated SMD production lines.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



0.75 Watt DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details0.75S4A1_1.5RPSIP4±10%5; 12; 243.3; 5; 9; 12; 153••74% -40°C - +85°CUL62368

0.75S4A1_1.5RP

Download PDF

The 0.75S4A_3RP series is specially designed for applications where a group of

polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP4 Package (L x W x H) 11.6 x 6.0 x 10.16 mm
  • Regulated
  • 3 KVDC Isolation
  • Continuous Short circuit Protection (SCP)
  • UL-62368 approved
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No-load input current as low as 5mA
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details0.75T8A1_1.5RPSMD8±10%5; 12; 243.3; 5; 121.5••74% -40°C - +85°CUL62368

0.75T8A1_1.5RP

Download PDF

The 0.75T8A_1.5RP series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD8 Package (L x W x H) 13.2 x 8.5 (11.4) x 7.25mm
  • Regulated
  • 1500 VDC Isolation
  • Continuous Short circuit Protection (SCP)
  • UL-62368 approval
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • Internal SMD Construction
  • No-load input current as low as 5mA
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



1 Watt DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details1S4A1_1.5UPSIP4±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 241.5•80% -40°C - +105°CUL62368

1S4A1_1.5UP

Download PDF

The 1S4AE_1.5UP Series are designed for applications where isolated output is required from a distributed power system.

Features:

  • Miniature SIP 4 Package (L x W x H) 11.60 x 6.00 x 10.16 mm
  • Efficiency up to 85%
  • Single Output Voltage 1500VDC Isolation
  • Temperature Range: -40°C~+105°C
  • Industry Standard Pinout
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No External Component
  • Required
  • UL62368
  • PCB Mounting

Field of application:

  • digital circuits
  • low frequency analog circuits
  • relay drive circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S4A2_1.5UPSIP4±10%3.3; 5; 12; 15; 243.3; 5; 12; 15; 241.5•80% -40°C - +105°C

1S4A2_1.5UP

Download PDF

The 1S4AE_1.5UP Series are designed for applications where isolated output is required from a distributed power system.

Features:

  • Miniature SIP 4 Package (L x W x H) 11.60 x 6.00 x 10.16 mm
  • Efficiency up to 85%
  • Single Output Voltage 1500VDC Isolation
  • Temperature Range: -40°C~+105°C
  • Industry Standard Pinout
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No External Component
  • Required
  • UL62368
  • PCB Mounting

Field of application:

  • digital circuits
  • low frequency analog circuits
  • relay drive circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S4A1_3UPSIP4±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 243•80% -40°C - +105°CUL62368

1S4A1_3UP

Download PDF

The 1S4AE_3UP Series are designed for applications where isolated output is required from a distributed power system.

Features:

  • Miniature SIP 4 Package (L x W x H) 11.60 x 6.00 x 10.16 mm
  • Efficiency up to 85%
  • Single Output Voltage 3000VDC Isolation
  • Temperature Range: -40°C~+105°C
  • Industry Standard Pinout
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No External Component
  • Required
  • UL62368
  • PCB Mounting

Field of application:

  • digital circuits
  • low frequency analog circuits
  • relay drive circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S4A2_3UPSIP4±10%3.3; 5; 12; 15; 243.3; 5; 12; 15; 243•80% -40°C - +105°C

1S4A2_3UP

Download PDF

The 1S4AE_1.5UP Series are designed for applications where isolated output is required from a distributed power system.

Features:

  • Miniature SIP 4 Package (L x W x H) 11.60 x 6.00 x 10.16 mm
  • Efficiency up to 85%
  • Single Output Voltage 1500VDC Isolation
  • Temperature Range: -40°C~+105°C
  • Industry Standard Pinout
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No External Component
  • Required
  • UL62368
  • PCB Mounting

Field of application:

  • digital circuits
  • low frequency analog circuits
  • relay drive circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1MS4A1_1.5UPSIP4 micro±10%3.3; 5; 9; 12; 15; 243,3; 5; 9; 12; 15; 24; ±3,3; ±5;  ±9; ±12; ±15; ±241.5•87% -40°C - +105°C

1MS4A1_1.5UP

Download PDF

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1MS4A_3UPSIP4 micro±10%3.3; 5; 12; 243; 5; 9; 12; 153•81% -40°C - +85°C

1MS4A_3UP

Download PDF

The 1MS4A_3UP Series are specially designed for applications where a single power supply is isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Super miniature SIP4 Package (L x W x H) 11.48 x 6.0 x 7.46 mm
  • 3KVDC Isolation
  • Continuous Short Circuit Protection
  • Efficiency up to 81%
  • Temperature Range: -40°C to +85°C
  • UL94-V0 Package
  • No Heat sink Required
  • No external component required
  • Industry standard pinout
  • Internal SMD construction
  • RoHS Compliance

Field of application:

  • digital circuits
  • low frequency analog circuits
  • relay drive circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1MS4A_0303S3UP 3.33.3
1MS4A_0305S3UP 3.35
1MS4A_0309S3UP 3.39
1MS4A_0503S3UP 53.3
1MS4A_0505S3UP 55
1MS4A_0509S3UP 59
1MS4A_0512S3UP 512
1MS4A_0515S3UP 515
1MS4A_1205S3UP 125
1MS4A_1209S3UP 129
1MS4A_1212S3UP 1212
1MS4A_1215S3UP 1215
1MS4A_2405S3UP 245
Details1D8A1_1.5UPDIP8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 241.5•87%-40°C - +105°C

1D8A1_1.5UP

Download PDF

The 1D8AE_1.5UP Series are designed for applications where isolated output is required from a distributed power system.

Features:

  • DIP8 Package (L x W x H) 12.7 x 10.0 x 8.2 mm
  • Efficiency up to 82%
  • Single Output Voltage
  • 1500VDC Isolation
  • Temperature Range: -40°C~+105°C
  • Industry Standard Pinout
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No External Component Required
  • PCB Mounting

Field of application:

  • digital circuits
  • low frequency analog circuits
  • relay drive circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1D8A1_3UPDIP8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 243•87%-40°C - +105°CUL62368

1D8A1_3UP

Download PDF

The 1D8AE_3UP Series are designed for applications where isolated output is required from a distributed power system.

Features:

  • DIP8 Package (L x W x H) 12.7 x 10.0 x 8.2 mm
  • Efficiency up to 82%
  • Single Output Voltage
  • 3000VDC Isolation
  • Temperature Range: -40°C~+105°C
  • Industry Standard Pinout
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No External Component Required
  • PCB Mounting

Field of application:

  • digital circuits
  • low frequency analog circuits
  • relay drive circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1MD6A_1.5UPDIP4 micro±10%3.3; 53.3; 51.5•82%-40°C - +105°C

1MD6A_1.5UP

Download PDF

The 1MD6A_1.5UP series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP 6 Micro Package (L x W  x H) 8.5 x 8,5 x 7.0 mm
  • High Efficiency up to 82%
  • 1500 VDC Isolation
  • Short-Circuit-Protection (SCP)
  • Temperature Range: -40°C ~ +105°C
  • No Heatsink Required
  • No External Component Required
  • Internal SMD Construction
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1MD8A_3UPDIP8 micro±10%3.3; 5; 9; 12; 243.3; 5; 9; 12; 153•81% -40°C - +85°C

1MD8A_3UP

Download PDF

The 1MD8A_3UP series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP 8 Micro Package (L x W  x H) 11.5 x 9,8 x 5.4 mm
  • High Efficiency up to 81%
  • 3000VDC Isolation
  • Short-Circuit-Protection (SCP)
  • Temperature Range: -40°C ~ +85°C
  • No Heatsink Required
  • No External Component Required
  • Internal SMD Construction
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1MD8A_0303S3UP 3.33.3
1MD8A_0305S3UP 3.35
1MD8A_0309S3UP 3.39
1MD8A_0503S3UP 53.3
1MD8A_0505S3UP 55
1MD8A_0509S3UP 59
1MD8A_0512S3UP 512
1MD8A_0515S3UP 515
1MD8A_1205S3UP 125
1MD8A_1209S3UP 129
1MD8A_1212S3UP 1212
1MD8A_1215S3UP 1215
1MD8A_2403S3UP 243.3
1MD8A_2405S3UP 245
1MD8A_2412S3UP 2412
1MD8A_2415S3UP 2415
Details1D14A_DS3UPDIP14±10%5; 123.3; 5; 9; 12; 153•80%-40°C - +85°C

1D14A_DS3UP

Download PDF

The 1D14A_DS3UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP14 Package (L x W x H) 19.5 x 9.8 x 6.8 mm
  • Dual seperate output voltage
  • Efficiency up to 80%
  • 3000VDC Isolation Voltage between Vin & Vout
  • 3000VDC Isolation Voltage between Vout1 & Vout2
  • Internal SMD Construction
  • Operating Temperature: -40°C to +85°C
  • Industry Standard Pinout
  • RoHS Compliance
  • Design  meet UL60950-1 (approval pending)

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1D14A_050503DS3UP 55/3
1D14A_050505DS3UP 55/5
1D14A_050509DS3UP 55/9
1D14A_050512DS3UP 55/12
1D14A_050515DS3UP 55/15
1D14A_120505DS3UP 125/5
1D14A_120509DS3UP 125/9
1D14A_120512DS3UP 125/12
1D14A_120515DS3UP 125/15
Details1D14B2_1.5UPDIP14±10%5;12; 24±5; ±9; ±12; ±15; ±241.5•86%-40°C - +105°C

1D14B2_1.5UP

Download PDF

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1D14B_3RPDIP14±10%53,3; +/-53••70%-40°C - +85°C

1D14B_3RP

Download PDF

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S7AE_DS1USIP7±10%5; 12; 24Vout1: 3.3; 5; 7,2; 9; 12; 15
Vout2: 3.3; 5; 7,2; 9; 12; 15
180%-40°C - +85°C

1S7AE_DS1U

Download PDF

The 1S7AE_DS1U Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 Package (L x W x H) 19.5 x 6.0 x 9.5 mm
  • Dual seperate output voltage
  • Efficiency up to 80%
  • 1000VDC Isolation Voltage between Vin & Vout
  • 1000VDC Isolation Voltage between Vout1 & Vout2
  • Internal SMD Construction
  • Operating Temperature: -40°C to +85°C
  • Industry Standard Pinout
  • RoHS Compliance
  • Design  meet UL60950-1

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S7AE_050503DS1U 55/3
1S7AE_050505DS1U 55/5
1S7AE_050507DS1U 55/7
1S7AE_050509DS1U 55/9
1S7AE_050512DS1U 55/12
1S7AE_050515DS1U 55/15
1S7AE_050707DS1U 57.2/7
1S7AE_050909DS1U 59/9
1S7AE_051212DS1U 512/12
1S7AE_051515DS1U 515/15
1S7AE_120503DS1U 125/3
1S7AE_120505DS1U 125/5
1S7AE_120507DS1U 125/7
1S7AE_120509DS1U 125/9
1S7AE_120512DS1U 125/12
1S7AE_120515DS1U 125/15
1S7AE_120707DS1U 127.2/7
1S7AE_120909DS1U 129/9
1S7AE_121212DS1U 1212/12
1S7AE_121515DS1U 1215/15
1S7AE_240503DS1U 245/3
1S7AE_240505DS1U 245/5
1S7AE_240507DS1U 245/7
1S7AE_240509DS1U 245/9
1S7AE_240512DS1U 245/12
1S7AE_240515DS1U 245/15
1S7AE_240707DS1U 247.2/7
1S7AE_240909DS1U 249/9
1S7AE_241212DS1U 2412/12
1S7AE_241515DS1U 2415/15
Details1S7A_DS3UPSIP7±10%5; 9; 12; 15; 24Vout1: 3.3; 5; 9; 12; 15; 24
Vout2: 3.3; 5; 9; 12; 15; 24
3•80%-40°C - +85°C

1S7A_DS3UP

Download PDF

The 1S7A_DS3UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 Package (L x W x H) 19.5 x 6.0 x 10.0 mm
  • Dual seperate output voltage
  • Short circuit protection (SCP)
  • Efficiency up to 80%
  • 3kVDC Isolation Voltage between Vin & Vout
  • 3kVDC Isolation Voltage between Vout1 & Vout2
  • Internal SMD Construction
  • Operating Temperature: -40°C to +85°C
  • Industry Standard Pinout
  • RoHS Compliance
  • Design meet UL60950-1

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S7A_050503DS3UP 55/3
1S7A_050505DS3UP 55/5
1S7A_050509DS3UP 55/9
1S7A_050512DS3UP 55/12
1S7A_050515DS3UP 55/15
1S7A_120505DS3UP 125/5
1S7A_120509DS3UP 125/9
1S7A_120512DS3UP 125/12
1S7A_120515DS3UP 125/15
Details1S7A1_1.5UPSIP7±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 24; ±3.3; ±5; ±9; ±12; ±15; ±241.5•83%-40°C - +105°CUL62368

1S7A1_1.5UP

Download PDF

The 1S7A_1.5UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 Package (L x W x H) 19.5 x 6.0 x 9.3 mm
  • Efficiency up to 83%
  • Low Isolation Capacitance
  • 1500VDC Isolation Voltage
  • Internal SMD Construction
  • Operating Temperature: -40°C to +105°C
  • Industry Standard Pinout
  • RoHS Compliance
  • Short circuit protection (SCP)
  • Encapsulated SIP package

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S7B1_3UPSIP7±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 24; ±3.3; ±5; ±9; ±12; ±15; ±243•83%-40°C - +105°CUL62368

1S7B1_3UP

Download PDF

The 1S7B_3UP series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SIP7 package (L x W x H) 19.5 x 6.0 x 9.3 mm
  • Conversion efficiency high up to 81%
  • 3000VDC isolation voltage
  • Internal SMD construction
  • Operating temperature: -40°C to +105°C
  • Industry standard pinout
  • RoHS compliance
  • Short circuit Protection (SCP)
  • UL62368 approval

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S7B2_3UPSIP7±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±243•83%-40°C - +105°CUL62368

1S7B2_3UP

Download PDF

The 1S7B_3UP series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SIP7 package (L x W x H) 19.5 x 6.0 x 9.3 mm
  • Conversion efficiency high up to 81%
  • 3000VDC isolation voltage
  • Internal SMD construction
  • Operating temperature: -40°C to +105°C
  • Industry standard pinout
  • RoHS compliance
  • Short circuit Protection (SCP)
  • UL62368 approval

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S7B_4UPSIP7±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±244•80%-40°C - +105°C

1S7B_4UP

Download PDF

The 1S7B_4UP series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SIP7 package (L x W x H) 19.5 x 6.0 x 10.0 mm
  • Conversion efficiency high up to 80%
  • 4000VDC isolation voltage
  • Internal SMD construction
  • Operating temperature: -40°C to +105°C
  • Industry standard pinout
  • RoHS compliance
  • Short circuit Protection (SCP)

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S7B_0303S4UP 3.33.3
1S7B_0305S4UP 3.35
1S7B_0503S4UP 53.3
1S7B_0505D4UP 55
1S7B_0505S4UP 55
1S7B_0509D4UP 59
1S7B_0509S4UP 59
1S7B_0512D4UP 512
1S7B_0512S4UP 512
1S7B_0515D4UP 515
1S7B_0515S4UP 515
1S7B_0524S4UP 524
1S7B_0909S4UP 99
1S7B_0915S4UP 915
1S7B_1203S4UP 123.3
1S7B_1205D4UP 125
1S7B_1205S4UP 125
1S7B_1209D4UP 129
1S7B_1209S4UP 129
1S7B_1212D4UP 1212
1S7B_1212S4UP 1212
1S7B_1215D4UP 1215
1S7B_1215S4UP 1215
1S7B_1224S4UP 1224
1S7B_1505D4UP 155
1S7B_1505S4UP 155
1S7B_1509S4UP 159
1S7B_1512D4UP 1512
1S7B_1512S4UP 1512
1S7B_1515D4UP 1515
1S7B_1515S4UP 1515
Details1S7B_6USIP7±10%5; 9; 12; 15; 245; 9; 12; 15; 24; ±5;  ±9; ±12; ±15; ±24 680%-40°C - +85°C

1S7B_6U

Download PDF

The 1S7B_6U series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SIP7 package (L x W x H) 19.5 x 7.1 x 10.0 mm
  • Conversion efficiency high up to 82%
  • 6000VDC isolation voltage (protective separation insulation)
  • Internal SMD construction
  • Operating temperature: -40°C to +85°C
  • Industry standard pinout
  • RoHS compliance
  • No external component required
  • Design meet EN60950,UL60950-1 (approval pending)

Field Application:

  • High voltage collection circuit
  • IGBT FET circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S7B_0305D6U 3.35
1S7B_0305S6U 3.35
1S7B_0309D6U 3.39
1S7B_0309S6U 3.39
1S7B_0312D6U 3.312
1S7B_0312S6U 3.312
1S7B_0315D6U 3.315
1S7B_0315S6U 3.315
1S7B_0324D6U 3.324
1S7B_0324S6U 3.324
1S7B_0505D6U 55
1S7B_0505S6U 55
1S7B_0509D6U 59
1S7B_0509S6U 59
1S7B_0512D6U 512
1S7B_0512S6U 512
1S7B_0515D6U 515
1S7B_0515S6U 515
1S7B_0524D6U 524
1S7B_0524S6U 524
1S7B_0905D6U 95
1S7B_0905S6U 95
1S7B_0909D6U 99
1S7B_0909S6U 99
1S7B_0912D6U 912
1S7B_0912S6U 912
1S7B_0915D6U 915
1S7B_0915S6U 915
1S7B_0924D6U 924
1S7B_0924S6U 924
1S7B_1205D6U 125
1S7B_1205S6U 125
1S7B_1209D6U 129
1S7B_1209S6U 129
1S7B_1212D6U 1212
1S7B_1212S6U 1212
1S7B_1215D6U 1215
1S7B_1215S6U 1215
1S7B_1224D6U 1224
1S7B_1224S6U 1224
1S7B_1505D6U 155
1S7B_1505S6U 155
1S7B_1509D6U 159
1S7B_1509S6U 159
1S7B_1512D6U 1512
1S7B_1512S6U 1512
1S7B_1515D6U 1515
1S7B_1515S6U 1515
1S7B_1524D6U 1524
1S7B_1524S6U 1524
1S7B_2405D6U 245
1S7B_2405S6U 245
1S7B_2409D6U 249
1S7B_2409S6U 249
1S7B_2412D6U 2412
1S7B_2412S6U 2412
1S7B_2415D6U 2415
1S7B_2415S6U 2415
1S7B_2424D6U 2424
1S7B_2424S6U 2424
Details1S7B2_6UPSIP7±10%5; 12; 15; 243.3; 5; 9; 12; 15; ±3.3; ±5;  ±9; ±12; ±15 6•82% -40°C - +95°CUL62368

1S7B2_6UP

Download PDF

The 1S7B_6UP series meet reinforced insulation requirements. It is specially designed for applications which require compact size, high isolation, low isolation capacitor and low leakage current power.

Features:

  • SIP7 Package (L x W x H) 19.5 x 9.8 x 12.5 mm
  • Efficiency up to 81%
  • 4200VAC/6000VDC isolation
  • Reinforced insulation
  • The patient leakage current: max. 2μA
  • Industry standard pinout
  • No external component required
  • RoHS compliance
  • Short circuit protection (3sec)
  • Meets UL60950-1; EN60601-1
  • ANSI/AAMI ES60601-1 standards (Pending)
  • (1xMOPP/2xMOOP)

Field of application:

  • Medical collection and isolation
  • High voltage collection circuit
  • IGBTdriven circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S7BE_3RPSIP7±10%3.3; 5; 12; 243.3; 5; 7,2; 9; 12; 153••71%-40°C - +85°C

1S7BE_3RP

Download PDF

The 1S7BE_3RP Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Small Footprint SIP7 Package (L x W x H) 19.5 x 7,2 x 9.5 mm
  • 3000VDC Isolation
  • Regulated
  • Low Ripple
  • High EMC features
  • Temperature Range: -40°C ~ +85°C
  • No Heat Sink Required
  • No External Component Required
  • 1KVDC Isolation
  • Internal SMD construction
  • Continuous Short Circuit Protection (SCP)
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • low frequency analog circuits
  • data switching circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S7BE_0303S3RP 3.33.3
1S7BE_0305S3RP 3.35
1S7BE_0307S3RP 3.37.2
1S7BE_0309S3RP 3.39
1S7BE_0312S3RP 3.312
1S7BE_0315S3RP 3.315
1S7BE_0503S3RP 53.3
1S7BE_0505S3RP 55
1S7BE_0507S3RP 57.2
1S7BE_0509S3RP 59
1S7BE_0512S3RP 512
1S7BE_0515S3RP 515
1S7BE_1203S3RP 123.3
1S7BE_1205S3RP 125
1S7BE_1207S3RP 127.2
1S7BE_1209S3RP 129
1S7BE_1212S3RP 1212
1S7BE_1215S3RP 1215
1S7BE_2403S3RP 243.3
1S7BE_2405S3RP 245
1S7BE_2407S3RP 247.2
1S7BE_2409S3RP 249
1S7BE_2412S3RP 2412
1S7BE_2415S3RP 2415
Details1S10A1_3RPSIP10±10%5;12; 24±5; ±9; ±12; ±153••83% -40°C - +85°C

1S10A1_3RP

Download PDF

The 1S8W4_2 & 1S8W4_4 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Wide 4:1 Input Voltage Range
  • High Efficiency up to 81%
  • 1W Single and Dual outputs
  • I/O Isolation 2KVDC and 4KVDC
  • Operating Temperature Range: -40°C to +100°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T8B2_1.5UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 151.5•83%-40°C - +105°CUL62368

1T8B2_1.5UP

Download PDF

The 1T8B1_1.5UP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 8/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 1500VDC isolation
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T8B2_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•80%-40°C - +105°CUL62368

1T8B2_3UP

Download PDF

The 1T8A1_3RP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 5/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 3000VDC isolation
  • Regulated output
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T8C2_1.5UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 151.5•80%-40°C - +105°CUL62368

1T8C2_1.5UP

Download PDF

The 1T8A1_3RP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 5/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 3000VDC isolation
  • Regulated output
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T8C2_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•80%-40°C - +105°CUL62368

1T8C2_3UP

Download PDF

The 1T8A1_3RP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 5/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 3000VDC isolation
  • Regulated output
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T8D2_1.5UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 151.5•80%-40°C - +105°CUL62368

1T8D2_1.5UP

Download PDF

The 1T8A1_3RP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 5/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 3000VDC isolation
  • Regulated output
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T8A3_1.5UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 151.5•83%-40°C - +105°C

1T8A3_1.5UP

Download PDF

The 1T8A1_1.5UP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 5/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 1500VDC isolation
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S7WA_3RPSIP72:14.5-9; 9-18; 18-365; 9; 12; 15; 243••83%-40°C - +95°C

1S7WA_3RP

Download PDF

The 1S7WA_3RP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 package (L x W x H) 19.5 x 7.1 x 10.0 mm
  • 2:1 Wide input voltage range
  • Standard Pinout
  • Pin connection Vin 1 & 2; Vout 4 & 6
  • 3KV Isolation
  • High Efficiency up to 80%
  • Regulated output types
  • Internal SMD construction
  • Operating temperature: -40°C to +85°C
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No external component required
  • Industry standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S7WA_0505S3RP 55
1S7WA_0509S3RP 59
1S7WA_0512S3RP 512
1S7WA_0515S3RP 515
1S7WA_0524S3RP 524
1S7WA_1205S3RP 125
1S7WA_1209S3RP 129
1S7WA_1212S3RP 1212
1S7WA_1215S3RP 1215
1S7WA_1224S3RP 1224
1S7WA_2405S3RP 245
1S7WA_2409S3RP 249
1S7WA_2412S3RP 2412
1S7WA_2415S3RP 2415
1S7WA_2424S3RP 2424
Details1S7WB_3RPSIP72:14.5-9; 9-18; 18-365; 9; 12; 15; 243••83%-40°C - +95°C

1S7WB_3RP

Download PDF

The 1S7WB_3RP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 package (L x W x H) 19.5 x 7.1 x 10.0 mm
  • 2:1 Wide input voltage range
  • Standard Pinout
  • Pin connection Vin 1 & 2; Vout 5 & 7
  • 3KV Isolation
  • High Efficiency up to 80%
  • Regulated output types
  • Internal SMD construction
  • Operating temperature: -40°C to +85°C
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No external component required
  • Industry standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S7WB_0505S3RP 55
1S7WB_0509S3RP 59
1S7WB_0512S3RP 512
1S7WB_0515S3RP 515
1S7WB_0524S3RP 524
1S7WB_1205S3RP 125
1S7WB_1209S3RP 129
1S7WB_1212S3RP 1212
1S7WB_1215S3RP 1215
1S7WB_1224S3RP 1224
1S7WB_2405S3RP 245
1S7WB_2409S3RP 249
1S7WB_2412S3RP 2412
1S7WB_2415S3RP 2415
1S7WB_2424S3RP 2424
Details1S6W_1.5RPSIP62:14.5-9; 9-18; 18-36; 36-753.3; 5; 9; 12; 15; ±5; ±9; ±12; ±151.5••83% -40°C - +85°C

1S6W_1.5RP

Download PDF

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S6W_0505S1.5RP 55
1S6W_0512D1.5RP 512
1S6W_0512S1.5RP 512
1S6W_0515D1.5RP 515
1S6W_0515S1.5RP 515
1S6W_0524S1.5RP 524
1S6W_1205S1.5RP 125
1S6W_1212D1.5RP 1212
1S6W_1212S1.5RP 1212
1S6W_1215D1.5RP 1215
1S6W_1215S1.5RP 1215
1S6W_1224S1.5RP 1224
1S6W_2405S1.5RP 245
1S6W_2412D1.5RP 2412
1S6W_2412S1.5RP 2412
1S6W_2415D1.5RP 2415
1S6W_2415S1.5RP 2415
1S6W_2424S1.5RP 2424
1S6W_4805S1.5RP 485
1S6W_4812D1.5RP 4812
1S6W_4815D1.5RP 4815
1S6W_4815S1.5RP 4815
1S6W_4824S1.5RP 4824
Details1S8W_1.5RPRSIP82:14.5-9; 9-18; 18-36; 36-755; 9; 12; 15; 24; ±5; ±12; ±151.5••79%-40°C - +85°C

1S8W_1.5RPR

Download PDF

The 1S8W_1.5RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. For these DC-DC converters, You can reduce the design point of failure and save the development of micro power supply‘s manpower, material and time costs, also better ensure product quality stability, protect safety and reliability of the end of products.

Features:

  • SIP8 package (L x W x H) 22.0 x 9.5 x 12.0 mm
  • 2:1 wide input voltage range
  • 1.5KVDC isolation
  • Short circuit protection (automatic recovery)
  • External On/Off control
  • High Power Density
  • Operating Temperature: -40°C to +85°C
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S8W_3RPRSIP82:14.5-9; 9-18; 18-36; 36-753.3; 5; 9; 12; 15; ±5; ±12; ±153••81%-40°C - +85°C

1S8W_3RPR

Download PDF

The 1S8W_S3 & 1S8W_D3 Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 22.0 x 9.5 x 12.0 mm
  • 2:1 wide input voltage range
  • 3 KVDC isolation
  • Short circuit protection (SCP (automatic recovery)
  • External On/Off control
  • High Power Density
  • Operating Temperature: -40°C to +85°C
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1S8W_2RPSIP82:14.5-9; 9-18; 18-363.3; 5; 9; 12; 15; 24; ±3.3; ±5; ±12; ±152; 4; 5.2••81%-40°C - +100°C

1S8W_2RP

Download PDF

The 1S8W_2 & 1S8W_4 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Wide 2:1 Input Voltage Range
  • High Efficiency up to 81%
  • 1W Single and Dual outputs
  • I/O Isolation 2KVDC and 4KVDC
  • Operating Temperature Range: -40°C to +100°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S8W_0503D2RP 53.3
1S8W_0503S2RP 53.3
1S8W_0505D2RP 55
1S8W_0505S2RP 55
1S8W_0509D2RP 59
1S8W_0509S2RP 59
1S8W_0512D2RP 512
1S8W_0512S2RP 512
1S8W_0515D2RP 515
1S8W_0515S2RP 515
1S8W_1203D2RP 123.3
1S8W_1203S2RP 123.3
1S8W_1205D2RP 125
1S8W_1205S2RP 125
1S8W_1209D2RP 129
1S8W_1209S2RP 129
1S8W_1212D2RP 1212
1S8W_1212S2RP 1212
1S8W_1215D2RP 1215
1S8W_1215S2RP 1215
1S8W_2403D2RP 243.3
1S8W_2403S2RP 243.3
1S8W_2405D2RP 245
1S8W_2405S2RP 245
1S8W_2409D2RP 249
1S8W_2409S2RP 249
1S8W_2412D2RP 2412
1S8W_2412S2RP 2412
1S8W_2415D2RP 2415
1S8W_2415S2RP 2415
1S8W_4803D2RP 483.3
1S8W_4803S2RP 483.3
1S8W_4805D2RP 485
1S8W_4805S2RP 485
1S8W_4809D2RP 489
1S8W_4809S2RP 489
1S8W_4812D2RP 4812
1S8W_4812S2RP 4812
1S8W_4815D2RP 4815
1S8W_4815S2RP 4815
Details1S8W4_2RPSIP84:14.5-18; 9-36; 18-753.3; 5; 9; 12; 15; 24; ±3.3; ±5; ±12; ±152 & 4••81%-40°C - +100°C

1S8W4_2RP

Download PDF

The 1S8W4_2 & 1S8W4_4 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Wide 4:1 Input Voltage Range
  • High Efficiency up to 81%
  • 1W Single and Dual outputs
  • I/O Isolation 2KVDC and 4KVDC
  • Operating Temperature Range: -40°C to +100°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1S8W4_0503D2RP 53.3
1S8W4_0503S2RP 53.3
1S8W4_0505D2RP 55
1S8W4_0505S2RP 55
1S8W4_0509D2RP 59
1S8W4_0509S2RP 59
1S8W4_0512D2RP 512
1S8W4_0512S2RP 512
1S8W4_0515D2RP 515
1S8W4_0515S2RP 515
1S8W4_1203D2RP 123.3
1S8W4_1203S2RP 123.3
1S8W4_1205D2RP 125
1S8W4_1205S2RP 125
1S8W4_1209D2RP 129
1S8W4_1209S2RP 129
1S8W4_1212D2RP 1212
1S8W4_1212S2RP 1212
1S8W4_1215D2RP 1215
1S8W4_1215S2RP 1215
1S8W4_2403D2RP 243.3
1S8W4_2403S2RP 243.3
1S8W4_2405D2RP 245
1S8W4_2405S2RP 245
1S8W4_2409D2RP 249
1S8W4_2409S2RP 249
1S8W4_2412D2RP 2412
1S8W4_2412S2RP 2412
1S8W4_2415D2RP 2415
1S8W4_2415S2RP 2415
1S8W4_4803D2RP 483.3
1S8W4_4803S2RP 483.3
1S8W4_4805D2RP 485
1S8W4_4805S2RP 485
1S8W4_4809D2RP 489
1S8W4_4809S2RP 489
1S8W4_4812D2RP 4812
1S8W4_4812S2RP 4812
1S8W4_4815D2RP 4815
1S8W4_4815S2RP 4815
Details1T8A2_1.5UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 151.5•83%-40°C - +105°CUL62368

1T8A2_1.5UP

Download PDF

The 1T8A1_1.5UP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 5/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 1500VDC isolation
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T8A2_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•85%-40°C - +105°CUL62368

1T8A2_3UP

Download PDF

The 1T8A1_3RP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 5/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 3000VDC isolation
  • Regulated output
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T8A3_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•85%-40°C - +105°C

1T8A3_3UP

Download PDF

The 1T8A1_3RP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD 5/8 Pin Package (L x W x H) 13.20 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 3000VDC isolation
  • Regulated output
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • UL62368 approved

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T10A2_1.5UPSMD10±10%3.3; 5; 9; 12; 15; 24±3.3; ±5;  ±9; ±12; ±15; ±241.5•82%-40°C - +105°CUL62368

1T10A2_1.5UP

Download PDF

The 1T10A1_1.5UP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD10 Package (L x W x H) 15.24 x 11.4 x 7.25 mm
  • High efficiency up to 82%
  • 1500VDC isolation
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)

Field of application:

  • preceding-stage interference isolation condition
  • ground-interference canceled condition
  • digit circuit condition
  • Voltage-isolation converting condition
  • normal low-frequency artificial circuit condition
  • relay drive circuit condition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T10A3_1.5UPSMD10±10%±5;  ±9; ±12; ±15±5;  ±9; ±12; ±151.5•82%-40°C - +105°CUL62368

1T10A3_1.5UP

Download PDF

The 1T10A1_1.5UP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD10 Package (L x W x H) 15.24 x 11.4 x 7.25 mm
  • High efficiency up to 82%
  • 1500VDC isolation
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)

Field of application:

  • preceding-stage interference isolation condition
  • ground-interference canceled condition
  • digit circuit condition
  • Voltage-isolation converting condition
  • normal low-frequency artificial circuit condition
  • relay drive circuit condition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T10A2_3UPSMD10±10%3.3; 5; 9; 12; 15; 24±3.3; ±5;  ±9; ±12; ±15; ±243•82%-40°C - +105°CUL62368

1T10A2_3UP

Download PDF

The 1T10A1_3UP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD10 Package (L x W x H) 15.24 x 11.4 x 7.25 mm
  • High efficiency up to 82%
  • 3000VDC isolation
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)

Field of application:

  • preceding-stage interference isolation condition
  • ground-interference canceled condition
  • digit circuit condition
  • Voltage-isolation converting condition
  • normal low-frequency artificial circuit condition
  • relay drive circuit condition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T10A3_3UPSMD10±10%±5;  ±9; ±12; ±15±5;  ±9; ±12; ±151.5•82%-40°C - +105°CUL62368

1T10A3_3UP

Download PDF

The 1T10A1_1.5UP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD10 Package (L x W x H) 15.24 x 11.4 x 7.25 mm
  • High efficiency up to 82%
  • 1500VDC isolation
  • Temperature range: -40°C ~ +105°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)

Field of application:

  • preceding-stage interference isolation condition
  • ground-interference canceled condition
  • digit circuit condition
  • Voltage-isolation converting condition
  • normal low-frequency artificial circuit condition
  • relay drive circuit condition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T10A2_3RPSMD10±10%5; 12; 243.3; 5; 12; 3••71%-40°C - +85°C

1T10A2_3RP

Download PDF

The 1T10A_3RP Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD10 Package Style (L x W x H) 15.24 x 11.2 x 7.25 mm
  • Regulated Output
  • 3000 VDC Isolation
  • Continuous Short Circuit Protection (SCP)
  • Internal SMD construction
  • Temperature Range: -40°C ~ +85°C
  • Industry Standard Pinout
  • No External Component Required
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • low frequency analog circuits
  • data switching circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T10A3_3RPSMD10±10%3; 5; 123; 5; 123••71%-40°C - +85°C

1T10A3_3RP

Download PDF

The 1T10A_3RP Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD10 Package Style (L x W x H) 15.24 x 11.2 x 7.25 mm
  • Regulated Output
  • 3000 VDC Isolation
  • Continuous Short Circuit Protection (SCP)
  • Internal SMD construction
  • Temperature Range: -40°C ~ +85°C
  • Industry Standard Pinout
  • No External Component Required
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • low frequency analog circuits
  • data switching circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details1T12CW_1.5RPSMD122:19-18; 18-36; 36-725; 12; 15; 241.5••75%-40°C - +85°C

1T12CW_1.5RP

Download PDF

The 1T12CW_1.5RP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD12 Package (L x W x H) 15.24 x 10,90 x 7,10 mm
  • Regulated
  • Wide input range
  • Ultra-thin package
  • High efficiency up to 75%
  • 1500VDC isolation
  • Temperature range: -40°C ~ +85°C
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1T12CW_1205S1.5RP 125
1T12CW_1212S1.5RP 1212
1T12CW_1215S1.5RP 1215
1T12CW_2405S1.5RP 245
1T12CW_2412S1.5RP 2412
1T12CW_2415S1.5RP 2415
1T12CW_4805S1.5RP 485
1T12CW_4812S1.5RP 4812
1T12CW_4815S1.5RP 4815
1T12CW_4824S1.5RP 4824
Details1T16WE_1.5RPSMD162:14,5-9; 9-18; 18-363.3; 5; 12; 15; ±5; ±12; ±151.5••80%-40°C - +85°C

1T16WE_1.5RP

Download PDF

The 1T16WE_1.5RP Series are specially designed for cost effective applications

Features:

  • SMD16 Package (L x W x H) 24.10 x 17.78 x 10,25 mm
  • Wide 2:1 input range
  • Operating temperature: -40°C ~ +85°C
  • 1500VDC isolation
  • No heat sink required
  • Internal SMD construction
  • Short circuit protection SCP (Automatic recovery)
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

1T16WE_0503S1.5RP 53.3
1T16WE_0505D1.5RP 55
1T16WE_0505S1.5RP 55
1T16WE_0512D1.5RP 512
1T16WE_0512S1.5RP 512
1T16WE_0515D1.5RP 515
1T16WE_0515S1.5RP 515
1T16WE_1203S1.5RP 123.3
1T16WE_1205D1.5RP 125
1T16WE_1205S1.5RP 125
1T16WE_1212D1.5RP 1212
1T16WE_1212S1.5RP 1212
1T16WE_1215D1.5RP 1215
1T16WE_1215S1.5RP 1215
1T16WE_2403S1.5RP 243.3
1T16WE_2405D1.5RP 245
1T16WE_2405S1.5RP 245
1T16WE_2412D1.5RP 2412
1T16WE_2412S1.5RP 2412
1T16WE_2415D1.5RP 2415
1T16WE_2415S1.5RP 2415
1T16WE_4803S1.5RP 483.3
1T16WE_4805D1.5RP 485
1T16WE_4805S1.5RP 485
1T16WE_4812D1.5RP 4812
1T16WE_4812S1.5RP 4812
1T16WE_4815D1.5RP 4815
1T16WE_4815S1.5RP 4815
Details1T12A2_3UPSMD12±10%5; 12; 153.3; 5; 9; 12; 15; 24; ±3.3; ±5; ±9; ±12; ±15; ±24385%-40°C - +105°CUL62368

1T12A2_3UP

Download PDF

The 1T12A1_3UP Series is specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD12 Package (L x W x H) 15.24 x 11.40 x 7.25 mm
  • High efficiency up to 85%
  • 3000VDC isolation
  • Short circuit protection [SCP]
  • Temperature range: -40°C ~ +105°C
  • UL62368 approved
  • Industry standard pinout
  • Low temperature rise
  • Internal SMD construction
  • No external component required
  • RoHS compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • driven circuits
  • data switching circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



2 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details2S4A1_1.5UPSIP4±10%5; 12; 155; 9; 12; 15; 241.5•82%-40°C - +85°CUL62368

2S4A1_1.5UP

Download PDF

The 2S4AE_1.5UP Series are designed for application where isolated output is required from a distributed power system.

Features:

  • SIP4 package (L x W x H) 11.6 x 7.5 x 10.2 mm
  • Efficiency up to 82%
  • Short circuit protection (SCP)
  • Temperature Range: -40°C to +85°C
  • 1.5KVDC isolation
  • Industry standard pinout
  • Internal SMD construction
  • High power density
  • No external component required
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S4A2_1.5UPSIP4±10%5; 12; 243;3; 5; 7,2; 12; 151.5•83%-40°C - +85°C

2S4A2_1.5UP

Download PDF

The 2S4AE_1.5UP Series are designed for application where isolated output is required from a distributed power system.

Features:

  • SIP4 package (L x W x H) 11.6 x 7.5 x 10.2 mm
  • Efficiency up to 82%
  • Short circuit protection (SCP)
  • Temperature Range: -40°C to +85°C
  • 1.5KVDC isolation
  • Industry standard pinout
  • Internal SMD construction
  • High power density
  • No external component required
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2D8A1_1.5UPDIP8±10%5; 12; 15; 245; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±241.5•87% -40°C - +105°CUL62368

2D8A1_1.5UP

Download PDF

The 2S4AE_1.5UP Series are designed for application where isolated output is required from a distributed power system.

Features:

  • SIP4 package (L x W x H) 11.6 x 7.5 x 10.2 mm
  • Efficiency up to 82%
  • Short circuit protection (SCP)
  • Temperature Range: -40°C to +85°C
  • 1.5KVDC isolation
  • Industry standard pinout
  • Internal SMD construction
  • High power density
  • No external component required
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2D8A1_3UPDIP8±10%5; 12; 15; 245; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±243•87% -40°C - +105°CUL62368

2D8A1_3UP

Download PDF

The 2S4AE_1.5UP Series are designed for application where isolated output is required from a distributed power system.

Features:

  • SIP4 package (L x W x H) 11.6 x 7.5 x 10.2 mm
  • Efficiency up to 82%
  • Short circuit protection (SCP)
  • Temperature Range: -40°C to +85°C
  • 1.5KVDC isolation
  • Industry standard pinout
  • Internal SMD construction
  • High power density
  • No external component required
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S4A1_3UPSIP4±10%5; 12; 155; 9; 12; 15; 243•82%-40°C - +85°CUL62368

2S4A1_3UP

Download PDF

The 2S4AE_1.5UP Series are designed for application where isolated output is required from a distributed power system.

Features:

  • SIP4 package (L x W x H) 11.6 x 7.5 x 10.2 mm
  • Efficiency up to 82%
  • Short circuit protection (SCP)
  • Temperature Range: -40°C to +85°C
  • 1.5KVDC isolation
  • Industry standard pinout
  • Internal SMD construction
  • High power density
  • No external component required
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7A_1USIP7±10%5; 12; 15; 24; 483.3; 5; 7,2 ; 9; 12; 15; 24; ±3.3; ±5; ±7,2; ±12; ±15; ±18; ±241 82%-40°C - +85°C

2S7A_1U

Download PDF

The 2S7A_1U cost effective series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SIP7 package (L x W x H) 19.5 x 6.0 x 9.5 mm
  • Efficiency up to 82%
  • 1KVDC Isolation
  • Internal SMD construction
  • Temperature range: -40°C ~ +85°C (without derating)
  • No external component required
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2S7A_0303D1UP 3.33.3
2S7A_0303S1UP 3.33.3
2S7A_0305D1UP 3.35
2S7A_0305S1UP 3.35
2S7A_0307D1UP 3.37.2
2S7A_0307S1UP 3.37.2
2S7A_0309D1UP 3.39
2S7A_0309S1UP 3.39
2S7A_0312D1UP 3.312
2S7A_0312S1UP 3.312
2S7A_0315D1UP 3.315
2S7A_0315S1UP 3.315
2S7A_0318D1UP 3.318
2S7A_0318S1UP 3.318
2S7A_0324D1UP 3.324
2S7A_0324S1UP 3.324
2S7A_0503D1UP 53.3
2S7A_0503S1UP 53.3
2S7A_0505D1UP 55
2S7A_0505S1UP 55
2S7A_0507D1UP 57.2
2S7A_0507S1UP 57.2
2S7A_0509D1UP 59
2S7A_0509S1UP 59
2S7A_0512D1UP 512
2S7A_0512S1UP 512
2S7A_0515D1UP 515
2S7A_0515S1UP 515
2S7A_0518D1UP 518
2S7A_0518S1UP 518
2S7A_0524D1UP 524
2S7A_0524S1UP 524
2S7A_1203D1UP 123.3
2S7A_1203S1UP 123.3
2S7A_1205D1UP 125
2S7A_1205S1UP 125
2S7A_1207D1UP 127.2
2S7A_1207S1UP 127.2
2S7A_1209D1UP 129
2S7A_1209S1UP 129
2S7A_1212D1UP 1212
2S7A_1212S1UP 1212
2S7A_1215D1UP 1215
2S7A_1215S1UP 1215
2S7A_1218D1UP 1218
2S7A_1218S1UP 1218
2S7A_1218S1UP 1218
2S7A_1224D1UP 1224
2S7A_1224S1UP 1224
2S7A_1224S1UP 1224
2S7A_2403D1UP 243.3
2S7A_2403S1UP 243.3
2S7A_2405D1UP 245
2S7A_2405S1UP 245
2S7A_2407D1UP 247.2
2S7A_2407S1UP 247.2
2S7A_2409D1UP 249
2S7A_2409S1UP 249
2S7A_2412D1UP 2412
2S7A_2412S1UP 2412
2S7A_2415D1UP 2415
2S7A_2415S1UP 2415
2S7A_2418D1UP 2418
2S7A_2424D1UP 2424
2S7A_4803D1UP 483.3
2S7A_4803S1UP 483.3
2S7A_4805D1UP 485
2S7A_4805S1UP 485
2S7A_4807D1UP 487.2
2S7A_4807S1UP 487.2
2S7A_4809D1UP 489
2S7A_4809S1UP 489
2S7A_4812D1UP 4812
2S7A_4812S1UP 4812
2S7A_4815D1UP 4815
2S7A_4815S1UP 4815
2S7A_4818D1UP 4818
2S7A_4818S1UP 4818
2S7A_4824D1UP 4824
2S7A_4824S1UP 4824
Details2D14B_1UDIP14±10%3.3; 5; 12; 24; 483.3; 5; 7,2; 9; 12; 15; 18; 24; ±3,3; ±5; ±7,2; ±9; ±12; ±15; ±18; ±241 82%-40°C - +85°C

2D14B_1U

Download PDF

The 2D14B_1U Series are specially designed for cost effective applications.

Features:

  • Miniature DIP14 Package (L x W x H) 20.32 x 10.16 x 6.88 mm
  • High Efficiency up to 82%
  • 1000VDC Isolation
  • Internal SMD Construction
  • High power density
  • Temperature Range: -40°C to +85°C
  • No external component required
  • Industry Standard Pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2D14B_0303D1U 3.33.3
2D14B_0303S1U 3.33.3
2D14B_0305D1U 3.35
2D14B_0305S1U 3.35
2D14B_0307D1U 3.37.2
2D14B_0307S1U 3.37.2
2D14B_0309D1U 3.39
2D14B_0309S1U 3.39
2D14B_0312D1U 3.312
2D14B_0312S1U 3.312
2D14B_0315D1U 3.315
2D14B_0315S1U 3.315
2D14B_0318D1U 3.318
2D14B_0318S1U 3.318
2D14B_0324D1U 3.324
2D14B_0324S1U 3.324
2D14B_0503D1U 53.3
2D14B_0503S1U 53.3
2D14B_0505D1U 55
2D14B_0505S1U 55
2D14B_0507D1U 57.2
2D14B_0507S1U 57.2
2D14B_0509D1U 59
2D14B_0509S1U 59
2D14B_0512D1U 512
2D14B_0512S1U 512
2D14B_0515D1U 515
2D14B_0515S1U 515
2D14B_0518D1U 518
2D14B_0518S1U 518
2D14B_0524D1U 524
2D14B_0524S1U 524
2D14B_1203D1U 123.3
2D14B_1203S1U 123.3
2D14B_1205D1U 125
2D14B_1205S1U 125
2D14B_1207D1U 127.2
2D14B_1207S1U 127.2
2D14B_1209D1U 129
2D14B_1209S1U 129
2D14B_1212D1U 1212
2D14B_1212S1U 1212
2D14B_1215D1U 1215
2D14B_1215S1U 1215
2D14B_1218D1U 1218
2D14B_1218S1U 1218
2D14B_1218S1U 1218
2D14B_1224D1U 1224
2D14B_1224S1U 1224
2D14B_1224S1U 1224
2D14B_2403D1U 243.3
2D14B_2403S1U 243.3
2D14B_2405D1U 245
2D14B_2405S1U 245
2D14B_2407D1U 247.2
2D14B_2407S1U 247.2
2D14B_2409D1U 249
2D14B_2409S1U 249
2D14B_2412D1U 2412
2D14B_2412S1U 2412
2D14B_2415D1U 2415
2D14B_2415S1U 2415
2D14B_2418D1U 2418
2D14B_2424D1U 2424
2D14B_4803D1U 483.3
2D14B_4803S1U 483.3
2D14B_4805D1U 485
2D14B_4805S1U 485
2D14B_4807D1U 487.2
2D14B_4807S1U 487.2
2D14B_4809D1U 489
2D14B_4809S1U 489
2D14B_4812D1U 4812
2D14B_4812S1U 4812
2D14B_4815D1U 4815
2D14B_4815S1U 4815
2D14B_4818D1U 4818
2D14B_4818S1U 4818
2D14B_4824D1U 4824
2D14B_4824S1U 4824
Details2S10A1_1.5RPSIP10±10%5; 12; 24±5; ±12; ±15 1.5••80% -40°C - +85°C

2S10A1_1.5RP

Download PDF

The 2S7AE_1.5UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SIP7 package (L x W x H) 19.6 x 7.0 x 10.0 mm
  • High efficiency up to 89%
  • 1.5KVDC Isolation
  • Internal SMD construction
  • Temperature range: -40°C ~ +105°C
  • Short circuit protection (SCP)
  • No external component required
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7A1_1.5UPSIP7±10%5; 9; 12; 15; 245; 12; 15; 24; ±5; ±9; ±12; ±15; ±241.5•84%-40°C - +105°CUL62368

2S7A1_1.5UP

Download PDF

The 2S7AE_1.5UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SIP7 package (L x W x H) 19.6 x 7.0 x 10.0 mm
  • High efficiency up to 89%
  • 1.5KVDC Isolation
  • Internal SMD construction
  • Temperature range: -40°C ~ +105°C
  • Short circuit protection (SCP)
  • No external component required
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7A2_3RPSIP7±10%5; 12; 15; 245; 12; 153••84% -40°C - +85°C

2S7A2_3RP

Download PDF

The 2S7AE_1.5UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SIP7 package (L x W x H) 19.6 x 7.0 x 10.0 mm
  • High efficiency up to 89%
  • 1.5KVDC Isolation
  • Internal SMD construction
  • Temperature range: -40°C ~ +105°C
  • Short circuit protection (SCP)
  • No external component required
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7A2_3UPSIP7±10%5; 9; 12; 15; 245; 12; 15; 24; ±5; ±9; ±12; ±15; ±243•84%-40°C - +105°CUL62368

2S7A2_3UP

Download PDF

The 2S7AE_1.5UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SIP7 package (L x W x H) 19.6 x 7.0 x 10.0 mm
  • High efficiency up to 89%
  • 1.5KVDC Isolation
  • Internal SMD construction
  • Temperature range: -40°C ~ +105°C
  • Short circuit protection (SCP)
  • No external component required
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7B2_3RPSIP7±10%5; 12; 15; 245; 12; 153••84% -40°C - +85°C

2S7B2_3RP

Download PDF

The 2S7AE_1.5UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature SIP7 package (L x W x H) 19.6 x 7.0 x 10.0 mm
  • High efficiency up to 89%
  • 1.5KVDC Isolation
  • Internal SMD construction
  • Temperature range: -40°C ~ +105°C
  • Short circuit protection (SCP)
  • No external component required
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7B1_3UPSIP7±10%5; 12; 15; 243.3; 5; 6.4; 7.2; 9; 12; 15; 24; ±3.3; ±5;±7.2; ±9; ±12; ±15; ±243•86% -40°C - +105°CUL62368

2S7B1_3UP

Download PDF

The 2S7BE_3U series meet reinforced insulation requirements. It is specially designed for applications which require compact size, high isolation, low isolation capacitor and low leakage current power.

Features:

  • SIP7 package (L x W x H) 19.5 x 6.0 x 9.5 mm
  • Efficiency up to 80%
  • 3000VDC basis isolation
  • Industry standard pinout
  • No external component required
  • RoHS compliance
  • Short circuit protection (3sec)
  • UL-60950-1 approved

Field of application:

  • High voltage collection circuit
  • IGBT driven circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7BE_6USIP7±10%3.3; 5; 12; 24; 483.3; 5; 9; 12; 15; 24; ±3.3; ±5; ±9; ±12; ±15; ±24682%-40°C - +85°C

2S7BE_6U

Download PDF

The 2S7BE_6U series meet reinforced insulation requirements. It is specially designed for applications which require compact size, high isolation, low isolation capacitor and low leakage current power.

Features:

  • SIP7 package (L x W x H) 19.5 x 6.0 x 9.5 mm
  • Efficiency up to 80%
  • 6000VDC basis isolation
  • Industry standard pinout
  • No external component required
  • RoHS compliance
  • Short circuit protection (3sec)
  • UL-60950-1 approved

Field of application:

  • High voltage collection circuit
  • IGBT driven circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2S7BE_0303D6U 3.33.3
2S7BE_0303S6U 3.33.3
2S7BE_0305D6U 3.35
2S7BE_0305S6U 3.35
2S7BE_0309D6U 3.39
2S7BE_0309S6U 3.39
2S7BE_0312D6U 3.312
2S7BE_0312S6U 3.312
2S7BE_0315D6U 3.315
2S7BE_0315S6U 3.315
2S7BE_0324D6U 3.324
2S7BE_0324S6U 3.324
2S7BE_0503D6U 53.3
2S7BE_0503S6U 53.3
2S7BE_0505D6U 55
2S7BE_0505S6U 55
2S7BE_0509D6U 59
2S7BE_0509S6U 59
2S7BE_0512D6U 512
2S7BE_0512S6U 512
2S7BE_0515D6U 515
2S7BE_0515S6U 515
2S7BE_0524D6U 524
2S7BE_0524S6U 524
2S7BE_1203D6U 123.3
2S7BE_1203S6U 123.3
2S7BE_1205D6U 125
2S7BE_1205S6U 125
2S7BE_1209D6U 129
2S7BE_1209S6U 129
2S7BE_1212D6U 1212
2S7BE_1212S6U 1212
2S7BE_1215D6U 1215
2S7BE_1215S6U 1215
2S7BE_1224D6U 1224
2S7BE_1224S6U 1224
2S7BE_2403D6U 243.3
2S7BE_2403S6U 243.3
2S7BE_2405D6U 245
2S7BE_2405S6U 245
2S7BE_2409D6U 249
2S7BE_2409S6U 249
2S7BE_2412D6U 2412
2S7BE_2412S6U 2412
2S7BE_2415D6U 2415
2S7BE_2415S6U 2415
2S7BE_2424D6U 2424
2S7BE_2424S6U 2424
2S7BE_4803D6U 483.3
2S7BE_4803S6U 483.3
2S7BE_4805D6U 485
2S7BE_4805S6U 485
2S7BE_4809D6U 489
2S7BE_4809S6U 489
2S7BE_4812D6U 4812
2S7BE_4812S6U 4812
2S7BE_4815D6U 4815
2S7BE_4815S6U 4815
2S7BE_4824D6U 4824
2S7BE_4824S6U 4824
Details2S7B2_6UPSIP7±10%5; 12; 15; 243.3; 5; 9; 12; 15; ±3.3; ±5;  ±9; ±12; ±156•80%-40°C - +95°CUL62368

2S7B2_6UP

Download PDF

The 2S7B1_6UP series meet reinforced insulation requirements. It is specially designed for applications which require compact size, high isolation, low isolation capacitor and low leakage current power.

Features:

  • SIP7 package (L x W x H) 19.5 x 9.8 x 12.5 mm
  • Efficiency up to 81%
  • 5000VAC/6000VDC isolation
  • Reinforced insulation
  • The patient leakage current: max. 2μA
  • Industry standard pinout
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • Meets EN60601-1
  • ANSI/AAMI ES60601-1 standards (Pending)
  • (1xMOPP/2xMOOP)

Field of application:

  • Medical collection and isolation
  • High voltage collection circuit
  • IGBTdriven circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7B3_6UPSIP7±10%12; 15; 2412; 15; ±9; ±12; ±156•80%-40°C - +95°CUL62368

2S7B3_6UP

Download PDF

The 2S7B1_6UP series meet reinforced insulation requirements. It is specially designed for applications which require compact size, high isolation, low isolation capacitor and low leakage current power.

Features:

  • SIP7 package (L x W x H) 19.5 x 9.8 x 12.5 mm
  • Efficiency up to 81%
  • 5000VAC/6000VDC isolation
  • Reinforced insulation
  • The patient leakage current: max. 2μA
  • Industry standard pinout
  • No external component required
  • RoHS compliance
  • Short circuit protection (SCP)
  • Meets EN60601-1
  • ANSI/AAMI ES60601-1 standards (Pending)
  • (1xMOPP/2xMOOP)

Field of application:

  • Medical collection and isolation
  • High voltage collection circuit
  • IGBTdriven circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S7WA_3RPSIP72:14.5-9; 9-18; 18-365; 9; 12; 15; 243••83%-40°C - +95°C

2S7WA_3RP

Download PDF

The 2S7WA_3RP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 package (L x W x H) 19.5 x 7.1 x 10.0 mm
  • 2:1 Wide input voltage range
  • Standard Pinout
  • Pin connection Vin 1 & 2; Vout 4 & 6
  • 3KV Isolation
  • High Efficiency up to 80%
  • Regulated output types
  • Internal SMD construction
  • Operating temperature: -40°C to +85°C
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No external component required
  • Industry standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2S7WA_0505S3RP 55
2S7WA_0509S3RP 59
2S7WA_0512S3RP 512
2S7WA_0515S3RP 515
2S7WA_0524S3RP 524
2S7WA_1205S3RP 125
2S7WA_1209S3RP 129
2S7WA_1212S3RP 1212
2S7WA_1215S3RP 1215
2S7WA_1224S3RP 1224
2S7WA_2405S3UP 245
2S7WA_2409S3UP 249
2S7WA_2412S3UP 2412
2S7WA_2415S3UP 2415
2S7WA_2424S3UP 2424
Details2S7WB_3RPSIP72:14.5-9; 9-18; 18-365; 9; 12; 15; 243••83%-40°C - +95°C

2S7WB_3RP

Download PDF

The 2S7WB_3RP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP7 package (L x W x H) 19.5 x 7.1 x 10.0 mm
  • 2:1 Wide input voltage range
  • Standard Pinout
  • Pin connection Vin 1 & 2; Vout 5 & 7
  • 3KV Isolation
  • High Efficiency up to 80%
  • Regulated output types
  • Internal SMD construction
  • Operating temperature: -40°C to +85°C
  • Short circuit protection (SCP)
  • RoHS Compliance
  • No external component required
  • Industry standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2S7WB_0505S3RP 55
2S7WB_0509S3RP 59
2S7WB_0512S3RP 512
2S7WB_0515S3RP 515
2S7WB_0524S3RP 524
2S7WB_1205S3RP 125
2S7WB_1209S3RP 129
2S7WB_1212S3RP 1212
2S7WB_1215S3RP 1215
2S7WB_1224S3RP 1224
2S7WB_2405S3UP 245
2S7WB_2409S3UP 249
2S7WB_2412S3UP 2412
2S7WB_2415S3UP 2415
2S7WB_2424S3UP 2424
Details2D14B1_1.5UPDIP14±10%12; 15; 245; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±241.5•85%-40°C - +85°C

2D14B1_1.5UP

Download PDF

The 2D14B_1.5UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature DIP14 Package (L x W x H) 20.0 x 10.0 x 8.2 mm
  • High Efficiency up to 86%
  • 1.5KVDC Isolation
  • Internal SMD Construction
  • Short Circuit Protection (SCP)
  • High power density
  • Temperature Range: -40°C to +85°C
  • No external component required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2D14B1_3UPDIP14±10%5; 12; 15; 245; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±243•85%-40°C - +85°C

2D14B1_3UP

Download PDF

The 2D14B_3UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature DIP14 Package (L x W x H) 20.0 x 10.0 x 8.2 mm
  • High Efficiency up to 86%
  • 3.0KVDC Isolation
  • Internal SMD Construction
  • Short Circuit Protection (SCP)
  • High power density
  • Temperature Range: -40°C to +85°C
  • No external component required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2D14C2_3UPDIP14±10%5; 12; 245; 12; 15; ±5; ±12; ±153•86%-40°C - +85°C

2D14C2_3UP

Download PDF

The 2D14B_3UP Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature DIP14 Package (L x W x H) 20.0 x 10.0 x 8.2 mm
  • High Efficiency up to 86%
  • 3.0KVDC Isolation
  • Internal SMD Construction
  • Short Circuit Protection (SCP)
  • High power density
  • Temperature Range: -40°C to +85°C
  • No external component required
  • Industry Standard Pinout
  • RoHS Compliance

Field of application:

  • purely digital circuits
  • ordinary low frequency analog circuits
  • IGBT power device driving circuits

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S8WE_1RPSIP82:14.5-9; 9-18; 18-36; 36-723.3; 5; 9; 12; 15; 241••80%-40°C - +85°C

2S8WE_1RP

Download PDF

The 2S8WE_1RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Cost Effective Type
  • Wide 2:1 Input Voltage Range
  • High Efficiency up to 80%
  • 2W Single and Dual outputs
  • I/O Isolation 1KVDC
  • Operating Temperature Range: -40°C to +85°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2S8WE_0505S1RP 55
2S8WE_0509S1RP 59
2S8WE_0512S1RP 512
2S8WE_0515S1RP 515
2S8WE_0524S1RP 524
2S8WE_1205S1RP 125
2S8WE_1209S1RP 129
2S8WE_1212S1RP 1212
2S8WE_1215S1RP 1215
2S8WE_1224S1RP 1224
2S8WE_2405S1RP 245
2S8WE_2409S1RP 249
2S8WE_2412S1RP 2412
2S8WE_2415S1RP 2415
2S8WE_2424S1RP 2424
2S8WE_4805S1RP 485
2S8WE_4809S1RP 489
2S8WE_4812S1RP 4812
2S8WE_4815S1RP 4815
2S8WE_4824S1RP 4824
Details2S8WE_3RPSIP82:14.5-9; 9-18; 18-36; 36-723.3; 5; 9; 12; 15; 243••80%-40°C - +85°C

2S8WE_3RP

Download PDF

The 2S8WE_3RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Cost Effective Type
  • Wide 2:1 Input Voltage Range
  • High Efficiency up to 80%
  • 2W Single and Dual outputs
  • I/O Isolation 3KVDC
  • Operating Temperature Range: -40°C to +85°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2S8W_0505S3RP 55
2S8W_0509S3RP 59
2S8W_0512S3RP 512
2S8W_0515S3RP 515
2S8W_0524S3RP 524
2S8W_1205S3RP 125
2S8W_1209S3RP 129
2S8W_1212S3RP 1212
2S8W_1215S3RP 1215
2S8W_1224S3RP 1224
2S8W_2405S3RP 245
2S8W_2409S3RP 249
2S8W_2412S3RP 2412
2S8W_2415S3RP 2415
2S8W_2424S3RP 2424
2S8W_4805S3RP 485
2S8W_4809S3RP 489
2S8W_4812S3RP 4812
2S8W_4815S3RP 4815
2S8W_4824S3RP 4824
Details2S8W_2RPSIP82:14.5-9; 9-18; 18-36; 36-753.3; 5; 9; 12; 15; ±3.3; ±5; ±12; ±152; 4; 5.2••85%-40°C - +100°C

2S8W_2RP

Download PDF

The 2S8W_2RP & 2S8W_4RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Wide 2:1 Input Voltage Range
  • High Efficiency up to 81%
  • 2W Single and Dual outputs
  • I/O Isolation 2KVDC and 4KVDC
  • Operating Temperature Range: -40°C to +100°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2S8W_0503D2RP 53.3
2S8W_0503S2RP 53.3
2S8W_0505D2RP 55
2S8W_0505S2RP 55
2S8W_0509D2RP 59
2S8W_0509S2RP 59
2S8W_0512D2RP 512
2S8W_0512S2RP 512
2S8W_0515D2RP 515
2S8W_0515S2RP 515
2S8W_1203D2RP 123.3
2S8W_1203S2RP 123.3
2S8W_1205D2RP 125
2S8W_1205S2RP 125
2S8W_1209D2RP 129
2S8W_1209S2RP 129
2S8W_1212D2RP 1212
2S8W_1212S2RP 1212
2S8W_1215D2RP 1215
2S8W_1215S2RP 1215
2S8W_2403D2RP 243.3
2S8W_2403S2RP 243.3
2S8W_2405D2RP 245
2S8W_2405S2RP 245
2S8W_2409D2RP 249
2S8W_2409S2RP 249
2S8W_2412D2RP 2412
2S8W_2412S2RP 2412
2S8W_2415D2RP 2415
2S8W_2415S2RP 2415
2S8W_4803D2RP 483.3
2S8W_4803S2RP 483.3
2S8W_4805D2RP 485
2S8W_4805S2RP 485
2S8W_4809D2RP 489
2S8W_4809S2RP 489
2S8W_4812D2RP 4812
2S8W_4812S2RP 4812
2S8W_4815D2RP 4815
2S8W_4815S2RP 4815
Details2S8WE4_1RPSIP84:19-36; 18-755; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±241••80%-40°C - +85°C

2S8WE4_1RP

Download PDF

The 2S8WE4_1RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Cost Effective Type
  • Wide 4:1 Input Voltage Range
  • High Efficiency up to 80%
  • 2W Single and Dual outputs
  • I/O Isolation 1KVDC
  • Operating Temperature Range: -40°C to +85°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2S8WE4_3RPSIP84:19-36; 18-755; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±243••80%-40°C - +85°C

2S8WE4_3RP

Download PDF

The 2S8WE4_1RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Cost Effective Type
  • Wide 4:1 Input Voltage Range
  • High Efficiency up to 80%
  • 2W Single and Dual outputs
  • I/O Isolation 3KVDC
  • Operating Temperature Range: -40°C to +85°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2S8WE4_2405D3RP 245
2S8WE4_2405S3RP 245
2S8WE4_2409D3RP 249
2S8WE4_2409S3RP 249
2S8WE4_2412D3RP 2412
2S8WE4_2412S3RP 2412
2S8WE4_2415D3RP 2415
2S8WE4_2415S3RP 2415
2S8WE4_2424D3RP 2424
2S8WE4_2424S3RP 2424
2S8WE4_4805D3RP 485
2S8WE4_4805S3RP 485
2S8WE4_4809D3RP 489
2S8WE4_4809S3RP 489
2S8WE4_4812D3RP 4812
2S8WE4_4812S3RP 4812
2S8WE4_4815D3RP 4815
2S8WE4_4815S3RP 4815
2S8WE4_4824D3RP 4824
2S8WE4_4824S3RP 4824
Details2T10A2_1.5UPSMD10±10%5; 9; 12; 15; 245; 9; 12; 15; ±5; ±9; ±12; ±15; ±241.5•85%-40°C - +105°C

2T10A2_1.5UP

Download PDF

The 2T8A1_1.5UP Series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SMD8 package (L x W x H) 12.7 x 11.2 x 7.25 mm
  • Isolation voltage: 1500 VDC
  • Operating temperature range: -40°C to +105°C
  • Efficiency up to 86%
  • Internal SMD construction
  • No external component required
  • International standard pin-out
  • RoHS compliance
  • Short circuit protection (SCP)

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2T8A2_1.5UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 151.5•85%-40°C - +105°C

2T8A2_1.5UP

Download PDF

The 2T8A1_1.5UP Series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SMD8 package (L x W x H) 12.7 x 11.2 x 7.25 mm
  • Isolation voltage: 1500 VDC
  • Operating temperature range: -40°C to +105°C
  • Efficiency up to 86%
  • Internal SMD construction
  • No external component required
  • International standard pin-out
  • RoHS compliance
  • Short circuit protection (SCP)

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2T8A3_1.5UPSMD8±10%3.3; 5; 12; 15; 243.3; 5; 9; 12; 15; 241.5•85%-40°C - +105°C

2T8A3_1.5UP

Download PDF

The 2T8A1_1.5UP Series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SMD8 package (L x W x H) 12.7 x 11.2 x 7.25 mm
  • Isolation voltage: 1500 VDC
  • Operating temperature range: -40°C to +105°C
  • Efficiency up to 86%
  • Internal SMD construction
  • No external component required
  • International standard pin-out
  • RoHS compliance
  • Short circuit protection (SCP)

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2T10A2_3UPSMD10±10%5; 9; 12; 15; 245; 9; 12; 15; ±5; ±9; ±12; ±15; ±243•85%-40°C - +105°C

2T10A2_3UP

Download PDF

The 2T8A1_3UP Series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SMD8 package (L x W x H) 12.7 x 11.2 x 7.25 mm
  • Isolation voltage: 3000 VDC
  • Operating temperature range: -40°C to +105°C
  • Efficiency up to 84%
  • Internal SMD construction
  • No external component required
  • International standard pin-out
  • RoHS compliance
  • Short circuit protection (SCP)
  • Safety Meets UL60950-1, EN60950-1, IEC60950-1

Field of application:

  • preceding-stage interference isolation condition
  • ground-interference canceled condition
  • digit circuit condition
  • Voltage-isolation converting condition
  • normal low-frequency artificial circuit condition
  • relay drive circuit condition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2T8A2_3UPSMD8±10%3.3; 5; 9; 12; 15; 243.3; 5; 9; 12; 153•85%-40°C - +105°C

2T8A2_3UP

Download PDF

The 2T8A1_3UP Series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SMD8 package (L x W x H) 12.7 x 11.2 x 7.25 mm
  • Isolation voltage: 3000 VDC
  • Operating temperature range: -40°C to +105°C
  • Efficiency up to 84%
  • Internal SMD construction
  • No external component required
  • International standard pin-out
  • RoHS compliance
  • Short circuit protection (SCP)
  • Safety Meets UL60950-1, EN60950-1, IEC60950-1

Field of application:

  • preceding-stage interference isolation condition
  • ground-interference canceled condition
  • digit circuit condition
  • Voltage-isolation converting condition
  • normal low-frequency artificial circuit condition
  • relay drive circuit condition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2T8A3_3UPSMD8±10%3.3; 5; 12; 15; 243.3; 5; 9; 12; 15; 243•85%-40°C - +105°C

2T8A3_3UP

Download PDF

The 2T8A1_3UP Series is specially designed for applications where an isolated voltage is required in a distributed power supply system.

Features:

  • Miniature SMD8 package (L x W x H) 12.7 x 11.2 x 7.25 mm
  • Isolation voltage: 3000 VDC
  • Operating temperature range: -40°C to +105°C
  • Efficiency up to 84%
  • Internal SMD construction
  • No external component required
  • International standard pin-out
  • RoHS compliance
  • Short circuit protection (SCP)
  • Safety Meets UL60950-1, EN60950-1, IEC60950-1

Field of application:

  • preceding-stage interference isolation condition
  • ground-interference canceled condition
  • digit circuit condition
  • Voltage-isolation converting condition
  • normal low-frequency artificial circuit condition
  • relay drive circuit condition

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details2D16WA_1.5RPDIP162:14,5-9; 9-18; 18-363.3; 5; 12; 15; 24; ±5; ±12; ±151.5••80%-40°C - +85°C

2D16WA_1.5RP

Download PDF

The 2D16WA_1.5RP Series are specially designed for cost effective applications

Features:

  • DIP16 Package (L x W x H) 24.10 x 14.35 x 8,25 mm
  • Wide 2:1 input range
  • Operating temperature: -40°C ~ +85°C
  • 1500VDC isolation
  • No heat sink required
  • Internal SMD construction
  • Short circuit protection SCP (Automatic recovery)
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2D16WA_0503S1.5RP 53.3
2D16WA_0505D1.5RP 55
2D16WA_0505S1.5RP 55
2D16WA_0512D1.5RP 512
2D16WA_0512S1.5RP 512
2D16WA_0515D1.5RP 515
2D16WA_0515S1.5RP 515
2D16WA_0524D1.5RP 524
2D16WA_0524S1.5RP 524
2D16WA_1203S1.5RP 123.3
2D16WA_1205D1.5RP 125
2D16WA_1205S1.5RP 125
2D16WA_1212D1.5RP 1212
2D16WA_1212S1.5RP 1212
2D16WA_1215D1.5RP 1215
2D16WA_1215S1.5RP 1215
2D16WA_1224D1.5RP 1224
2D16WA_1224S1.5RP 1224
2D16WA_2403S1.5UP 243.3
2D16WA_2405D1.5RP 245
2D16WA_2405S1.5UP 245
2D16WA_2412D1.5RP 2412
2D16WA_2412S1.5UP 2412
2D16WA_2415D1.5RP 2415
2D16WA_2415S1.5UP 2415
2D16WA_2424D1.5RP 2424
2D16WA_2424S1.5UP 2424
Details2T16WE_1.5RPSMD162:14,5-9; 9-18; 18-363.3; 5; 12; 15; ±5; ±12; ±15; ±241.5••83%-40°C - +85°C

2T16WE_1.5RP

Download PDF

The 2T16WE_1.5RP Series are specially designed for cost effective applications

Features:

  • SMD16 Package (L x W x H) 24.10 x 14.35 x 10,25 mm
  • Wide 2:1 input range
  • Operating temperature: -40°C ~ +85°C
  • 1500VDC isolation[optional 2000VDC]
  • No heat sink required
  • Internal SMD construction
  • Short circuit protection SCP (Automatic recovery)
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

2T16WE_0503S1.5RP 53.3
2T16WE_0505D1.5RP 55
2T16WE_0505S1.5RP 55
2T16WE_0512D1.5RP 512
2T16WE_0512S1.5RP 512
2T16WE_0515D1.5RP 515
2T16WE_0515S1.5RP 515
2T16WE_1203S1.5RP 123.3
2T16WE_1205D1.5RP 125
2T16WE_1205S1.5RP 125
2T16WE_1212D1.5RP 1212
2T16WE_1212S1.5RP 1212
2T16WE_1215D1.5RP 1215
2T16WE_1215S1.5RP 1215
2T16WE_2403S1.5RP 243.3
2T16WE_2405D1.5RP 245
2T16WE_2405S1.5RP 245
2T16WE_2412D1.5RP 2412
2T16WE_2412S1.5RP 2412
2T16WE_2415D1.5RP 2415
2T16WE_2415S1.5RP 2415
2T16WE_4803S1.5RP 483.3
2T16WE_4805D1.5RP 485
2T16WE_4805S1.5RP 485
2T16WE_4812D1.5RP 4812
2T16WE_4812S1.5RP 4812
2T16WE_4815D1.5RP 4815
2T16WE_4815S1.5RP 4815


3 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details3D8W4_1.6RPDIP4:14,5-18; 9-36; 18-753,3; 5; 12; 15; ±5; ±12; ±151.6 84%-40°C - +80°C

3D8W4_1.6RP

Download PDF

The 3D8W4_1.6RP Series is specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Miniature DIP Package (L x W x H) 14.00 x 14.00 x 8.10 mm
  • Wide Input range 4:1
  • 1600VDC isolation
  • Continous Short Circuit Protection
  • Operating temperature range: -40°C℃~ +80°C
  • Fully automated SMD manufacture
  • Industry standard pinout

Field of application:

  • digit circuit condition
  • instrumentation
  • industrial electronics applications

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3D8W4_1203S1.6RP 123.3
3D8W4_1205D1.6RP 125
3D8W4_1205S1.6RP 125
3D8W4_1212D1.6RP 1212
3D8W4_1212S1.6RP 1212
3D8W4_1215D1.6RP 1215
3D8W4_1215S1.6RP 1215
3D8W4_2405D1.6RP 245
3D8W4_2405S1.6RP 245
3D8W4_2412D1.6RP 2412
3D8W4_2412S1.6RP 2412
3D8W4_2415D1.6RP 2415
3D8W4_2415S1.6RP 2415
3D8W4_243R3S1.6RP 243R
3D8W4_4805D1.6RP 485
3D8W4_4805S1.6RP 485
3D8W4_4812D1.6RP 4812
3D8W4_4812S1.6RP 4812
3D8W4_4812S1.6RP 4812
3D8W4_4815D1.6RP 4815
3D8W4_4815S1.6RP 4815
3D8W4_483R3S1.6RP 483R
Details3S8W4_1.5RPRSIP84:19-36; 18-753.3; 5; 12; 15; ±5; ±12; ±151.5••80%-40°C - +85°C

3S8W4_1.5RPR

Download PDF

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S8W4_3RPRSIP84:19-36; 18-753.3; 5; 12; 15; ±5; ±12; ±153••80%-40°C - +85°C

3S8W4_3RPR

Download PDF

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S4A_1UPSIP4±10%5; 125; 9; 12; 15; 18 1 •86% -40°C - +85°C

3S4A_1UP

Download PDF

The 3S4A_1UP series are miniature, isolated 3W DC/DC converters in a SIP package. They offer the ideal solution in many space critical applications for board level power distribution.

The internal SMD construction makes it possible to offer a product with high performance at low cost. The series offers smaller size, improved efficiency, lower output ripple noise.

  • Ultra compact SIP4 Package (L x W x H) 11.48 x 6.00 x 10.0 mm
  • Short Circuit Protection (SCP)
  • Unregulated
  • High power density: 1.53W/cm3
  • Switching Frequency 110KHz / 145KHz
  • Temperature range: -40°C ~ +85°C
  • Efficiency up to 86%
  • No external component required
  • 1KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S4A_0505S1UP 55
3S4A_0509S1UP 59
3S4A_0512S1UP 512
3S4A_0515S1UP 515
3S4A_0524S1UP 524
3S4A_1205S1UP 125
3S4A_1209S1UP 129
3S4A_1212S1UP 1212
3S4A_1215S1UP 1215
3S4A_1218S1UP 1218
Details3D8A1_1.5UPSIP4±10%5; 12; 15; 245; 12; 15; 24; ±5; ±12; ±15; ±24 1.5•88% -40°C - +85°CUL62368

3D8A1_1.5UP

Download PDF

The 3D8A_1.5UP series are miniature, isolated 3W DC/DC converters in a DIP package. They offer the ideal solution in many space critical applications for board level power distribution.

The internal SMD construction makes it possible to offer a product with high performance at low cost. The series offers smaller size, improved efficiency, lower output ripple noise.

  • Compact 8 Pin DIP Package (L x W x H) 12.70 x 10.16 x 7.50 mm
  • Short Circuit Protection (SCP)
  • Single & Dual Output
  • Unregulated
  • Temperature range: -40°C ~ +85°C
  • Efficiency up to 88%
  • No external component required
  • 1500 VDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3D8A1_3UPDIP8±10%5; 12; 15; 245; 12; 15; 24; ±5; ±12; ±15; ±24 1.5•88% -40°C - +85°CUL62368

3D8A1_3UP

Download PDF

The 3D8A_1.5UP series are miniature, isolated 3W DC/DC converters in a DIP package. They offer the ideal solution in many space critical applications for board level power distribution.

The internal SMD construction makes it possible to offer a product with high performance at low cost. The series offers smaller size, improved efficiency, lower output ripple noise.

  • Compact 8 Pin DIP Package (L x W x H) 12.70 x 10.16 x 7.50 mm
  • Short Circuit Protection (SCP)
  • Single & Dual Output
  • Unregulated
  • Temperature range: -40°C ~ +85°C
  • Efficiency up to 88%
  • No external component required
  • 1500 VDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S4A1_1.5UPSIP4±10%5; 12; 15; 245; 12; 15; 241•84% -40°C - +85°CUL62368

3S4A1_1.5UP

Download PDF

The 3S4AE_1UP series are miniature, isolated 3W DC/DC converters in a SIP package. They offer the ideal solution in many space critical applications for board level power distribution.

The internal SMD construction makes it possible to offer a product with high performance at low cost. The series offers smaller size, improved efficiency, lower output ripple noise.

  • Ultra compact SIP4 Package (L x W x H) 11.50 x 7.50 x 10.0 mm
  • Short Circuit Protection (SCP)
  • Unregulated
  • Temperature range: -40°C ~ +85°C
  • Switching Frequency 100 KHz
  • Efficiency up to 84%
  • No external component required
  • 1KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S4A1_3UPSIP4±10%5; 12; 15; 245; 12; 15; 241•84% -40°C - +85°C

3S4A1_3UP

Download PDF

The 3S4AE_1UP series are miniature, isolated 3W DC/DC converters in a SIP package. They offer the ideal solution in many space critical applications for board level power distribution.

The internal SMD construction makes it possible to offer a product with high performance at low cost. The series offers smaller size, improved efficiency, lower output ripple noise.

  • Ultra compact SIP4 Package (L x W x H) 11.50 x 7.50 x 10.0 mm
  • Short Circuit Protection (SCP)
  • Unregulated
  • Temperature range: -40°C ~ +85°C
  • Switching Frequency 100 KHz
  • Efficiency up to 84%
  • No external component required
  • 1KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3MS4A_1.5UPSIP4 micro±10%5; 12; 243.3; 5; 9; 12; 151.5•84% -40°C - +85°C

3MS4A_1.5UP

Download PDF

The 3MS4A_1.5UP Series are designed for application where isolated output is required from a distributed power system.

Features:

  • Micro Size SIP4 package (L x W x H) 14.00 x 7.50 x 10.00 mm
  • Efficiency up to 86%
  • Short circuit protection (SCP)
  • Temperature Range: -40°C to +105°C
  • 1.5KVDC isolation
  • Industry standard pinout
  • Internal SMD construction
  • High power density
  • No external component required
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3MS4B_3UPSIP4 micro±10%5; 12; 243.3; 5; 9; 12; 153•84% -40°C - +85°C

3MS4B_3UP

Download PDF

The 3MS4B_1.5UP Series are designed for application where isolated output is required from a distributed power system.

Features:

  • Micro Size SIP4 package (L x W x H) 14.00 x 7.50 x 10.00 mm
  • Efficiency up to 86%
  • Short circuit protection (SCP)
  • Temperature Range: -40°C to +105°C
  • 3KVDC isolation
  • Industry standard pinout
  • Internal SMD construction
  • High power density
  • No external component required
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S6W4_1.6RPSIP64:14.5-18; 9-36; 18-753.3; 5; 12; 15; ±5; ±12; ±151.6••84%-40°C - +71°CUL62368

3S6W4_1.6RP

Download PDF

The 3S6W4_1.6RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP6 Package (L x W x H) 17.0 x 10.02 x 11.7 mm
  • 3W Single and Dual outputs
  • Ultra Wide 4:1 Input Voltage Range
  • High Efficiency up to 84%
  • I/O Isolation 1,6KV
  • Operating Temperature Range: -40°C to +76°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S6W4_1203S1.6RP 123.3
3S6W4_1205D1.6RP 125
3S6W4_1205S1.6RP 125
3S6W4_1212D1.6RP 1212
3S6W4_1212S1.6RP 1212
3S6W4_1215D1.6RP 1215
3S6W4_1215S1.6RP 1215
3S6W4_2403S1.6RP 243.3
3S6W4_2405D1.6RP 245
3S6W4_2405S1.6RP 245
3S6W4_2412D1.6RP 2412
3S6W4_2412S1.6RP 2412
3S6W4_2415D1.6RP 2415
3S6W4_2415S1.6RP 2415
3S6W4_4803S1.6RP 483.3
3S6W4_4805D1.6RP 485
3S6W4_4805S1.6RP 485
3S6W4_4812D1.6RP 4812
3S6W4_4812S1.6RP 4812
3S6W4_4815D1.6RP 4815
3S6W4_4815S1.6RP 4815
Details3S6W4_3RPSIP64:14.5-18; 9-36; 18-753.3; 5; 12; 15; ±5; ±12; ±151.6••84%-40°C - +71°C

3S6W4_3RP

Download PDF

The 3S6W4_1.6RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP6 Package (L x W x H) 17.0 x 10.02 x 11.7 mm
  • 3W Single and Dual outputs
  • Ultra Wide 4:1 Input Voltage Range
  • High Efficiency up to 84%
  • I/O Isolation 1,6KV
  • Operating Temperature Range: -40°C to +76°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S7A_1USIP7±10%5; 125; 9; 12; 15; ±5; ±9; ±12; ±15 1 90%-40°C - +85°C

3S7A_1U

Download PDF

The 3S7A_1U Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

  • SIP7 package (L x W x H) 19.6 x 7.0 x 10.0 mm
  • Semi-regulated
  • Low ripple and high EMC features
  • Temperature range: -40°C ~ +85°C
  • No heat sink required
  • No external component required
  • 1KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S7A_0505D1U 55
3S7A_0505S1U 55
3S7A_0509D1U 59
3S7A_0509S1U 59
3S7A_0512D1U 512
3S7A_0512S1U 512
3S7A_0515D1U 515
3S7A_0515S1U 515
3S7A_1205D1U 125
3S7A_1205S1U 125
3S7A_1209D1U 129
3S7A_1209S1U 129
3S7A_1212D1U 1212
3S7A_1212S1U 1212
3S7A_1215D1U 1215
3S7A_1215S1U 1215
Details3S7A1_1.5UPSIP7±10%5; 12; 15; 245; 12; 15; 24 1.5•88%-40°C - +105°CUL62368

3S7A1_1.5UP

Download PDF

The 3S7A_1.5UP Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

  • SIP7 package (L x W x H) 19.5 x 7.5 x 10.0 mm
  • Short Circuit Protection (SCP)
  • Low ripple and high EMC features
  • Temperature range: -40°C ~ +105°C
  • No heat sink required
  • No external component required
  • 1.5KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S7A_1.5UPSIP7±10%3.3; 5; 12; 24; 483.3; 5; 9; 12; 15; 24 1.5•88%-40°C - +105°C

3S7A_1.5UP

Download PDF

The 3S7A_1.5UP Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

  • SIP7 package (L x W x H) 19.5 x 7.5 x 10.0 mm
  • Short Circuit Protection (SCP)
  • Low ripple and high EMC features
  • Temperature range: -40°C ~ +105°C
  • No heat sink required
  • No external component required
  • 1.5KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S7A_0305S1.5UP 3.35
3S7A_0503S1.5UP 53.3
3S7A_0503S1.5UP 53.3
3S7A_0505S1.5UP 55
3S7A_0505S1.5UP 55
3S7A_0509S1.5UP 59
3S7A_0509S1.5UP 59
3S7A_0512S1.5UP 512
3S7A_0512S1.5UP 512
3S7A_0515S1.5UP 515
3S7A_0515S1.5UP 515
3S7A_0524S1.5UP 524
3S7A_0524S1.5UP 524
3S7A_1203S1.5UP 123.3
3S7A_1203S1.5UP 123.3
3S7A_1205S1.5UP 125
3S7A_1205S1.5UP 125
3S7A_1209S1.5UP 129
3S7A_1209S1.5UP 129
3S7A_12124S1.5UP 1212
3S7A_12124S1.5UP 1212
3S7A_1212S1.5UP 1212
3S7A_1212S1.5UP 1212
3S7A_1215S1.5UP 1215
3S7A_1215S1.5UP 1215
3S7A_1505S1.5UP 155
3S7A_1505S1.5UP 155
3S7A_1515S1.5UP 1515
3S7A_1515S1.5UP 1515
3S7A_2403S1.5UP 243.3
3S7A_2403S1.5UP 243.3
3S7A_2405S1.5UP 245
3S7A_2405S1.5UP 245
3S7A_2409S1.5UP 249
3S7A_2409S1.5UP 249
3S7A_24124S1.5UP 2412
3S7A_24124S1.5UP 2412
3S7A_2412S1.5UP 2412
3S7A_2412S1.5UP 2412
3S7A_2415S1.5UP 2415
3S7A_2415S1.5UP 2415
3S7A_4805S1.5UP 485
3S7A_4805S1.5UP 485
3S7A_4812S1.5UP 4812
Details3S7B_3USIP7±10%5; 125; 9; 12; 15; ±5; ±9; ±12; ±15 390%-40°C - +85°C

3S7B_3U

Download PDF

The 3S7B_3U Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

  • SIP7 package (L x W x H) 19.6 x 7.0 x 10.0 mm
  • Semi-regulated
  • Low ripple and high EMC features
  • Temperature range: -40°C ~ +85°C
  • No heat sink required
  • No external component required
  • 3KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S7B_0505D3U 55
3S7B_0505S3U 55
3S7B_0509D3U 59
3S7B_0509S3U 59
3S7B_0512D3U 512
3S7B_0512S3U 512
3S7B_0515D3U 515
3S7B_0515S3U 515
3S7B_1205D3U 125
3S7B_1205S3U 125
3S7B_1209D3U 129
3S7B_1209S3U 129
3S7B_1212D3U 1212
3S7B_1212S3U 1212
3S7B_1215D3U 1215
3S7B_1215S3U 1215
Details3S7B1_3UPSIP7±10%5; 12; 15; 245; 12; 15; 24 3•87%-40°C - +85°CUL62368

3S7B1_3UP

Download PDF

The 3S7B_3UP Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

  • SIP7 package (L x W x H) 19.5 x 7.7 x 10.0 mm
  • Semi-regulated
  • Short Circuit Protection (SCP)
  • Low ripple and high EMC features
  • Temperature range: -40°C ~ +85°C
  • No heat sink required
  • No external component required
  • 3KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S7B_3UPSIP7±10%3.3; 5; 12; 243.3; 5; 9; 12; 15; ±5; ±9; ±12; ±15; ±24 3•87%-40°C - +85°C

3S7B_3UP

Download PDF

The 3S7B_3UP Series is specially designed for applications where a single power supply is highly isolated from the input power supply in a distributed power supply system on a circuit board.

  • SIP7 package (L x W x H) 19.5 x 7.7 x 10.0 mm
  • Semi-regulated
  • Short Circuit Protection (SCP)
  • Low ripple and high EMC features
  • Temperature range: -40°C ~ +85°C
  • No heat sink required
  • No external component required
  • 3KVDC isolation
  • Internal SMD construction
  • Industry standard pinout
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S7B_0303S3UP 3.33.3
3S7B_0305S3UP 3.35
3S7B_0503S3UP 53.3
3S7B_0505D3UP 55
3S7B_0505S3UP 55
3S7B_0509D3UP 59
3S7B_0509S3UP 59
3S7B_0512D3UP 512
3S7B_0512S3UP 512
3S7B_0515D3UP 515
3S7B_0515S3UP 515
3S7B_0524D3UP 524
3S7B_1205D3UP 125
3S7B_1205S3UP 125
3S7B_1209D3UP 129
3S7B_1209S3UP 129
3S7B_1212D3UP 1212
3S7B_1212S3UP 1212
3S7B_1215D3UP 1215
3S7B_1215S3UP 1215
3S7B_1515D3UP 1515
3S7B_1515S3UP 1515
3S7B_2405D3UP 245
3S7B_2405S3UP 245
3S7B_2412D3UP 2412
3S7B_2412S3UP 2412
3S7B_2415D3UP 2415
3S7B_2415S3UP 2415
3S7B_2424D3UP 2424
3S7B_2424S3UP 2424
Details3S8W_1.5RPRSIP82:14.5-9; 9-18; 18-36; 36-753.3; 5; 9; 12; 15; 241.5••84%-40°C - +85°C

3S8W_1.5RPR

Download PDF

The 3S8W_S & 3S8W_D Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. For these DC-DC converters, You can reduce the design point of failure and save the development of micro power supply‘s manpower, material and time costs, also better ensure product quality stability, protect safety and reliability of the end of products.

Features:

  • SIP8 Package (L x W x H) 22.0 x 9.5 x 12.0 mm
  • 2:1 wide input voltage range
  • 1.5KVDC isolation
  • Short circuit protection (SCP (automatic recovery)
  • External On/Off control
  • High Power Density
  • Operating Temperature: -40°C to +85°C
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S8W_3RPRSIP82:14.5-9; 9-18; 18-36; 36-753.3; 5; 9; 12; 15; 243••84%-40°C - +85°C

3S8W_3RPR

Download PDF

The 3S8W_S & 3S8W_D Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. For these DC-DC converters, You can reduce the design point of failure and save the development of micro power supply‘s manpower, material and time costs, also better ensure product quality stability, protect safety and reliability of the end of products.

Features:

  • SIP8 Package (L x W x H) 22.0 x 9.5 x 12.0 mm
  • 2:1 wide input voltage range
  • 1.5KVDC isolation
  • Short circuit protection (SCP (automatic recovery)
  • External On/Off control
  • High Power Density
  • Operating Temperature: -40°C to +85°C
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3S8W_3RPSIP82:14.5-9; 9-18; 18-36; 36-753.3; 5; 9; 12; 15; ±5; ±9; ±12; ±153••83%-40°C - +85°C

3S8W_3RP

Download PDF

The 3S8W_S3RP & 3S8W_D3RP Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. For these DC-DC converters, You can reduce the design point of failure and save the development of micro power supply‘s manpower, material and time costs, also better ensure product quality stability, protect safety and reliability of the end of products.

Features:

  • SIP8 Package (L x W x H) 22.0 x 9.5 x 12.0 mm
  • 2:1 wide input voltage range
  • 3 KVDC isolation
  • Short circuit protection (SCP (automatic recovery)
  • External On/Off control
  • High Power Density
  • Operating Temperature: -40°C to +85°C
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S8W_0505D3RP 55
3S8W_0505S3RP 55
3S8W_0509S3RP 59
3S8W_0512D3RP 512
3S8W_0512S3RP 512
3S8W_0515D3RP 515
3S8W_0515S3RP 515
3S8W_1203S3RP 123.3
3S8W_1205D3RP 125
3S8W_1205S3RP 125
3S8W_1209S3RP 129
3S8W_1212D3RP 1212
3S8W_1212S3RP 1212
3S8W_1215D3RP 1215
3S8W_1215S3RP 1215
3S8W_1224S3RP 1224
3S8W_2403S3RP 243.3
3S8W_2405D3RP 245
3S8W_2405S3RP 245
3S8W_2409D3RP 249
3S8W_2409S3RP 249
3S8W_2412D3RP 2412
3S8W_2412S3RP 2412
3S8W_2415D3RP 2415
3S8W_2415S3RP 2415
3S8W_2424S3RP 2424
3S8W_4803S3RP 483.3
3S8W_4805D3RP 485
3S8W_4805S3RP 485
3S8W_4812D3RP 4812
3S8W_4812S3RP 4812
3S8W_4815D3RP 4815
3S8W_4815S3RP 4815
Details3S8W_2RPSIP82:14.5-9; 9-18; 18-36; 36-753.3; 5; 9; 12; 15; ±5; ±12; ±152 & 4••86%-40°C - +100°C

3S8W_2RP

Download PDF

The 3S8W_2RP & 3S8W_4RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • 3W Single and Dual outputs
  • Wide 2:1 Input Voltage Range
  • Very Low Stand-by (no-load) Power Consumption
  • 50mW typ and 150mW max. High Efficiency up to 86%
  • I/O Isolation 2KVDC and 4KVDC
  • Operating Temperature Range: -40°C to +85°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S8W_0503S2RP 53.3
3S8W_0505D2RP 55
3S8W_0505S2RP 55
3S8W_0509S2RP 59
3S8W_0512D2RP 512
3S8W_0512S2RP 512
3S8W_0515D2RP 515
3S8W_0515S2RP 515
3S8W_1203S2RP 123.3
3S8W_1205D2RP 125
3S8W_1205S2RP 125
3S8W_1209S2RP 129
3S8W_1212D2RP 1212
3S8W_1212S2RP 1212
3S8W_1215D2RP 1215
3S8W_1215S2RP 1215
3S8W_2403S2RP 243.3
3S8W_2405D2RP 245
3S8W_2405S2RP 245
3S8W_2409S2RP 249
3S8W_2412D2RP 2412
3S8W_2412S2RP 2412
3S8W_2415D2RP 2415
3S8W_2415S2RP 2415
3S8W_4803S2RP 483.3
3S8W_4805D2RP 485
3S8W_4805S2RP 485
3S8W_4809S2RP 489
3S8W_4812D2RP 4812
3S8W_4812S2RP 4812
3S8W_4815D2RP 4815
3S8W_4815S2RP 4815
Details3S8EW4_1.5RPSIP84:19-36; 18-753.3; 5; 9; 12; 15; ±5; ±9; ±12; ±151.5••80%-40°C - +85°C

3S8EW4_1.5RP

Download PDF

The 3S8EW4_1.5RP cost effective series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.0 mm
  • 4:1 wide input voltage range
  • Cost effective design
  • 1.5KVDC isolation
  • Short circuit protection (SCP (automatic recovery)
  • External On/Off control
  • High Power Density
  • Operating Temperature: -40°C to +85°C
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S8EW4_2403S1.5RP 243.3
3S8EW4_2405D1.5RP 245
3S8EW4_2405S1.5RP 245
3S8EW4_2409D1.5RP 249
3S8EW4_2409S1.5RP 249
3S8EW4_2412D1.5RP 2412
3S8EW4_2412S1.5RP 2412
3S8EW4_2415D1.5RP 2415
3S8EW4_2415S1.5RP 2415
3S8EW4_4803S1.5RP 483.3
3S8EW4_4805D1.5RP 485
3S8EW4_4805S1.5RP 485
3S8EW4_4809D1.5RP 489
3S8EW4_4809S1.5RP 489
3S8EW4_4812D1.5RP 4812
3S8EW4_4812S1.5RP 4812
3S8EW4_4815D1.5RP 4815
3S8EW4_4815S1.5RP 4815
Details3S8W4_2RPSIP84:14.5-18; 9-36; 18-753.3; 5; 12; 15; ±3.3; ±5; ±12; ±152 & 4••86%-40°C - +100°C

3S8W4_2RP

Download PDF

The 3S8W4_2RP & 3S8W4_4RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 Package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • 3W Single and Dual outputs
  • Ultra Wide 4:1 Input Voltage Range
  • Very Low Stand-by (no-load) Power Consumption 50mW typ and 150mW max.
  • High Efficiency up to 86%
  • I/O Isolation 2KVDC and 4KVDC Version
  • Operating Temperature Range: -40°C to +85°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3S8W4_0503S2RP 53.3
3S8W4_0505D2RP 55
3S8W4_0505S2RP 55
3S8W4_0512D2RP 512
3S8W4_0512S2RP 512
3S8W4_0515D2RP 515
3S8W4_0515S2RP 515
3S8W4_1203S2RP 123.3
3S8W4_1205D2RP 125
3S8W4_1205S2RP 125
3S8W4_1212D2RP 1212
3S8W4_1212S2RP 1212
3S8W4_1215D2RP 1215
3S8W4_1215S2RP 1215
3S8W4_2403S2RP 243.3
3S8W4_2405D2RP 245
3S8W4_2405S2RP 245
3S8W4_2412D2RP 2412
3S8W4_2412S2RP 2412
3S8W4_2415D2RP 2415
3S8W4_2415S2RP 2415
3S8W4_4803S2RP 483.3
3S8W4_4805D2RP 485
3S8W4_4805S2RP 485
3S8W4_4812D2RP 4812
3S8W4_4812S2RP 4812
3S8W4_4815D2RP 4815
3S8W4_4815S2RP 4815
Details3T16W4_1.5RPRSMD162:14.5-18; 9-363.3; 5; 9; 12; 15; ±5; ±9; ±12; ±151.5••80%-40°C - +85°C

3T16W4_1.5RPR

Download PDF

The 3T16WE_1.5RP Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD16 Package (L x W x H) 24.1 x (14,35) 19.8 x 10.25 mm
  • 2:1 Wide input voltage range
  • Operating temperature: -40°C ~ +85°C
  • 1500VDC isolation
  • No heatsink required
  • Internal SMD construction
  • MTBF>1,000,000 hours
  • Short circuit protection (SCP) (automatic recovery)
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3T16WE_1.5RPSMD162:14.5-9; 9-18; 18-36; 36-753.3; 5; 12; 15; ±5; ±12; ±151.5••82%-40°C - +85°C

3T16WE_1.5RP

Download PDF

The 3T16WE_1.5RP Series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SMD16 Package (L x W x H) 24.1 x (14,35) 19.8 x 10.25 mm
  • 2:1 Wide input voltage range
  • Operating temperature: -40°C ~ +85°C
  • 1500VDC isolation
  • No heatsink required
  • Internal SMD construction
  • MTBF>1,000,000 hours
  • Short circuit protection (SCP) (automatic recovery)
  • Industry standard pinout
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3T16WE_0503S1.5RP 53.3
3T16WE_0505D1.5RP 55
3T16WE_0505S1.5RP 55
3T16WE_0512D1.5RP 512
3T16WE_0512S1.5RP 512
3T16WE_0515D1.5RP 515
3T16WE_0515S1.5RP 515
3T16WE_1203S1.5RP 123.3
3T16WE_1205D1.5RP 125
3T16WE_1205S1.5RP 125
3T16WE_1212D1.5RP 1212
3T16WE_1212S1.5RP 1212
3T16WE_1215D1.5RP 1215
3T16WE_1215S1.5RP 1215
3T16WE_2403S1.5RP 243.3
3T16WE_2405D1.5RP 245
3T16WE_2405S1.5RP 245
3T16WE_2412D1.5RP 2412
3T16WE_2412S1.5RP 2412
3T16WE_2415D1.5RP 2415
3T16WE_2415S1.5RP 2415
3T16WE_4803S1.5RP 483.3
3T16WE_4805D1.5RP 485
3T16WE_4805S1.5RP 485
3T16WE_4812D1.5RP 4812
3T16WE_4812S1.5RP 4812
3T16WE_4815D1.5RP 4815
3T16WE_4815S1.5RP 4815
Details3TAW_1.5SMD242:19-18; 18-36; 36-755; 12; 15; ±5; ±12; ±151.5••85%-40°C - +85°C

3TAW_1.5

Download PDF

The 3TAW_1.5 series offers

  • SMD24 Package (L x W x H) 31.8 x 25.4 x 11.4 mm
  • 2:1 Wide input voltage range
  • 1.5kVDC Input/Output Isolation
  • Short circuit protection (SCP) (automatic recovery)
  • High efficiency
  • UL94-V0 package material
  • RoHS Compliance
  • Custom solutions available

All models are particularly suited to industrial. tele-communications. test equipments power.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3TAW_1205D1.5 125
3TAW_1205S1.5 125
3TAW_1212D1.5 1212
3TAW_1212S1.5 1212
3TAW_1215D1.5 1215
3TAW_1215S1.5 1215
3TAW_2405D1.5 245
3TAW_2405S1.5 245
3TAW_2412D1.5 2412
3TAW_2412S1.5 2412
3TAW_2415D1.5 2415
3TAW_2415S1.5 2415
3TAW_4805D1.5 485
3TAW_4805S1.5 485
3TAW_4812D1.5 4812
3TAW_4812S1.5 4812
3TAW_4815D1.5 4815
3TAW_4815S1.5 4815
Details3DAW_2DIP242:14.5-9; 9-18; 18-36; 36-753.3; 5; 12; 15; ±3.3; ±5; ±12; ±152; 4; 6••85%-40°C - +100°C

3DAW_2

Download PDF

The 3DAW series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP24 Package (L x W x H) 32.0 x 20.3 x 10.2 mm
  • 3W Single and Dual outputs
  • Wide 2:1 Input Voltage Range
  • Very Low Stand-by (no-load) Power Consumption 50mW typ. and 150mW max.
  • High Efficiency up to 86%
  • I/O Isolation 1KVDC, 2KVDC, 4KVDC & 6KVDC Option
  • Operating Temperature Range: -40°C to +100°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control Option
  • 3 Pinout Options A, B & C Pinniung
  • Plastic & Metal Case Styles
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3DAW_0503S2 53.3
3DAW_0505D2 55
3DAW_0505S2 55
3DAW_0509S2 59
3DAW_0512D2 512
3DAW_0512S2 512
3DAW_0515D2 515
3DAW_0515S2 515
3DAW_0524S2 524
3DAW_1203S2 123.3
3DAW_1205D2 125
3DAW_1205S2 125
3DAW_1209S2 129
3DAW_1212D2 1212
3DAW_1212S2 1212
3DAW_1215D2 1215
3DAW_1215S2 1215
3DAW_1224S2 1224
3DAW_2403S2 243.3
3DAW_2405D2 245
3DAW_2405S2 245
3DAW_2409S2 249
3DAW_2412D2 2412
3DAW_2412S2 2412
3DAW_2415D2 2415
3DAW_2415S2 2415
3DAW_2424S2 2424
3DAW_4803S2 483.3
3DAW_4805D2 485
3DAW_4805S2 485
3DAW_4809S2 489
3DAW_4812D2 4812
3DAW_4812S2 4812
3DAW_4815D2 4815
3DAW_4815S2 4815
3DAW_4824S2 4824
Details3DAW4_1.5RDIP244:19-36; 18-723.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±151.5••83%-40°C - +85°C

3DAW4_1.5R

Download PDF

The 3DAW4_1.5 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP24 Package (L x W x H) 32.0 x 20.0 x 10.8 mm
  • Ultra Wide 4:1 wide input voltage range
  • Operating temperature: -40°C to +85°C
  • 1500VDC isolation
  • Short circuit protection, SCP (automatic recovery)
  • Internal SMD construction
  • UL94-V0 package
  • No external component required
  • Industry standard pinout (B-Pinning)
  • MTBF>1,000,000 hours
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3DAW_1.5RDIP242:14.5-9; 9-18; 18-36; 36-723.3; 5; 9; 12; 15; 24; ±5; ±12; ±151.5••85%-40°C - +85°C

3DAW_1.5R

Download PDF

The 3DAW4_1.5 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP24 Package (L x W x H) 32.0 x 20.0 x 10.8 mm
  • Ultra Wide 4:1 wide input voltage range
  • Operating temperature: -40°C to +85°C
  • 1500VDC isolation
  • Short circuit protection, SCP (automatic recovery)
  • Internal SMD construction
  • UL94-V0 package
  • No external component required
  • Industry standard pinout (B-Pinning)
  • MTBF>1,000,000 hours
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3DAW_3RDIP242:14.5-9; 9-18; 18-36; 36-723.3; 5; 9; 12; 15; 24; ±5; ±12; ±153••85%-40°C - +85°C

3DAW_3R

Download PDF

The 3DAW4_1.5 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP24 Package (L x W x H) 32.0 x 20.0 x 10.8 mm
  • Ultra Wide 4:1 wide input voltage range
  • Operating temperature: -40°C to +85°C
  • 1500VDC isolation
  • Short circuit protection, SCP (automatic recovery)
  • Internal SMD construction
  • UL94-V0 package
  • No external component required
  • Industry standard pinout (B-Pinning)
  • MTBF>1,000,000 hours
  • RoHS compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details3DAW4_2DIP244:14.5-18; 9-36; 18-753.3; 5; 12; 15; ±5; ±12; ±152; 4; 6••86%-40°C - +100°C

3DAW4_2

Download PDF

The 3DAW4_2 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP24 Package (L x W x H) 32.0 x 20.3 x 10.2 mm
  • 3W Single and Dual outputs
  • Ultra Wide 4:1 Input Voltage Range
  • Very Low Stand-by (no-load) Power Consumption 50mW typ and 150mW max.
  • High Efficiency up to 86%
  • I/O Isolation 1KVDC, 2KVDC, 4KVDC & 6KVDC Option
  • Operating Temperature Range: -40°C to +100°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control add Suffix „/CTRL“ Option
  • 3 Pinout Options A, B & C Pinning
  • Plastic & Metal case option
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

3DAW4_0503S2 53.3
3DAW4_0505D2 55
3DAW4_0505S2 55
3DAW4_0512D2 512
3DAW4_0512S2 512
3DAW4_0515D2 515
3DAW4_0515S2 515
3DAW4_1203S2 123.3
3DAW4_1205D2 125
3DAW4_1205S2 125
3DAW4_1212D2 1212
3DAW4_1212S2 1212
3DAW4_1215D2 1215
3DAW4_1215S2 1215
3DAW4_2403S2 243.3
3DAW4_2405D2 245
3DAW4_2405S2 245
3DAW4_2412D2 2412
3DAW4_2412S2 2412
3DAW4_2415D2 2415
3DAW4_2415S2 2415
3DAW4_4803S2 483.3
3DAW4_4805D2 485
3DAW4_4805S2 485
3DAW4_4812D2 4812
3DAW4_4812S2 4812
3DAW4_4815D2 4815
3DAW4_4815S2 4815
Details3DAW4_3DIP244:19-36; 18-753.3; 5; 12; 15; 24; ±3.3; ±5; ±12; ±15; ±243••82% -40°C - +100°CUL62368

3DAW4_3

Download PDF

The 3DAW4_2 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP24 Package (L x W x H) 32.0 x 20.3 x 10.2 mm
  • 3W Single and Dual outputs
  • Ultra Wide 4:1 Input Voltage Range
  • Very Low Stand-by (no-load) Power Consumption 50mW typ and 150mW max.
  • High Efficiency up to 86%
  • I/O Isolation 1KVDC, 2KVDC, 4KVDC & 6KVDC Option
  • Operating Temperature Range: -40°C to +100°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control add Suffix „/CTRL“ Option
  • 3 Pinout Options A, B & C Pinning
  • Plastic & Metal case option
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



5 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details5S8W_2RPSIP82:14.5-9; 9-18; 18-36; 36-753.3; 5; 12; 15; ±5; ±12; ±152; 4 ••85%-40°C - +100°C

5S8W_2RP

Download PDF

The 5S8W_2RP & 5S8W_4RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 package (L x W x L) 21.8 x 9.2 x 11.1 mm
  • 5W single and dual outputs
  • Highest power density
  • Wide 2:1 input voltage range
  • High efficiency up to 87%
  • I/O isolation 2KVDC and 4KVDC option
  • Operating temperature range: -40°C to +85°C
  • Continuous short circuit protection (SCP)
  • Remote ON/OFF control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

5S8W_0503S2RP 53.3
5S8W_0505D2RP 55
5S8W_0505S2RP 55
5S8W_0509S2RP 59
5S8W_0512D2RP 512
5S8W_0512S2RP 512
5S8W_0515D2RP 515
5S8W_0515S2RP 515
5S8W_1203S2RP 123.3
5S8W_1205D2RP 125
5S8W_1205S2RP 125
5S8W_1209S2RP 129
5S8W_1212D2RP 1212
5S8W_1212S2RP 1212
5S8W_1215D2RP 1215
5S8W_1215S2RP 1215
5S8W_2403S2RP 243.3
5S8W_2405D2RP 245
5S8W_2405S2RP 245
5S8W_2409S2RP 249
5S8W_2412D2RP 2412
5S8W_2412S2RP 2412
5S8W_2415D2RP 2415
5S8W_2415S2RP 2415
5S8W_4803S2RP 483.3
5S8W_4805D2RP 485
5S8W_4805S2RP 485
5S8W_4809S2RP 489
5S8W_4812D2RP 4812
5S8W_4812S2RP 4812
5S8W_4815D2RP 4815
5S8W_4815S2RP 4815
Details5S8W4_2RPSIP84:19-36; 18-753.3; 5; 12; 15; ±5; ±12; ±152; 4 ••85%-40°C - +85°C

5S8W4_2RP

Download PDF

The 5S8W4_2RP & 5S8W4_4RP series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • SIP8 package (L x W x L) 21.8 x 9.2 x 11.1 mm
  • 5W single and dual outputs
  • Highest power density
  • Wide 4:1 input voltage range
  • High efficiency up to 87%
  • I/O isolation 2KVDC and 4KVDC option
  • Operating temperature range: -40°C to +85°C
  • Continuous short circuit protection (SCP)
  • Remote ON/OFF control

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

5S8W4_0503S2RP 53.3
5S8W4_0505D2RP 55
5S8W4_0505S2RP 55
5S8W4_0509D2RP 59
5S8W4_0509S2RP 59
5S8W4_0512D2RP 512
5S8W4_0512S2RP 512
5S8W4_0515S2RP 515
5S8W4_1203S2RP 123.3
5S8W4_1205D2RP 125
5S8W4_1205S2RP 125
5S8W4_1209D2RP 129
5S8W4_1209S2RP 129
5S8W4_1212D2RP 1212
5S8W4_1212S2RP 1212
5S8W4_1215D2RP 1215
5S8W4_1215D2RP 1215
5S8W4_1215S2RP 1215
5S8W4_2403S2RP 243.3
5S8W4_2405D2RP 245
5S8W4_2405S2RP 245
5S8W4_2409D2RP 249
5S8W4_2409S2RP 249
5S8W4_2412D2RP 2412
5S8W4_2412S2RP 2412
5S8W4_2415D2RP 2415
5S8W4_2415S2RP 2415
5S8W4_4803S2RP 483.3
5S8W4_4805D2RP 485
5S8W4_4805S2RP 485
5S8W4_4809D2RP 489
5S8W4_4809S2RP 489
5S8W4_4812D2RP 4812
5S8W4_4812S2RP 4812
5S8W4_4815D2RP 4815
5S8W4_4815S2RP 4815
Details5DAW_2DIP242:14.5-9; 9-18; 18-36; 36-753.3; 5; 12; 15; ±5; ±12; ±152; 4; 6••87%-40°C - +100°C

5DAW_2

Download PDF

The 5DAW_2 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 5 Watt Power with wide 2:1 Input Voltage Range
  • Very Low Stand-by (no-load) Power Consumption 50mW typ. and 150mW max.
  • High Efficiency up to 86%
  • 5W Single and Dual outputs I/O Isolation 2KVDC, 4KVDC and 6KVDC Option
  • Operating Temperature Range -40°C to +75°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control add Suffix „/CTRL“ Option
  • Pinning Option A, B or C-Pinning

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

5DAW_0503S2 53.3
5DAW_0505D2 55
5DAW_0505S2 55
5DAW_0509D2 59
5DAW_0509S2 59
5DAW_0512D2 512
5DAW_0512S2 512
5DAW_0515D2 515
5DAW_0515S2 515
5DAW_1203S2 123.3
5DAW_1205D2 125
5DAW_1205S2 125
5DAW_1209D2 129
5DAW_1209S2 129
5DAW_1212D2 1212
5DAW_1212S2 1212
5DAW_1215D2 1215
5DAW_1215S2 1215
5DAW_2403S2 243.3
5DAW_2405D2 245
5DAW_2405S2 245
5DAW_2409D2 249
5DAW_2409S2 249
5DAW_2412D2 2412
5DAW_2412S2 2412
5DAW_2415D2 2415
5DAW_2415S2 2415
5DAW_4803S2 483.3
5DAW_4805D2 485
5DAW_4805S2 485
5DAW_4809D2 489
5DAW_4809S2 489
5DAW_4812D2 4812
5DAW_4812S2 4812
5DAW_4815D2 4815
5DAW_4815S2 4815
Details5DAW4_2DIP244:19-36; 18-753.3; 5; 9; 12; 15; ±5; ±9; ±12; ±152; 4; 6••85%-40°C - +100°C

5DAW4_2

Download PDF

The 5DAW4_2 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 5 Watt Power with wide 4:1 Input Voltage Range
  • Very Low Stand-by (no-load) Power Consumption 50mW typ. and 150mW max.
  • High Efficiency up to 86%
  • 5W Single and Dual outputs I/O Isolation 2KVDC, 4KVDC and 6KVDC Option
  • Operating Temperature Range -40°C to +100°C
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control add Suffix „/CTRL“ Option
  • Pinning Option A, B or C-Pinning

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

5DAW4_0503S2 53.3
5DAW4_0505D2 55
5DAW4_0505S2 55
5DAW4_0509D2 59
5DAW4_0509S2 59
5DAW4_0512D2 512
5DAW4_0512S2 512
5DAW4_0515D2 515
5DAW4_0515S2 515
5DAW4_1203S2 123.3
5DAW4_1205D2 125
5DAW4_1205S2 125
5DAW4_1209D2 129
5DAW4_1209S2 129
5DAW4_1212D2 1212
5DAW4_1212S2 1212
5DAW4_1215D2 1215
5DAW4_1215S2 1215
5DAW4_2403S2 243.3
5DAW4_2405D2 245
5DAW4_2405S2 245
5DAW4_2409D2 249
5DAW4_2409S2 249
5DAW4_2412D2 2412
5DAW4_2412S2 2412
5DAW4_2415D2 2415
5DAW4_2415S2 2415
5DAW4_4803S2 483.3
5DAW4_4805D2 485
5DAW4_4805S2 485
5DAW4_4809D2 489
5DAW4_4809S2 489
5DAW4_4812D2 4812
5DAW4_4812S2 4812
5DAW4_4815D2 4815
5DAW4_4815S2 4815
Details5TAW_1.5SMD242:19-18; 18-36; 36-725; 12; 15; ±5; ±12; ±151.5••85%-40°C - +85°C

5TAW_1.5

Download PDF

The 5TAW_1.5 series offers 5W of output. with

  • 2:1 wide input voltage of 9-18VDC. 18-36VDC. 36-72VDC
  • 1500VDC isolation.
  • over current protection
  • over voltage protection
  • short-circuit protection

All models are particularly suited to industrial. tele-communications. test equipments power.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

5TAW_1205D1.5 125
5TAW_1205S1.5 125
5TAW_1212D1.5 1212
5TAW_1212S1.5 1212
5TAW_1215D1.5 1215
5TAW_1215S1.5 1215
5TAW_2405D1.5 245
5TAW_2405S1.5 245
5TAW_2412D1.5 2412
5TAW_2412S1.5 2412
5TAW_2415D1.5 2415
5TAW_2415S1.5 2415
5TAW_4805D1.5 485
5TAW_4805S1.5 485
5TAW_4812D1.5 4812
5TAW_4812S1.5 4812
5TAW_4815D1.5 4815
5TAW_4815S1.5 4815


6 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details6S8W4_3RPRSIP84:19-36; 18-723.3; 5; 9; 12; 15; 24; ±5; ±12; ±153••87%-40°C - +85°C

6S8W4_3RPR

Download PDF

The 6S8W4_3 Series is an excellent performance and high power density design, with high isolation.

Features:

  • SIP8 package (L x W x H) 21.85 x 9.20 x 10.6 mm
  • Wide 4:1 input voltage ranges
  • Highest power density
  • Operating temperature -40°C to +85°C
  • Isolation Voltage 3000VDC
  • High Efficiency up to 88%
  • Short circuit protection (SCP) (automatic recovery)
  • External On/Off control
  • Internal SMD construction
  • RoHS Compliance
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6S8W1_1.5RPSIP82:14.5-9; 9-18; 18-36; 36-753.3; 5; 9; 12; 15; 24; ±5; ±12; ±151.6••87%-40°C - +85°CUL62368

6S8W1_1.5RP

Download PDF

The 6S8W_1.6 Series is an excellent performance and high power density design. The highest efficiency allows high operating temperatures up to 105°C.

Features:

  • SIP8 package (L x W x H) 22.0 x 9.5 x 12.0 mm
  • Wide 2:1 input voltage ranges
  • Highest power density
  • Operating temperature -40°C to +105°C
  • Isolation Voltage 1600VDC
  • High Efficiency up to 87%
  • Short circuit protection (SCP) (automatic recovery)
  • External On/Off control
  • Meets UL62368, EN62368 standards (pending)
  • Internal SMD construction
  • RoHS Compliance
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6S8W_3RPSIP82:14.5-9; 9-18; 18-36; 36-755; 9; 12; 15; ±5; ±12; ±153••88%-40°C - +85°CUL60950

6S8W_3RP

Download PDF

The 6S8W_3RP series is an excellent performance and high power density design. The highest efficiency allows high operating temperatures.The very low stand-by (no-load) input power consumption 50mW typ,makes them an ideal solution for application in battery-powered equipment and instrumentation.

Features:

  • SIP8 package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Wide 2:1 input voltage ranges
  • Highest power density
  • Operating temperature -40°C to +85°C
  • Isolation Voltage 3000VDC
  • High Efficiency up to 88%
  • Short circuit protection (SCP) (automatic recovery)
  • External On/Off control
  • Internal SMD construction
  • RoHS Compliance
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

6S8W_0503S3RP 53.3
6S8W_0505D3RP 55
6S8W_0505S3RP 55
6S8W_0509S3RP 59
6S8W_0512D3RP 512
6S8W_0512S3RP 512
6S8W_0515D3RP 515
6S8W_0515S3RP 515
6S8W_1203S3RP 123.3
6S8W_1205D3RP 125
6S8W_1205S3RP 125
6S8W_1209S3RP 129
6S8W_1212D3RP 1212
6S8W_1212S3RP 1212
6S8W_1215D3RP 1215
6S8W_1215S3RP 1215
6S8W_2403S3RP 243.3
6S8W_2405D3RP 245
6S8W_2405S3RP 245
6S8W_2409S3RP 249
6S8W_2412D3RP 2412
6S8W_2412S3RP 2412
6S8W_2415D3RP 2415
6S8W_2415S3RP 2415
6S8W_4803S3RP 483.3
6S8W_4805D3RP 485
6S8W_4805S3RP 485
6S8W_4809S3RP 489
6S8W_4812D3RP 4812
6S8W_4812S3RP 4812
6S8W_4815D3RP 4815
6S8W_4815S3RP 4815
Details6S8W4_1.5RPSIP84:19-36; 18-723.3; 5; 9; 12; 15; 24; ±5; ±12; ±151.5 ••88%-40°C - +85°C

6S8W4_1.5RP

Download PDF

The 6S8W4_1.5 Series is an excellent performance and high power density design. The highest efficiency allows high operating temperatures up to 85°C.

Features:

  • SIP8 package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Wide 4:1 input voltage ranges
  • Highest power density
  • Operating temperature -40°C to +85°C
  • Isolation Voltage 1500VDC
  • High Efficiency up to 88%
  • Short circuit protection (SCP) (automatic recovery)
  • External On/Off control
  • Internal SMD construction
  • RoHS Compliance
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

6S8W4_2403S1.5RP 243.3
6S8W4_2405D1.5RP 245
6S8W4_2405S1.5RP 245
6S8W4_2409S1.5RP 249
6S8W4_2412D1.5RP 2412
6S8W4_2412S1.5RP 2412
6S8W4_2415D1.5RP 2415
6S8W4_2415S1.5RP 2415
6S8W4_2415S1.5RP 2415
6S8W4_4803S1.5RP 483.3
6S8W4_4805D1.5RP 485
6S8W4_4805S1.5RP 485
6S8W4_4809S1.5RP 489
6S8W4_4812D1.5RP 4812
6S8W4_4812S1.5RP 4812
6S8W4_4815D1.5RP 4815
6S8W4_4815S1.5RP 4815
6S8W4_4815S1.5RP 4815
Details6S8W10_1.5RPSIP810:16-603.3; 5; 9; 12; 15;241.6••87%-40°C - +85°C

6S8W10_1.5RP

Download PDF

The 6S8W10_1.5RP Series is an excellent performance and high power density design. The highest efficiency allows high operating temperatures up to 105°C.

Features:

  • 6 Watt SIP8 package (L x W x H) 21.80 x 9.20 x 11.0 mm
  • Wide 10:1 input voltage ranges
  • Highest power density
  • Operating temperature -40°C to +85°C
  • Isolation Voltage 1500VDC
  • High Efficiency up to 88%
  • Short circuit protection (SCP) (automatic recovery)
  • External On/Off control
  • Internal SMD construction
  • RoHS Compliance
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6DAW_1.5RDIP242:19-18; 18-36; 36-725; 9; 12; 15; 24; ±9; ±12; ±15; ±241.5••87%-40°C - +85°C

6DAW_1.5R

Download PDF

The 6DAW_1.5 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • Efficiency up to 89%
  • 2:1 wide input voltage range
  • 1.5KVDC input/output isolation
  • Short circuit protection (SCP), automatic recovery
  • Operating temperature: -40°C ~ +85°C
  • Output over-voltage protection
  • Low ripple & noise
  • Meet CISPR22/EN55022 CLASS A
  • International standard pin-out
  • Design Meet EN60950

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6DM1W4_1.5R1“x1“4:19-36; 18-753.3; 5; 9; 12; 15; 24; ±5; ±12; ±15; ±241.5••87%-40°C - +85°C

6DM1W4_1.5R

Download PDF

The 6DMW_1.5 series products are of 6W output power, wide range of voltage input of 9-18VDC, 18-36VDC, isolation voltage of 1500VDC, output over-voltage protection and output short circuit protection with the bare component in compliance with CISPR22/EN55022 CLASS A; these products are widely used in fields such as Medical care, industrial control, electric power, instruments and communication.

Features:

  • 6 Watt Power in 1"x1" case (L x W x H) 25.4 x 25.4 x 11.7 mm
  • Efficiency up to 87%
  • 2:1 wide input voltage range
  • 1.5KVDC input/output isolation
  • Continuous short circuit protection (SCP)
  • No-load power consumption as low as 0.12W
  • Operating temperature: -40°C ~ +85°C
  • Input under-voltage protection
  • Output over-voltage protection
  • Output over-current protection
  • Meet CISPR22/EN55022 CLASS A
  • International standard pin-out
  • Design meets UL60950 , EN60950 and IEC60950

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6DM1W4_3R1“x1“4:19-36; 18-753.3; 5; 9; 12; 15; 24; ±5; ±12; ±15; ±243••87%-40°C - +85°C

6DM1W4_3R

Download PDF

The 6DMW_1.5 series products are of 6W output power, wide range of voltage input of 9-18VDC, 18-36VDC, isolation voltage of 1500VDC, output over-voltage protection and output short circuit protection with the bare component in compliance with CISPR22/EN55022 CLASS A; these products are widely used in fields such as Medical care, industrial control, electric power, instruments and communication.

Features:

  • 6 Watt Power in 1"x1" case (L x W x H) 25.4 x 25.4 x 11.7 mm
  • Efficiency up to 87%
  • 2:1 wide input voltage range
  • 1.5KVDC input/output isolation
  • Continuous short circuit protection (SCP)
  • No-load power consumption as low as 0.12W
  • Operating temperature: -40°C ~ +85°C
  • Input under-voltage protection
  • Output over-voltage protection
  • Output over-current protection
  • Meet CISPR22/EN55022 CLASS A
  • International standard pin-out
  • Design meets UL60950 , EN60950 and IEC60950

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6DMW_1.5R1“x1“2:19-18; 18-365; 12; 15; 24; ±5; ±12; ±151.5••87%-40°C - +85°C

6DMW_1.5R

Download PDF

The 6DMW_1.5 series products are of 6W output power, wide range of voltage input of 9-18VDC, 18-36VDC, isolation voltage of 1500VDC, output over-voltage protection and output short circuit protection with the bare component in compliance with CISPR22/EN55022 CLASS A; these products are widely used in fields such as Medical care, industrial control, electric power, instruments and communication.

Features:

  • 6 Watt Power in 1"x1" case (L x W x H) 25.4 x 25.4 x 11.7 mm
  • Efficiency up to 87%
  • 2:1 wide input voltage range
  • 1.5KVDC input/output isolation
  • Continuous short circuit protection (SCP)
  • No-load power consumption as low as 0.12W
  • Operating temperature: -40°C ~ +85°C
  • Input under-voltage protection
  • Output over-voltage protection
  • Output over-current protection
  • Meet CISPR22/EN55022 CLASS A
  • International standard pin-out
  • Design meets UL60950 , EN60950 and IEC60950

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6DMW4_1.5R1“x1“4:19-36; 18-755; 9; 12; 15; 24; ±5; ±12; ±15; ±241.5••88%-40°C - +85°C

6DMW4_1.5R

Download PDF

The 6DMW4_1.5 series products are of 6W output power, wide range of voltage input of 9-36VDC, 18-75VDC, isolation voltage of 1500VDC, output over-voltage protection and output short circuit protection with the bare component in compliance with CISPR22/EN55022 CLASS A; these products are widely used in fields such as Medical care, industrial control, electric power, instruments and communication.

Features:

  • 6 Watt Power in 1"x1" case (L x W x H) 25.4 x 25.4 x 11.7 mm
  • Efficiency up to 88%
  • 4:1 wide input voltage range
  • 1.5KVDC input/output isolation
  • Continuous short circuit protection (SCP)
  • No-load power consumption as low as 0.12W
  • Operating temperature: -40°C ~ +85°C
  • Input under-voltage protection
  • Output over-voltage protection
  • Output over-current protection
  • Meet CISPR22/EN55022 CLASS A
  • International standard pin-out
  • Design meets UL60950 , EN60950 and IEC60950

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6DAW4_1.5RDIP244:14.5-18; 9-36; 18-723.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±241.5••88%-40°C - +85°C

6DAW4_1.5R

Download PDF

The 6DAW4_3 series are specially designed for applications where a wide

range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • High Efficiency up to 86% size (L x W x H) 32,0 x 20,0 x 10,8mm
  • Operating Temperature: -40°C to +85°C
  • Wide input voltage range (4:1)
  • 3KVDC Input/Output Isolation
  • Short Circuit Protection (SCP)
  • No-load power consumption as low as 0.12W
  • Over-voltage protection
  • Over-current protection
  • Input under-voltage protection
  • Meet CISPR22/EN55022 CLASS A
  • Industry standard pin-out
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6DAW4_3RDIP244:19-36; 18-723.3; 5; 9; 12; 15; 24; ±5; ±12; ±153••88%-40°C - +85°C

6DAW4_3R

Download PDF

The 6DAW4_3 series are specially designed for applications where a wide

range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • High Efficiency up to 86% size (L x W x H) 32,0 x 20,0 x 10,8mm
  • Operating Temperature: -40°C to +85°C
  • Wide input voltage range (4:1)
  • 3KVDC Input/Output Isolation
  • Short Circuit Protection (SCP)
  • No-load power consumption as low as 0.12W
  • Over-voltage protection
  • Over-current protection
  • Input under-voltage protection
  • Meet CISPR22/EN55022 CLASS A
  • Industry standard pin-out
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details6DAMW4_6DIP244:19-36; 18-755; 12; 15; ±5; ±12; ±156••85%-40°C - +85°C

6DAMW4_6

Download PDF

The 6DAMW4_6 series are specially designed for applications where a wide

range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • High Efficiency up to 88% - size (L x W x H) 32,0 x 20,0 x 10,8mm
  • Operating Temperature: -40°C to +85°C
  • 6KVDC Input/Output Isolation
  • 2 x MOPP [Re-inforced isolation]
  • Short Circuit Protection SCP (Automatic recovery)
  • No-load power consumption as low as 0.12W
  • Over-voltage protection
  • Over-current protection
  • Input under-voltage protection
  • Meet CISPR32/EN55032 CLASS A
  • EN60601-1 (3rd edition medical grade)
  • UL60601-1 (pending)
  • Industry standard pin-out
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

6DAMW4_2405S6 245
6DAMW4_2406S6 246.5
6DAMW4_2409S6 249
6DAMW4_2412S6 2412
6DAMW4_2415S6 2415
6DAMW4_2418S6 2418
6DAMW4_2424S6 2424
6DAMW4_4805S6 485
6DAMW4_4809S6 489
6DAMW4_4812S6 4812
6DAMW4_4815S6 4815
6DAMW4_4824S6 4824


7.5 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details7.5DAW_2DIP242:19-18; 18-36; 36-753.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±24 2; 3••87%-40°C - +100°C

7.5DAW_2

Download PDF

The 7.5DAW_2 & 7.5DAW_3 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP24 Package (L x W x H) 32.0 x 20.3 x 10.2 mm
  • 7.5W Single and Dual outputs
  • Operating temperature -40°C - 100°C
  • Wide 2:1 Input Voltage Range
  • 5 Side Shielded Metal Case
  • High Efficiency up to 87%
  • I/O Isolation 2KVDC and 3KVDC Version
  • Operating Temperature Range -40°C to +100°C (with derating)
  • Continuous Short Circuit Protection (SCP)
  • Remote ON/OFF Control option
  • Pinning Option A, B or C-pinning

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

7.5DAW_1203S2 123.3
7.5DAW_1205D2 125
7.5DAW_1205S2 125
7.5DAW_1209D2 129
7.5DAW_1209S2 129
7.5DAW_1212D2 1212
7.5DAW_1212S2 1212
7.5DAW_1215D2 1215
7.5DAW_1215S2 1215
7.5DAW_1224D2 1224
7.5DAW_1224S2 1224
7.5DAW_2403S2 243.3
7.5DAW_2405D2 245
7.5DAW_2405S2 245
7.5DAW_2409D2 249
7.5DAW_2409S2 249
7.5DAW_2412D2 2412
7.5DAW_2412S2 2412
7.5DAW_2415D2 2415
7.5DAW_2415S2 2415
7.5DAW_2424D2 2424
7.5DAW_2424S2 2424
7.5DAW_4803S2 483.3
7.5DAW_4805D2 485
7.5DAW_4805S2 485
7.5DAW_4809D2 489
7.5DAW_4809S2 489
7.5DAW_4812D2 4812
7.5DAW_4812S2 4812
7.5DAW_4815D2 4815
7.5DAW_4815S2 4815
7.5DAW_4824D2 4824
7.5DAW_4824S2 4824


8 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details8DPW_1.6DIP242:14.5-9; 9-18; 18-36; 36-723.3; 5; 12; 15; ±5; ±12; ±15 1.6••86%-40°C - +85°C

8DPW_1.6

Download PDF

The 8DPW_1.6 Series are isolated 8W DC/DC converters. Designed with high efficiency in a 24 pin DIP package with industry-standard footprint.

Further features include:

  • DIP24 Package (L x W x H) 31.6 x 20.1 x 10.0 mm
  • Operating temperature: -40°C to +85°C
  • 1600Vdc isolation
  • 100% Burned IN
  • Wide 2:1 input voltage range
  • remote on/off control
  • short-circuit protection
  • over voltage protection
  • RoHS compliant

These converters are well suitable for:

  • battery operated equipment
  • measurement equipment
  • telecom
  • wireless network and industry control systems

Everywhere where isolated, tightly regulated voltages and compact size are required.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

8DPW_0512D1.6 512
8DPW_0512S1.6 512
8DPW_0515D1.6 515
8DPW_0515S1.6 515
8DPW_1203S1.6 123.3
8DPW_1205D1.6 125
8DPW_1205S1.6 125
8DPW_1212D1.6 1212
8DPW_1212S1.6 1212
8DPW_1215D1.6 1215
8DPW_1215S1.6 1215
8DPW_2403S1.6 243.3
8DPW_2405D1.6 245
8DPW_2405S1.6 245
8DPW_2412D1.6 2412
8DPW_2412S1.6 2412
8DPW_2415D1.6 2415
8DPW_2415S1.6 2415
8DPW_4803S1.6 483.3
8DPW_4805D1.6 485
8DPW_4805S1.6 485
8DPW_4812D1.6 4812
8DPW_4812S1.6 4812
8DPW_4815S1.6 4815
Details8DPW4_1.6DIP244:19-36; 18-753.3; 5; 12; 15; ±5; ±12; ±15 1.6••86%-40°C - +85°C

8DPW4_1.6

Download PDF

The 8DPW4_1.6 Series are isolated 8W DC/DC converters. Designed with high efficiency in a 24 pin DIP package with industry-standard footprint.

Further features include:

  • DIP24 Package (L x W x H) 31.6 x 20.1 x 10.0 mm
  • Operating temperature: -40°C to +85°C
  • Wide 4:1 input voltage range
  • 100% Burned IN
  • remote on/off control
  • short-circuit protection
  • over voltage protection
  • RoHS compliant

These converters are well suitable for:

  • battery operated equipment
  • measurement equipment
  • telecom
  • wireless network and industry control systems

Everywhere where isolated. tightly regulated voltages and compact size are required.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

8DPW4_2403S1.6 243.3
8DPW4_2405D1.6 245
8DPW4_2405S1.6 245
8DPW4_2412D1.6 2412
8DPW4_2412S1.6 2412
8DPW4_2415D1.6 2415
8DPW4_2415S1.6 2415
8DPW4_4803S1.6 483.3
8DPW4_4805D1.6 485
8DPW4_4805S1.6 485
8DPW4_4812D1.6 4812
8DPW4_4812S1.6 4812
8DPW4_4815S1.6 4815
Details8DPRW4_3DIP244:113-70; 42-1763.3; 5; 12; 15; ±5; ±12; ±15 3••86%-40°C - +85°CEN50155

8DPRW4_3

Download PDF

The 8DPRW4_3 Series are isolated 8W DC/DC converters. Designed with high efficiency in a 24 pin DIP package with industry-standard footprint.

Further features include:

  • DIP24 Package (L x W x H) 31.8 x 20.3 x 10.2 mm
  • Operating temperature: -40°C to +85°C
  • Wide 4:1 input voltage range
  • 3KV Isolation
  • 100% Burned IN
  • remote on/off control
  • short-circuit protection
  • over voltage protection
  • under voltage lock-out circuit
  • over load protection
  • EN50155 approval for railway applications
  • RoHS compliant

These converters are well suitable for:

  • railway applications

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

8DPRW4_11003D3 110
8DPRW4_11003S3 110
8DPRW4_11005D3 110
8DPRW4_11005S3 110
8DPRW4_11012S3 111
8DPRW4_11015S3 111
8DPRW4_2403D3 243.3
8DPRW4_2403S3 243.3
8DPRW4_2405D3 245
8DPRW4_2405S3 245
8DPRW4_2412D3 2412
8DPRW4_2412S3 2412
8DPRW4_2415D3 2415
8DPRW4_2415S3 2415


9 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details9S8W4E_1.6RPSIP84:19-36; 18-753.3; 5; 9; 12; 15; 24; ±5; ±12; ±151.6••89%-40°C - +100°C

9S8W4E_1.6RP

Download PDF

The 9S8W4E_ cost effective series is an excellent performance and high power density design with wide range devices operate over 4:1 input voltage range.

Features:

  • SIP8 package (L x W x H) 21.8 x 9.2 x 11.1 mm
  • Wide 4:1 input voltage ranges
  • Highest power density
  • Plastic Case [UL94-V0]
  • Operating temperature -40°C to +100°C (with derating)
  • Isolation Voltage 1600VDC
  • High Efficiency up to 89%
  • Short circuit protection (SCP) (automatic recovery)
  • External On/Off control
  • Internal SMD construction
  • RoHS Compliance
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

9S8W4E_2403S1.6RP 243.3
9S8W4E_2405D1.6RP 245
9S8W4E_2405S1.6RP 245
9S8W4E_2409S1.6RP 249
9S8W4E_2412D1.6RP 2412
9S8W4E_2412S1.6RP 2412
9S8W4E_2415D1.6RP 2415
9S8W4E_2415S1.6RP 2415
9S8W4E_2424S1.6RP 2424
9S8W4E_4803S1.6RP 483.3
9S8W4E_4805D1.6RP 485
9S8W4E_4805S1.6RP 485
9S8W4E_4809S1.6RP 489
9S8W4E_4812D1.6RP 4812
9S8W4E_4812S1.6RP 4812
9S8W4E_4815D1.6RP 4815
9S8W4E_4815S1.6RP 4815
9S8W4E_4824S1.6RP 4824


10 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details10S8W4_2.25RPSIP84:19-36; 18-753.3; 5; 9; 12; 15; 242.25••88%-40°C - +85°C

10S8W4_2.25RP

Download PDF

The 10S8W4_2.25RP series is an excellent performance and high power density design with wide range devices operate over 2:1 input voltage range.

Features:

  • 10 Watt SIP8 package (L x W x H) 22.00 x 9.50 x 12.20 mm
  • Wide 4:1 input voltage ranges
  • Highest power density
  • Plastic Case [UL94-V0]
  • Operating temperature -40°C to +85°C (with derating)
  • Isolation Voltage 2250VDC
  • High Efficiency up to 88%
  • Short circuit protection (SCP) (automatic recovery)
  • External On/Off control
  • Internal SMD construction
  • RoHS Compliance
  • Internal PI-Filtering

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

Details10DPW4_1.5RDIP244:19-36; 18-753.3; 5; 12; 151.5••83%-40°C - +85°C

10DPW4_1.5R

Download PDF

The 10DPWE_1.5 Series are isolated 10W DC/DC converters. Designed with high efficiency in a 24 pin DIP package with industry-standard footprint.

Further features include:

  • DIP24 Package (L x W x H) 32.00 x 20.00 x 10.80 mm
  • Operating temperature: -40°C to +85°C
  • 1500Vdc isolation
  • Efficiency 88%
  • Wide 2:1 input voltage range
  • remote on/off control
  • short-circuit protection
  • over voltage protection
  • RoHS compliant

These converters are well suitable for:

  • battery operated equipment
  • measurement equipment
  • telecom
  • wireless network and industry control systems

Everywhere where isolated, tightly regulated voltages and compact size are required.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details10DPW_1.5RDIP242:19-18; 18-36; 36-753.3; 5; 12; 15; 24; ±5; ±12; ±151.5••83%-40°C - +85°C

10DPW_1.5R

Download PDF

The 10DPWE_1.5 Series are isolated 10W DC/DC converters. Designed with high efficiency in a 24 pin DIP package with industry-standard footprint.

Further features include:

  • DIP24 Package (L x W x H) 32.00 x 20.00 x 10.80 mm
  • Operating temperature: -40°C to +85°C
  • 1500Vdc isolation
  • Efficiency 88%
  • Wide 2:1 input voltage range
  • remote on/off control
  • short-circuit protection
  • over voltage protection
  • RoHS compliant

These converters are well suitable for:

  • battery operated equipment
  • measurement equipment
  • telecom
  • wireless network and industry control systems

Everywhere where isolated, tightly regulated voltages and compact size are required.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details10DMWE4_1.51“x1“4:19-36; 18-753.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±241.5••88%-40°C - +85°CUL60950

10DMWE4_1.5

Download PDF

The 10DMW4_1.5 series products are of 10W output power, wide range of voltage,isolation voltage of 1500VDC, output over-voltage protection and output short circuit protection with the bare component in compliance with CISPR22/EN55022 CLASS A; these products are widely used in fields such as Medical care, industrial control, electric power, instruments and communication.

Features:

  • 10 Watt Power in 1"x 1" case (L x W x H) 25.40 x 25.40 x 11.70 mm
  • Efficiency up to 88%
  • 4:1 wide input voltage range
  • 1.5KVDC input/output isolation
  • Efficiency up to 90%
  • Continuous short circuit protection (SCP)
  • No-load power consumption as low as 0.12W
  • Operating temperature: -40°C ~ +100°C
  • Remote On/Off

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details10D16W4_1.6RPDIP164:19-36; 18-753.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±241.5••88%-40°C - +85°CUL62368

10D16W4_1.6RP

Download PDF

The 10D16W4_1.6RP series, are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP16 Package (L x w x H) 24.00 x 14.00 x 9.50 mm
  • 4:1 wide input voltage range
  • Efficiency up to 88%
  • 1.6KVDC isolation
  • Short circuit protection (SCP)
  • Output over voltage protection
  • Output over current protection
  • Operating Temperature range: -40°C ~ +91°C
  • International standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details10D16W4_3RPDIP164:19-36; 18-753.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±241.5••88%-40°C - +85°CUL60950

10D16W4_3RP

Download PDF

The 10D16W4_3RP series, are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP16 Package (L x w x H) 24.00 x 14.00 x 9.50 mm
  • 4:1 wide input voltage range
  • Efficiency up to 88%
  • 3KVDC isolation
  • Short circuit protection (SCP)
  • Output over voltage protection
  • Output over current protection
  • Operating Temperature range: -40°C ~ +91°C
  • International standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details10DAW_1.5R2“x1“2:19-18; 18-36; 36-723.3; 5; 12; 15; 24; ±5; ±12; ±15; ±241.5••88%-40°C - +85°C

10DAW_1.5R

Download PDF

The 10DAW_1.5R series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 2:1 wide input voltage range
  • Efficiency up to 90%
  • Output over voltage protection
  • 1.5KVDC input/output Isolation
  • Short circuit protection (SCP) (automatic recovery)
  • Operating temperature: -40°C to +85°C
  • Six-sided metal shield
  • Industry standard pinout
  • Low ripple & noise
  • Meet CISPR22/EN55022 CLASS A
  • RoHS Compliance

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details10DAW4_1.5R2“x1“4:19-36; 18-753.3; 5; 12; 15; 24; ±5; ±12; ±15 1.5••87%-40°C - +85°C

10DAW4_1.5R

Download PDF

The 10DAW4_1.5 series, with wide input of 9-36VDC and 18-75VDC, are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 4:1 wide input voltage range
  • Efficiency up to 88%
  • 1.5KVDC isolation
  • Short circuit protection (SCP)
  • Output over voltage protection
  • Operating Temperature range: -40°C ~ +85°C
  • Six-sided metal shield
  • Industry standard pinout
  • Low ripple & noise
  • Meet CISPR22 / EN55022 CLASS A
  • Inverse polarity protection for chassis mounting and DIN-Rail mounting

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



12 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details12DPW_1.5DIP242:19-18; 18-36; 36-753.3; 5; 12; 15; ±5; ±12; ±15 1.5••83%-40°C - +85°C

12DPW_1.5

Download PDF

The 12DPW_1.5 Series are isolated 12W DC/DC converters. Designed with high efficiency. they allow the operating temperature range of these units to be -40°C to +85°C in a 24 pin DIP package with industry-standard footprint. Further features include wide 2:1 input voltage range. remote on/off control. short-circuit protection and over voltage protection. These converters are well suitable for battery operated equipment. measurement equipment. telecom. wireless network and industry control systems. Everywhere where isolated. tightly regulated voltages and compact size are required.

  • Wide 2:1 input voltage range
  • Input/Output Isolation Voltage: 1.5KVDC
  • Operating Temperature Range: -40°C to +85°C
  • Short circuit protection (SCP)
  • Remote On/Off
  • High efficiency 12W DIL package
  • Meet EN55022. Class A (Radiation)
  • Shielded Metal Case with Insulated Baseplate
  • Lead Free Design. RoHS Compliant
  • 24pin DIP Package with Industry-Standard Footprint
  • Customer Design Available



Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

12DPW_1203S1.5 123.3
12DPW_1205D1.5 125
12DPW_1205S1.5 125
12DPW_1212D1.5 1212
12DPW_1212S1.5 1212
12DPW_1215D1.5 1215
12DPW_1215S1.5 1215
12DPW_2403S1.5 243.3
12DPW_2405D1.5 245
12DPW_2405S1.5 245
12DPW_2412S1.5 2412
12DPW_2412S1.5 2412
12DPW_2415D1.5 2415
12DPW_2415S1.5 2415
12DPW_4803S1.5 483.3
12DPW_4805D1.5 485
12DPW_4805S1.5 485
12DPW_4812D1.5 4812
12DPW_4812S1.5 4812
12DPW_4815D1.5 4815
12DPW_4815D1.5 4815
Details12DPW4_1.5DIP244:19-36; 18-753.3; 5; 12; 15; ±5; ±12; ±15 1.5••83%-40°C - +85°C

12DPW4_1.5

Download PDF

The 12DPW4_1.5 Series are isolated 12W DC/DC converters. Designed with high efficiency. they allow the operating temperature range of these units to be -40°C to +85°C in a 24 pin DIP package with industry-standard footprint. Further features include wide 2:1 input voltage range. remote on/off control. short-circuit protection and over voltage protection. These converters are well suitable for battery operated equipment. measurement equipment. telecom. wireless network and industry control systems. Everywhere where isolated. tightly regulated voltages and compact size are required.

  • Wide 4:1 input voltage range
  • Input/Output Isolation Voltage: 1.5KVDC
  • Operating Temperature Range: -40°C to +85°C
  • Short circuit protection (SCP)
  • Remote On/Off
  • High efficiency 12W DIL package
  • Meet EN55022. Class A (Radiation)
  • Shielded Metal Case with Insulated Baseplate
  • Lead Free Design. RoHS
  • Compliant 24pin DIP Package with Industry-Standard Footprint
  • Customer Design Available

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

12DPW4_2403S1.5 243.3
12DPW4_2405D1.5 245
12DPW4_2405S1.5 245
12DPW4_2412D1.5 2412
12DPW4_2412S1.5 2412
12DPW4_2415D1.5 2415
12DPW4_2415S1.5 2415
12DPW4_4803S1.5 483.3
12DPW4_4805D1.5 485
12DPW4_4805S1.5 485
12DPW4_4812D1.5 4812
12DPW4_4812S1.5 4812
12DPW4_4815D1.5 4815
12DPW4_4815S1.5 4815


15 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details15D16W4_1.6RPDIP164:19-36; 18-753.3; 5; 12; 151.5••89%-40°C - +85°C

15D16W4_1.6RP

Download PDF

The 15D16W4_1.6RP series, are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • DIP16 Package (L x w x H) 24.00 x 14.00 x 9.50 mm
  • 4:1 wide input voltage range
  • Efficiency up to 88%
  • 1.6KVDC isolation
  • Short circuit protection (SCP)
  • Output over voltage protection
  • Output over current protection
  • Operating Temperature range: -40°C ~ +84°C
  • International standard pinout

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details15DPW_1.6DIP242:19-18; 18-36; 36-753.3; 5; 12; 15; ±5; ±12; ±151.6••90%-40°C - +85°C

15DPW_1.6

Download PDF

The 15DPW_1.6 series are high performance 15W single & dual output DC-DC converters. These converters are consisted with

nickle-coated copper DIP package with high performance features such as synchronis rectfication and tight line load regulation.

 Features:

  • DIP24 Package (L x W x H) 31.8 x 15.24 x 10.2 mm
  • Wide 2:1 Input
  • Efficiency up to 91%
  • Operating Temperature Range -40°C to +85°C
  • No Minimum Load Required
  • Over Voltage Protection
  • Remote On/Off
  • Built-in EMC filter meets EN55022 class A without external components

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

15DPW_1203S1.6 123.3
15DPW_1205D1.6 125
15DPW_1205S1.6 125
15DPW_1212D1.6 1212
15DPW_1212S1.6 1212
15DPW_1215D1.6 1215
15DPW_1215S1.6 1215
15DPW_2403S1.6 243.3
15DPW_2405D1.6 245
15DPW_2405S1.6 245
15DPW_2412D1.6 2412
15DPW_2412S1.6 2412
15DPW_2415D1.6 2415
15DPW_2415S1.6 2415
15DPW_4803S1.6 483.3
15DPW_4805D1.6 485
15DPW_4805S1.6 485
15DPW_4812D1.6 4812
15DPW_4812S1.6 4812
15DPW_4815D1.6 4815
15DPW_4815S1.6 4815
Details15DPW4_1.6DIP244:19-36; 18-753.3; 5; 12; 15; ±5; ±12; ±151.6••90%-40°C - +85°C

15DPW4_1.6

Download PDF

The 15DPW_1.6 series are high performance 15W single & dual output DC-DC converters. These converters are consisted with

nickle-coated copper DIP package with high performance features such as synchronis rectfication and tight line load regulation.

 Features:

  • DIP24 Package (L x W x H) 31.8 x 15.24 x 10.2 mm
  • Wide 4:1 Input
  • Efficiency up to 91%
  • Operating Temperature Range -40°C to +85°C
  • No Minimum Load Required
  • Over Voltage Protection
  • Remote On/Off
  • Built-in EMC filter meets EN55022 class A without external components

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details15DMWE4_1.5R1“x1“4:19-36; 18-753.3; 5; 12; 15; 24; ±5; ±10; ±12; ±15; ±241.5••89%-40°C - +85°C

15DMWE4_1.5R

Download PDF

The 15DMW_1.5 series are isolated 15W DC/DC converters. Designed with high efficiency. they allow the operating temperature range of these units to be -40°C to +85°C (with derating) with industry-standard footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 10.1 mm
  • wide 2 : 1 input voltage range
  • remote on/off control
  • trimmable output
  • shortcircuit protection
  • over voltage protection

These converters are well suitable for:

  • Battery operated equipment
  • Measurement equipment
  • Telecom
  • Wireless network
  • Industry control system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details15DMWE_1.5R1“x1“2:19-18; 18-36; 36-753.3; 5; 12; 15; 24; 48; ±5; ±12; ±151.5••89%-40°C - +85°C

15DMWE_1.5R

Download PDF

The 15DMW_1.5 series are isolated 15W DC/DC converters. Designed with high efficiency. they allow the operating temperature range of these units to be -40°C to +85°C (with derating) with industry-standard footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 10.1 mm
  • wide 2 : 1 input voltage range
  • remote on/off control
  • trimmable output
  • shortcircuit protection
  • over voltage protection

These converters are well suitable for:

  • Battery operated equipment
  • Measurement equipment
  • Telecom
  • Wireless network
  • Industry control system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details15DMOW4_1.51“x1“4:118-753.3; 121.5••88,5%-40°C - +85°C

15DMOW4_1.5

Download PDF

The 15DMOW4_S1.5 series are isolated 15W DC/DC open frame converters. Designed with high efficiency. they allow the operating temperature range of these units to be -40°C to +105°C (with derating) with industry-standard footprint.

Features:

  • Open frame 1"x1"package (L x W x H) 28.8 x 25.4 x 8.70 mm
  • Wide 4 : 1 input voltage range
  • Single output
  • Meet EN55032 Class A without external components
  • Design meet UL60950 standards
  • Over-current, over voltage, under-voltage protection
  • Remote on/off control
  • Trimmable output
  • Short circuit protection

These converters are well suitable for:

  • Distributed Power Architectures
  • Access and Optical Network Equipment
  • Latest generation IC\'s (DSP, FPGA, ASIC)
  • Wireless network
  • Industry control system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

15DMOW4_4803S1.5 483.3
15DMOW4_4812S1.5 4812
Details15DM1WE4_1.51“x1“4:19-36; 18-753.3; 5; 9; 12; 15; 24; ±5; ±12; ±15; ±241.5••88%-40°C - +85°C

15DM1WE4_1.5

Download PDF

The 15DMW4_1.5 series are isolated 15W DC/DC converters. Designed with high efficiency. they allow the operating temperature range of these units to be -40°C to +85°C (with derating) with industry-standard footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 10.1 mm
  • wide 4 : 1 input voltage range
  • remote on/off control
  • trimmable output
  • shortcircuit protection
  • over voltage protection

These converters are well suitable for:

  • Battery operated equipment
  • Measurement equipment
  • Telecom
  • Wireless network
  • Industry control system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details15DAW4_1.5R2“x1“4:19-40; 18-803.3; 5; 9; 12; 15; 24; ±5; ±9; ±12; ±15; ±241.5••90%-40°C - +85°CUL60950

15DAW4_1.5R

Download PDF

The 15DAWE_1.5 series offer 15W of output. with 2:1 wide input voltage of 18-36VDC and 36-75VDC. and features:

  • DIP 2" x 1" case
  • 1500VDC isolation
  • -40°C - +85C
  • over current protection
  • over voltage protection
  • short-circuit protection
  • six sided shielding

All models are particularly suited to industrial. tele-communications. test equipments power.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details15DAWE_1.5R2“x1“2:19-18; 18-36; 36-753.3; 5; 12; 15; ±5; ±12; ±151.5••90%-40°C - +85°CUL60950

15DAWE_1.5R

Download PDF

The 15DAWE_1.5 series offer 15W of output. with 2:1 wide input voltage of 18-36VDC and 36-75VDC. and features:

  • DIP 2" x 1" case
  • 1500VDC isolation
  • -40°C - +85C
  • over current protection
  • over voltage protection
  • short-circuit protection
  • six sided shielding

All models are particularly suited to industrial. tele-communications. test equipments power.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



20 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details20DPEW4_1.6DIP244:19-36; 18-755; 9; 12; 15; ±12; ±151.6••80%-40°C - +87°C

20DPEW4_1.6

Download PDF

The 20PEWE4_1.6 series are isolated cost effective 20W DC/DC converters. Designed with high efficiency and industry-standard 1"x1" footprint.

Features:

  • DIP24 package (L x W x H) 31.6 x 20.1 x 10.0 mm
  • wide 4 : 1 input voltage range
  • 1600VDC
  • Operating temperature range -40°C to 87°C (with derating)
  • remote on/off control
  • short circuit protection (SCP)
  • over voltage protection
  • over-voltage protection
  • under voltage protection

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details20DMWE4_1.5R1“x1“4:19-18; 9-36; 18-753.3; 5; 12; 15; 24; ±12; ±15; ±15 1.5••90%-40°C - +85°C

20DMWE4_1.5R

Download PDF

The 20DMW_1.5 series are isolated 20W DC/DC converters. Designed with high efficiency. they allow the operating temperature range of these units to be -40°C to +85°C (with derating) with industry-standard footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 10.1 mm
  • wide 2 : 1 input voltage range
  • remote on/off control
  • trimmable output
  • shortcircuit protection
  • over voltage protection

These converters are well suitable for:

  • Battery operated equipment
  • Measurement equipment
  • Telecom
  • Wireless network
  • Industry control system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details20DMWE_1.5R1“x1“2:19-18; 18-36; 36-753.3; 5; 12; 15; 24; 48; ±12; ±15; ±15 1.5••90%-40°C - +85°C

20DMWE_1.5R

Download PDF

The 20DMW_1.5 series are isolated 20W DC/DC converters. Designed with high efficiency. they allow the operating temperature range of these units to be -40°C to +85°C (with derating) with industry-standard footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 10.1 mm
  • wide 2 : 1 input voltage range
  • remote on/off control
  • trimmable output
  • shortcircuit protection
  • over voltage protection

These converters are well suitable for:

  • Battery operated equipment
  • Measurement equipment
  • Telecom
  • Wireless network
  • Industry control system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details20DA1W4_51“x1“4:19-36; 18-753.3; 5; 9; 12; 15; 245••89% -40°C - +85°CUL62368

20DA1W4_5

Download PDF

The 20DMWE4_1.5 series are isolated cost effective 20W DC/DC converters. Designed with high efficiency and industry-standard 1"x1" footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 11.7 mm
  • wide 4 : 1 input voltage range
  • 1500VDC
  • Operating temperature range -40°C to 105°C (with derating)
  • remote on/off control
  • trimmable output
  • short circuit protection (SCP)
  • over voltage protection
  • over-voltage protection
  • under voltage protection

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details20DM1W4_31“x1“4:19-36; 18-753.3; 5; 12; 15; 243••90% -40°C - +85°CUL62368

20DM1W4_3

Download PDF

The 20DMWE4_1.5 series are isolated cost effective 20W DC/DC converters. Designed with high efficiency and industry-standard 1"x1" footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 11.7 mm
  • wide 4 : 1 input voltage range
  • 1500VDC
  • Operating temperature range -40°C to 105°C (with derating)
  • remote on/off control
  • trimmable output
  • short circuit protection (SCP)
  • over voltage protection
  • over-voltage protection
  • under voltage protection

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details20DM1WE4_1.51“x1“4:19-36; 18-753.3; 5; 12; 15; 241.5••91% -40°C - +85°CUL62368

20DM1WE4_1.5

Download PDF

The 20DMWE4_1.5 series are isolated cost effective 20W DC/DC converters. Designed with high efficiency and industry-standard 1"x1" footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 11.7 mm
  • wide 4 : 1 input voltage range
  • 1500VDC
  • Operating temperature range -40°C to 105°C (with derating)
  • remote on/off control
  • trimmable output
  • short circuit protection (SCP)
  • over voltage protection
  • over-voltage protection
  • under voltage protection

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details20DAW8_1.62“x1“8:19-755; 9; 12; 15; 24; ±12; ±151.6••91% -40°C - +83°CUL62368

20DAW8_1.6

Download PDF

The 20DAW8_1.6 series offer 20W of output. with 8:1 wide input voltage.

Features:

  • 2"x1"" package (L x W x H) 50.8 x 25,4 x 11.6mm
  • 8:1 input range
  • No-load power consumption 0,15W
  • Operating temperature range: -40°C - 83°C
  • 1600VDC isolation
  • Over current protection
  • Over voltage protection
  • Short-circuit protection
  • Six sided shielding
  • UL62368 approved

All models are are applied to wide voltage range input situation such as:

  • data transmission device
  • battery power supply device
  • telecommunication device
  • distributed power supply system
  • remote control system.
  • industrial robot system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



25 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details25DPEW4_1.6DIP244:19-36; 18-755; 9; 12; 15; ±12; ±151.6••80%-40°C - +87°C

25DPEW4_1.6

Download PDF

The 20DPEW4_1.6 series are isolated cost effective 20W DC/DC converters. Designed with high efficiency and industry-standard DIP24 footprint.

Features:

  • DIP 24 package (L x W x H) 31.6 x 20.1 x 10.5 mm
  • Wide 4 : 1 input voltage range
  • 1600VDC
  • Operating temperature range -40°C to 87°C (with derating)
  • High efficieny up to 91%
  • Remote on/off control
  • Short circuit protection (SCP)
  • Over voltage protection
  • Over-voltage protection
  • Under voltage protection

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details25DMOW_1.515.24 x 19.1mm2:136-7551.5••88%-40°C - +85°CUL60950

25DMOW_1.5

Download PDF

The 25DMOW_1.5 series offer 25W of output. with 2:1 wide input voltage of 36-75VDC

Features:

  • DIP package (L x W x H) 19.1 x 15.24 x 9.0mm
  • 1500VDC isolation
  • Output over-voltage protection
  • Over-current protection
  • Over temperature protection
  • Input under-voltage lockout
  • Control-Pin / Trim-Pin
  • Meet EN55032 CLASS A
  • UL60950 approval
  • Efficiency up to 88%
  • Over current protection
  • Short-circuit protection (SCP)

All models are particularly suited to

  • tele-communications
  • industrial. test equipments power

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

25DMOW_4805S1.5 485
Details25TMOW_1.515.24 x 19.1mm2:136-7551.5••88%-40°C - +85°CUL60950

25TMOW_1.5

Download PDF

The 25TMOW_1.5 series offer 25W of output. with 2:1 wide input voltage of 36-75VDC

Features:

  • SMD package (L x W x H) 19.1 x 15.24 x 9.0mm
  • 1500VDC isolation
  • Output over-voltage protection
  • Over-current protection
  • Over temperature protection
  • Input under-voltage lockout
  • Control-Pin / Trim-Pin
  • Meet EN55032 CLASS A
  • UL60950 approval
  • Efficiency up to 88%
  • Over current protection
  • Short-circuit protection (SCP)

All models are particularly suited to

  • tele-communications
  • industrial. test equipments power

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

25TMOW_4805S1.5 485


30 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details30TB16FW_1.51/16 Brick2:136-753.31.5••91% -40°C - +85°CUL60950

30TB16FW_1.5

Download PDF

The 30TB16FW_1.5 series offer 25W of output. with 2:1 wide input voltage of 36-75VDC

Features:

  • SMD 1/16 Brick package (L x W x H) 33.0 x 22.9 x 8.6mm
  • 1500VDC isolation
  • Output over-voltage protection
  • Over-current protection
  • Over temperature protection
  • Input under-voltage lockout
  • Control-Pin / Trim-Pin
  • Meet EN55032 CLASS A
  • UL60950 approval
  • Efficiency up to 88%
  • Over current protection
  • Short-circuit protection (SCP)

All models are particularly suited to

  • tele-communications
  • industrial. test equipments power

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

30TB16FW_4803S1.5 483.3
Details30DMW_1.61“x1“2:19-18; 18-36; 36-753.3; 5; 12; 15; ±12; ±151.6••88%-40°C - +100°CUL60950

30DMW_1.6

Download PDF

The 30DMW_1.6 series are isolated 30W DC/DC converters.

Designed with high efficiency. They allow the operating temperature range of these units to be -40°C to +100°C (with derating) with industry-standard footprint.

Features:

  • DIP 1" x 1"" package (L x W x H) 25.4 x 25.4 x 10.4 mm
  • wide 2 : 1 input voltage range
  • 1600VDC Isolation
  • remote on/off control
  • trimmable output
  • shortcircuit protection
  • over voltage protection
  • over current protection
  • over temperature protection

These converters are well suitable for:

  • Battery operated equipment
  • Measurement equipment
  • Telecom
  • Wireless network
  • Industry control system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

30DMW_1203S1.6 123.3
30DMW_1205S1.6 125
30DMW_1212D1.6 1212
30DMW_1212S1.6 1212
30DMW_1215D1.6 1215
30DMW_1215S1.6 1215
30DMW_2403S1.6 243.3
30DMW_2405S1.6 245
30DMW_2412D1.6 2412
30DMW_2412S1.6 2412
30DMW_2415D1.6 2415
30DMW_2415S1.6 2415
30DMW_4803S1.6 483.3
30DMW_4805S1.6 485
30DMW_4812D1.6 4812
30DMW_4812S1.6 4812
30DMW_4815D1.6 4815
30DMW_4815S1.6 4815
Details30DMW4_1.61“x1“4:19-36; 18-753.3; 5; 12; 15; ±12; ±15 1.6••92%-40°C - +75°CUL60950

30DMW4_1.6

Download PDF

The 30DMW4_1.6 series are isolated 30W DC/DC converters. Designed with high efficiency. They allow the operating temperature range of these units to be -40°C to +85°C (with derating) with industry-standard footprint.

Features:

  • DIP 1" x 1" package (L x W x H) 25.4 x 25.4 x 10.4 mm
  • wide 4 : 1 input voltage range
  • 1600VDC Isolation
  • remote on/off control
  • trimmable output
  • shortcircuit protection
  • over voltage protection
  • over current protection
  • over temperature protection

These converters are well suitable for:

  • Battery operated equipment
  • Measurement equipment
  • Telecom
  • Wireless network
  • Industry control system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

30DMW4_2403S1.6 243.3
30DMW4_2405S1.6 245
30DMW4_2412D1.6 2412
30DMW4_2412S1.6 2412
30DMW4_2415D1.6 2415
30DMW4_2415S1.6 2415
30DMW4_4803S1.6 483.3
30DMW4_4805S1.6 485
30DMW4_4812D1.6 4812
30DMW4_4812S1.6 4812
30DMW4_4815D1.6 4815
30DMW4_4815S1.6 4815
Details30DAW8_1.62“x1“8:19-755; 12; 15; 24; ±12; ±151.6••91% -40°C - +70°CUL62368

30DAW8_1.6

Download PDF

The 30DAW8_1.6 series offer 20W of output. with 8:1 wide input voltage.

Features:

  • 2"x1"" package (L x W x H) 50.8 x 25,4 x 11.6mm
  • 8:1 input range
  • No-load power consumption 0,15W
  • Operating temperature range: -40°C - 83°C
  • 1600VDC isolation
  • Over current protection
  • Over voltage protection
  • Short-circuit protection
  • Six sided shielding
  • UL62368 approved

All models are are applied to wide voltage range input situation such as:

  • data transmission device
  • battery power supply device
  • telecommunication device
  • distributed power supply system
  • remote control system.
  • industrial robot system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details30DBW4_1.52“x1.6“4:19-36; 18-753.3; 5; 9; 12; 15; 241.5••89%-40°C - +75°C

30DBW4_1.5

Download PDF

The 30DBW4_1.5 series offer 30W of output. wide input voltage of 9-36VDC & 18-75VDC

Features:

  • 2"x1,6" case size (L x W x H) 50.8 x 40.6 x 11.8 mm
  • Efficiency up to 90%
  • 1500VDC isolation
  • Six-sided metal shield
  • Over current protection
  • Short circuit protection
  • Meet EN55022 CLASS A
  • Not recommended for new designs

All models are particularly suited to:

  • tele-communications
  • industrial test equipments power

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

30DBW4_2405D1.5 245
30DBW4_2405S1.5 245
30DBW4_2412D1.5 2412
30DBW4_2412S1.5 2412
30DBW4_2415D1.5 2415
30DBW4_2415S1.5 2415
30DBW4_4805D1.5 485
30DBW4_4805S1.5 485
30DBW4_4812D1.5 4812
30DBW4_4812S1.5 4812
30DBW4_4815D1.5 4815
30DBW4_4815S1.5 4815
Details30B16FW_1.51/16 Brick2:136-753.31.5••91% -40°C - +85°CUL60950

30B16FW_1.5

Download PDF

The 30B16FW_1.5 series offer 30W of output. with 2:1 wide input voltage of 36-75VDC

Features:

  • DIP 1/16 Brick package (L x W x H) 33.0 x 22.9 x 8.6mm
  • 1500VDC isolation
  • Output over-voltage protection
  • Over-current protection
  • Over temperature protection
  • Input under-voltage lockout
  • Control-Pin / Trim-Pin
  • Meet EN55032 CLASS A
  • UL60950 approval
  • Efficiency up to 88%
  • Over current protection
  • Short-circuit protection (SCP)

All models are particularly suited to

  • tele-communications
  • industrial. test equipments power

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

30B16FW_4803S1.5 483.3


40 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details40DAW_1.52“x1“2:19-18; 18-36; 36-753.3; 5; 12; 15; ±12; ±15 1.5••91%-40°C - +85°C

40DAW_1.5

Download PDF

The 40DAW_1.5 series are specially designed for applications where a wide range input voltage power supplies are isolated from the input power supply in a distributed power supply system on a circuit board.

Features:

  • 2"x1" Package Size (L x W x H) 50.8 x 25.4 x 10.2 mm
  • 2:1Wide Input Voltage.
  • Efficiency up To 91%
  • Under Voltage Lockout
  • Over Temperature Protection
  • 6-Side Shielded metal Case with insulated Baseplate
  • Remote Control:On/Off
  • Operating Temp. Range -40℃ to +85℃

Application Field:

  • Industry Control System
  • Semiconductor Equipment
  • Wireless Network
  • Telecom/Datacom
  • Measurement

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

40DAWE_4815S1.5 4815
Details40DAW8_1.62“x1“8:19-755; 12; 15; 24; ±12; ±15 1.6••91% -40°C - +60°C UL62368

40DAW8_1.6

Download PDF

The 40DAW8_1.6 series offer 20W of output. with 8:1 wide input voltage.

Features:

  • 2"x1"" package (L x W x H) 50.8 x 25,4 x 11.6mm
  • 8:1 input range
  • No-load power consumption 0,15W
  • Operating temperature range: -40°C - 83°C
  • 1600VDC isolation
  • Over current protection
  • Over voltage protection
  • Short-circuit protection
  • Six sided shielding
  • UL62368 approved

All models are are applied to wide voltage range input situation such as:

  • data transmission device
  • battery power supply device
  • telecommunication device
  • distributed power supply system
  • remote control system.
  • industrial robot system

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details40DDW_1.52“x2“2:19-18; 18-36; 36-753.3; 5; 12; 15; ±12; ±151.5••91%-40°C - +85°C

40DDW_1.5

Download PDF

The 40DDW_1.5 series offers 40W of output. wide input voltage of 9-18VDC. 18-36VDC. 36-75VDC

Features:

  • 2" x 2" Package (L x W x H) 51.0 x 51.0 x 10.3 mm
  • 1500VDC isolation
  • 2:1 Wide Input Voltage Range
  • High Efficiency Up To 90%
  • Under Voltage Lockout
  • Over Temperature Protection
  • Six-Sided Shield
  • Remote Control:On/Off

All models are particularly suited to

  • Industry Control System
  • Semiconductor Equipment
  • Wireless Network
  • Telecom/Datacom
  • Measurement

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

40DDW_1203S1.5 123.3
40DDW_1205S1.5 125
40DDW_1212D1.5 1212
40DDW_1212S1.5 1212
40DDW_1215D1.5 1215
40DDW_1215S1.5 1215
40DDW_2403S1.5 243.3
40DDW_2405S1.5 245
40DDW_2412D1.5 2412
40DDW_2412S1.5 2412
40DDW_2415D1.5 2415
40DDW_2415S1.5 2415
40DDW_4803S1.5 483.3
40DDW_4805S1.5 485
40DDW_4812D1.5 4812
40DDW_4812S1.5 4812
40DDW_4815D1.5 4815
40DDW_4815S1.5 4815
Details40DDW4_1.52“x2“4:19-36; 18-753.3; 5; 12; 15; ±12; ±15 1.5••90%-40°C - +85°C

40DDW4_1.5

Download PDF

The 40DDW4_1.5 series offers 40W of output. wide input voltage of 9-36VDC & 18-75VDC

Features:

  • 2" x 2" Package (L x W x H) 51.0 x 51.0 x 10.3 mm
  • 1500VDC isolation
  • 4:1 Wide Input Voltage Range
  • High Efficiency Up To 90%
  • Under Voltage Lockout
  • Over Temperature Protection
  • Six-Sided Shield
  • Remote Control:On/Off

All models are particularly suited to

  • Industry Control System
  • Semiconductor Equipment
  • Wireless Network
  • Telecom/Datacom
  • Measurement

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)



50 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details50DAW4_1.5R12“x1“4:118-755; 12; 15; 24 1.5••92%-40°C - +85°C

50DAW4_1.5R1

Download PDF

The 50DAW4_1.5R series offer 50W of output. with 4:1 ultra wide input voltage.

Features:

  • DIP 2" x1"case
  • 1500VDC isolation
  • over current protection
  • over voltage protection
  • short-circuit protection
  • six sided metal shielding

All models are particularly suited to industrial. tele-communications. test equipments power.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details50QBW_1.5Q-Brick2:19-18; 18-36; 36-725; 12; 15; 24; 281.5••85% -25°C - +70°C

50QBW_1.5

Download PDF

The 50QBW_1.5 Series is a high performance product with wide input voltage range. Output power contains 50W and no min. load requirement. Further product features include:

  • Q-Brick Package (L x W x H) 57.9 x 38.8 x 13.5mm
  • Input range 2:1
  • Isolation voltage : 1500VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Short circuit protection (SCP)
  • Remote control
  • Trim-Pin
  • Output voltage regulation functions

They are widely applied in battery power supplies, industrial control, electricity, instruments, railway, communication, intelligence robot fields.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Details50QBW4_1.5Q-Brick4:19-36; 18-755; 12; 15; 24; 281.5••85% -25°C - +70°C

50QBW4_1.5

Download PDF

The 50QBW4_1.5 Series is a high performance product with wide input voltage range. Output power contains 50W and no min. load requirement. Further product features include:

  • Q-Brick Package (L x W x H) 57.9 x 38.8 x 13.5mm
  • Input range 4:1
  • Isolation voltage : 1500VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Short circuit protection (SCP)
  • Remote control
  • Trim-Pin
  • Output voltage regulation functions

They are widely applied in battery power supplies, industrial control, electricity, instruments, railway, communication, intelligence robot fields.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



60 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details60DAW4_1.62“x1“4:19-36; 18-755; 12; 15; ±5; ±12; ±15 1.6••92,5%-40°C - +85°C

60DAW4_1.6

Download PDF

The 60DAW4_1.6 series offer 60W of output. with 4:1 ultra wide input voltage of 9-36VDC. 18-75VDC

Features:

  • DIP 2" x 1" package (L x W x H) 50.8 x 25.4 x 11.5 mm
  • 4:1 input range
  • 1600VDC isolation
  • Trim-Pin
  • Remote on/off
  • over current protection
  • over voltage protection
  • over temperature protection
  • soft start
  • No minimum load required
  • short-circuit protection
  • six sided metal shielding
  • RoHs compliant

Field Applications:

  • Industry Control System
  • Semiconductor Equipment
  • Wireless Network
  • Measurement

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

60DAW4_2405S1.6 245
60DAW4_2412D1.6 2412
60DAW4_2412S1.6 2412
60DAW4_2415D1.6 2415
60DAW4_2415S1.6 2415
60DAW4_4805S1.6 485
60DAW4_4812D1.6 4812
60DAW4_4812S1.6 4812
60DAW4_4815D1.6 4815
60DAW4_4815S1.6 4815
Details60DDW_32“x2“2:19-18; 18-36; 36-755; 12; 15; ±5; ±12; ±15 3••88%-40°C - +80°C

60DDW_3

Download PDF

The 60DDW_3 series offers 60W of output and wide input voltage of 18-36VDC. 36-75VDC

Features:

  • DIP package (L x W x H) 63.5 x 66.5 x 21.4 mm
  • 2:1 input range
  • 3000VDC isolation
  • High efficiency
  • Six-sided metal shield
  • Over current protection
  • Short circuit protection

All models are particularly suited to

  • Tele-communications
  • Industrial test equipments power

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

60DDW_1205D3 125
60DDW_1205S3 125
60DDW_1212D3 1212
60DDW_1212S3 1212
60DDW_1215D3 1215
60DDW_1215S3 1215
60DDW_2405D3 245
60DDW_2405S3 245
60DDW_2412D3 2412
60DDW_2412S3 2412
60DDW_2415D3 2415
60DDW_2415S3 2415
60DDW_4805D3 485
60DDW_4805S3 485
60DDW_4812D3 4812
60DDW_4812S3 4812
60DDW_4815D3 4815
60DDW_4815S3 4815
Details60DDW4_32“x2“4:19-36; 18-755; 12; 15; ±5; ±12; ±15 3••88%-40°C - +80°C

60DDW4_3

Download PDF

The 60DDW4_3 series offers 60W of output and wide input voltage of 9-36VDC. 18-75VDC

Features:

  • DIP package (L x W x H) 63.5 x 66.5 x 21.4 mm
  • 4:1 input range
  • 3000VDC isolation
  • High efficiency
  • Six-sided metal shield
  • Over current protection
  • Short circuit protection

All models are particularly suited to

  • Tele-communications
  • Industrial test equipments power

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

60DDW_2405D3 245
60DDW_2405S3 245
60DDW_2412D3 2412
60DDW_2412S3 2412
60DDW_2415D3 2415
60DDW_2415S3 2415
60DDW_4805D3 485
60DDW_4805S3 485
60DDW_4812D3 4812
60DDW_4812S3 4812
60DDW_4815D3 4815
60DDW_4815S3 4815


75 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details75HBW4_1.5H-Brick4:19-36; 18-753,3; 5; 12; 15; 24; 48 1.5••85% -40°C - +100°C

75HBW4_1.5

Download PDF

The 75HBW4_1.5 Series is a high performance product with wide input voltage range Wide input voltage 9-36VDC or 18-75VDC which allows the base plate temperature up to 100°C. Further product features include:

  • H-Brick Package (L x W x H) 57.9 x 57,9 x 12.7mm
  • Isolation voltage : 1500VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Short circuit protection (SCP)
  • Over temperature protection (OTP)
  • Remote control and compensated
  • Output voltage regulation functions

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

75HBW4_2403S1.5 243.3
75HBW4_2405S1.5 245
75HBW4_2412S1.5 2412
75HBW4_2415S1.5 2415
75HBW4_2424S1.5 2424
75HBW4_2448S1.5 2448
75HBW4_4803S1.5 483.3
75HBW4_4805S1.5 485
75HBW4_4812S1.5 4812
75HBW4_4815S1.5 4815
75HBW4_4824S1.5 4824
75HBW4_4848S1.5 4848
Details75HBAW4_1.5H-Brick4:19-36; 18-75; 40-1603,3; 5; 12; 15; 24 2,25••92% -40°C - +87°C

75HBAW4_1.5

Download PDF

The 75HBAW4_1.5 Series is a high performance product with wide input voltage range Wide input voltage 9-36VDC or 18-75VDC which allows the base plate temperature up to 100°C. Further product features include:

  • H-Brick Package (L x W x H) 57.9 x 57,9 x 12.7mm
  • Isolation voltage : 1500VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Short circuit protection (SCP)
  • Over temperature protection (OTP)
  • Remote control and compensated
  • Output voltage regulation functions

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



100 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details100HBAW_1.5H-Brick2:1 ; 4:19-18; 18-36; 9-36; 18-723.3; 5; 12; 15; 24; 481.5••90%-40°C - +85°C

100HBAW_1.5

Download PDF

The 100HBAW_1.5 series offers 100W of output. wide input voltage of 2:1 (9-18VDC; 18-36VDC; 36-72VDC) & 4:1 (9-36VDC; 18-72VDC). and features:

  • I/O isolation 1500VDC
  • input under voltage protection
  • over current protection
  • short circuit protection

All models are particularly suited to tele-communications. industrial. test equipments power etc.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

100HBAW4_xx03S1.5 xx3.3
100HBAW4_xx05S1.5 xx5
100HBAW4_xx12S1.5 xx12
100HBAW4_xx15S1.5 xx15
100HBAW4_xx24S1.5 xx24
100HBAW4_xx48S1.5 xx48
100HBAW_xx03S1.5 xx3.3
100HBAW_xx05S1.5 xx5
100HBAW_xx12S1.5 xx12
100HBAW_xx15S1.5 xx15
100HBAW_xx24S1.5 xx24
100HBAW_xx48S1.5 xx48


150 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details150HB4_1.5H-Brick4:118-7228; 481.5••80%-25°C - +85°C

150HB4_1.5

Download PDF

The 150HB4_1.5 series offers 150W of output. wide input voltage of 4:1 (18-72VDC). and features_

  • I/O isolation 1500VDC
  • input under voltage protection
  • over current protection
  • short circuit protection

All models are particularly suited to tele-communications. industrial. test equipments power etc.

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

150HB4_11003S1.5 1103.3
150HB4_11005S1.5 1105
150HB4_11012S1.5 11012
150HB4_11015S1.5 11015
150HB4_11018S1.5 11018
150HB4_11024S1.5 11024
150HB4_11028S1.5 11028
150HB4_11036S1.5 11036
150HB4_11048S1.5 11048
150HB4_1812S1.5 1812
150HB4_1815S1.5 1815
150HB4_1824S1.5 1824
150HB4_1828S1.5 1828
150HB4_1848S1.5 1848
150HB4_4812S1.5 4812
150HB4_4815S1.5 4815
150HB4_4824S1.5 4824
150HB4_4828S1.5 4828
150HB4_4848S1.5 4848
150HB_1212S1.5 1212
150HB_1215S1.5 1215
150HB_1224S1.5 1224
150HB_1228S1.5 1228
150HB_1248S1.5 1248
150HB_2403S1.5 243.3
150HB_2405S1.5 245
150HB_2412S1.5 2412
150HB_2415S1.5 2415
150HB_2418S1.5 2418
150HB_2424S1.5 2424
150HB_2428S1.5 2428
150HB_2436S1.5 2436
150HB_2448S1.5 2448
150HB_4803S1.5 483.3
150HB_4805S1.5 485
150HB_4812S1.5 4812
150HB_4815S1.5 4815
150HB_4818S1.5 4818
150HB_4824S1.5 4824
150HB_4828S1.5 4828
150HB_4836S1.5 4836
150HB_4848S1.5 4848
Details150HBRW4_3H-Brick4:150-16012; 15; 243••91% -40°C - +100°CEN50155

150HBRW4_3

Download PDF

The 150HBRW4_3 Series is a high performance railway product with Five-sided metal shielding package.Output power contains 150W and no min. load requirement. Wide input voltage 50-160VDC, which allows the base plate temperature up to 100°C. Further product features include:

  • H-Brick Package (L x W x H) 61.0 x 57.9.x 12.7mm
  • Isolation voltage: 3000VDC
  • Meets requirements of railway standard EN50155
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Short circuit protection (SCP)
  • Over temperature protection
  • Remote control and compensated
  • Five-sided metal shielding package
  • Output voltage regulation functions

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

150HBRW4_11012S3 11012
150HBRW4_11015S3 11015
150HBRW4_11024S3 11024


200 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details200QBOW_1.5Q-Brick2:136-755; 12; 24; 482.25••91% -40°C - +85°C

200QBOW_1.5

Download PDF

The 200QBOW_1.5 Series of isolated 200W DC_DC converter products with an 2:1 input voltage range.

Further product features include:

  • Q-Brick open-frame package (L x W x H) 57.90 x 36.80 x 10.05mm
  • Efficiency: 93%
  • Isolation voltage. 1500VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Short circuit protection (SCP)
  • Over temperature protection
  • Remote control and compensated
  • Output voltage regulation functions

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



350 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details350HBAW_1.5H-Brick2:120-3612; 24; 28; 321.5••89% -40°C - +100°C

350HBAW_1.5

Download PDF

The 350HBAW4_1.5 Series of isolated 350 Watt DC-DC products with a 2:1 input voltage range.

Further product features include:

  • H-Brick Package (L x W x H) 61.0 x 57.9.x 12.7mm
  • Isolation voltage: 1500VDC
  • Operating temperature range -40° ~ + 100°C
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Short circuit protection (SCP)
  • Over temperature protection
  • Remote control and trim-pin function
  • Five-sided metal shielding package
  • Output voltage regulation functions

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



400 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details400HBW_2.25H-Brick4:136-7512; 15; 24; 282.25••91% -40°C - +85°C

400HBW_2.25

Download PDF

The 400HBW_2.25 Series is a high performance product with Five-sided metal shielding package.Output power contains 400W and no min. load requirement. Wide input voltage 36-75VDC, which allows the base plate temperature up to 85°C. Further product features include:

  • H-Brick Package (L x W x H) 57.9 x 61.0 x 12.7mm
  • Efficiency: 95%
  • Isolation voltage. 2250VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Short circuit protection (SCP)
  • Over temperature protection
  • Remote control and compensated
  • Output voltage regulation functions

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



450 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details450HBAW_1.5H-Brick2:136-7528; 481.5••94,5% -40°C - +100°CUL60950

450HBAW_1.5

Download PDF

The 450HBAW_1.5 Series are half-brick DC/DC converters that provide a high efficiency single output. The remote control option is negative logic. The output voltage trim option is positive.

Wide input voltage 36-75VDC, which allows the base plate temperature up to 100°C. Further product features include:

  • H-Brick Package (L x W x H) 61.0 x 57,9 x 12.7mm
  • Efficiency: 93%
  • Isolation voltage. 1500VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Outout over currentprotection (OOC)
  • Short circuit protection (SCP)
  • Remote On/Off logic
  • Trim logic
  • Over temperature protection
  • Remote control and compensated
  • Output voltage regulation functions
  • Meets ETSI 300-132-2
  • UL60950 approval

Applications

  • Distrubuted Power Architectures
  • Wireless Networks
  • RF amplifier
  • Broadband/CATV amplifier

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

450HBAW_4848S1.5 4848


500 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details500HBAW_1.5H-Brick2:136-75501.5••93% -40°C - +100°CUL60950

500HBAW_1.5

Download PDF

The 500HBAW_1.5 Series are half-brick DC/DC converters that provide a high efficiency single output. The remote control option is negative logic. The output voltage trim option is positive.

Wide input voltage 36-75VDC, which allows the base plate temperature up to 100°C. Further product features include:

  • H-Brick Package (L x W x H) 61.0 x 57,9 x 12.7mm
  • Efficiency: 93%
  • Isolation voltage. 1500VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Outout over currentprotection (OOC)
  • Short circuit protection (SCP)
  • Remote On/Off logic
  • Trim logic
  • Over temperature protection
  • Remote control and compensated
  • Output voltage regulation functions
  • Meets ETSI 300-132-2
  • UL60950 approval

Applications

  • Distrubuted Power Architectures
  • Wireless Networks
  • RF amplifier
  • Broadband/CATV amplifier

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

500HBAW_xxyyS1.5 xxyy
Details500HBAW_2.25H-Brick2:118-3612; 15; 24; 282.25••94% -40°C - +100°C

500HBAW_2.25

Download PDF

The 500HBAW_2.25 Series are half-brick DC/DC converters that provide a high efficiency single output.

Wide input voltage 6-42VDC, which allows the base plate temperature up to 100°C. Further product features include:

  • H-Brick Package (L x W x H) 57.9 x 61.0 x 12.7mm
  • Efficiency: 94%
  • Isolation voltage. 2250VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Outout over currentprotection (OOC)
  • Short circuit protection (SCP)
  • Remote On/Off logic
  • Trim logic
  • Over temperature protection
  • Remote control and compensated
  • Output voltage regulation functions

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).



700 Watts DC-DC Converters


Series

Case Size

Input Range

Input Voltage (VDC)

Output Voltage (VDC)

Output Current (A)

Isolation (kVDC)

Regulation

SCP *

η max.

Operating Temp.

Dimming

Certs

Details700HBAW_1.5H-Brick2:136-7528; 501.5••94% -40°C - +100°CUL60950

700HBAW_1.5

Download PDF

The 700HBAW_1.5 Series are half-brick DC/DC converters that provide a high efficiency single output. The remote control option is negative logic. The output voltage trim option is positive.

Wide input voltage 36-75VDC, which allows the base plate temperature up to 100°C. Further product features include:

  • H-Brick Package (L x W x H) 61.0 x 58.0 x 12.7mm
  • Efficiency: 94%
  • Isolation voltage. 1500VDC
  • Input under-voltage protection (UVP)
  • Output overvoltage protection (OOP)
  • Outout over currentprotection (OOC)
  • Short circuit protection (SCP)
  • Remote On/Off logic
  • Trim logic
  • Over temperature protection
  • Remote control and compensated
  • Output voltage regulation functions
  • Meets ETSI 300-132-2
  • UL60950 approval

Applications

  • Distrubuted Power Architectures
  • Wireless Networks
  • RF amplifier
  • Broadband/CATV amplifier

Download PCB Footprints and Schematic Symbols for free, to download/request, please click the Logo on the right in the below Selection Guide.


Please check with our Distribution Partners for component availability by clicking onto their logo. Available components are shown in the Selection Guide below ( = stocked item).

Part number


Available at Digikey.
Click green button.

Input Voltage (VDC)

Output Voltage (VDC)

700HBAW_xxyyS1.5 xxyy
  • Legal notice
  • Disclaimer/Privacy Policy
  • Terms & Conditions

© 2025 GAPTEC Electronic, All Rights Reserved.

  • Home
  • Products
    ▼
    • Power-Chart Overview
    • AC-DC Modules (Industrial)
    • AC-DC Modules (Medical)
    • AC-DC Power Supply Medical
    • AC DC DIN Rail
    • AC-DC Off Board (Housing)
    • AC-DC Off Board (Open Frame)
    • DC-DC Converters (Industrial)
    • DC-DC Converters (Railway)
    • DC-DC Converters (Telecom Power)
    • DC-DC Converters (IGBT & SiC)
    • DC-DC Converters (Photovoltaic)
    • DC-DC Converters (POL)
    • DC-DC Converters (PoE)
  • Isolation Calculator
  • About us
  • Info
  • Application Notes
    ▼
    • Video: Linear Regulators
      vs. Switching Regulators
    • AC-DC
      Application Notes
    • Fixed Input (DC-DC)
      Application Notes
    • Wide Input (DC-DC)
      Application Notes
    • Railway (DC-DC)
      Application Notes
    • IGBT (DC-DC)
      Application Notes
    • Photovoltaic (DC-DC)
      Application Notes
    • Non-Isolated Switching Regulator
      Application Notes
    • LED (DC-DC)
      Application Notes
  • Approvals & Certifications
  • Components Service
  • Press Releases
  • Contact
  • 3D CAD
  • English
    ▼
    • Deutsch
We use cookies on our website to give you the most relevant experience by remembering your preferences and repeat visits. By clicking “Accept”, you consent to the use of ALL the cookies. However you may visit Cookie Settings to provide a controlled consent.
Cookie settingsAccept
Privacy & Cookies Policy

Privacy Preference Centre

When you visit any web site, it may store or retrieve information on your browser, mostly in the form of cookies. This information might be about you, your preferences or your device and is mostly used to make the site work as you expect it to. The information does not usually directly identify you, but it can give you a more personalised web experience. Because we respect your right to privacy, you can choose not to allow some types of cookies. Click on the different category headings to find out more and change our default settings. However, blocking some types of cookies may impact your experience of the site and the services we are able to offer. More information

Strictly Necessary Cookies
Always Enabled

These cookies are necessary for the website to function and cannot be switched off in our systems. You can set your browser to block or alert you about these cookies, but some parts of the site will not work as a result. These cookies are not used to market or advertise to site visitors.

Performance Cookies

These cookies allow us to count visits and traffic sources so we can measure and improve site performance. Information these cookies collect is anonymous. If you do not allow these cookies we will not know when you have visited our site, and will not be able to monitor its performance.

Functional Cookies

These cookies enable the website to provide enhanced functionality and personalization. They may be set by us or by third party providers whose services we have added to our pages. If you do not allow these cookies then some or all of these services may not function properly.

Targeting Cookies

These cookies may be set through our site by our advertising partners, or by social media services that we have added to the site to enable you to share our content with your friends and networks. These cookies have been disabled for visitors from certain geographies in compliance with local law.

  • English
  • German
